Icom IC-F1710 Service Manual

[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C503 4030017420 S.CER ECJ0EC1H470J T 106.9/106.7
C504 4030017420 S.CER ECJ0EC1H470J T 112.6/106.7
C505 4030017420 S.CER ECJ0EC1H470J T 128.6/106.9
C508 4030017420 S.CER ECJ0EC1H470J B 110.8/106.6
C509 4030017420 S.CER ECJ0EC1H470J T 99.9/87.6
C511 4030017420 S.CER ECJ0EC1H470J T 102.9/106.7
C513 4030017420 S.CER ECJ0EC1H470J T 135.9/106.9
C515 4030017030 S.CER ECJ0EB1A273K T 99.1/70.8
C516 4030017580 S.CER ECJ0EC1H060C [L] B 46.3/71.5
4030017620 S.CER ECJ0EC1H100C [H] B 46.3/71.5
C522 4550000560 S.TAN TEESVA 1V 334M-8L B 81.2/61.9
C523 4550003250 S.TAN TEESVA 1V 474M8L B 81.2/59.6
C525 4030017770 S.CER ECJ0EB1E332K B 76.2/59.9
C526 4030016930 S.CER ECJ0EB1A104K T 25.4/14.7
C527 4030016930 S.CER ECJ0EB1A104K T 25.9/17.1
C529 4510006220 S.ELE ECEV1CA101UP T 24.4/40.4
C533 4030017420 S.CER ECJ0EC1H470J B 66.9/96.7
C534 4030017400 S.CER ECJ0EC1H220J B 66.9/97.7
C535 4030017460 S.CER ECJ0EB1E102K B 41.9/50.2
C536 4030017460 S.CER ECJ0EB1E102K B 41.8/49.2
C537 4030017380 S.CER ECJ0EC1H050B
[F2721D], [F2821D] only B 95.3/35.3
C538 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only B 90.5/35.9
C539 4030016930 S.CER ECJ0EB1A104K
[F2721D], [F2821D] only B 94.4/32.9
C540 4030017530 S.CER ECJ0EC1H0R5B T 61.7/51.8
C541 4030017600 S.CER ECJ0EC1H080C [L] T 65.8/49.3
4030017630 S.CER ECJ0EC1H120J [H] T 65.8/49.3
C542 4030017580 S.CER ECJ0EC1H060C [H] T 61/50.3
4030017620 S.CER ECJ0EC1H100C [L] T 61/50.3
C543 4030017640 S.CER ECJ0EC1H150J T 65.8/47.3
C544 4030017630 S.CER ECJ0EC1H120J [H] T 67.6/47.3
4030017670 S.CER ECJ0EC1H390J [L] T 67.6/47.3
C545 4030017460 S.CER ECJ0EB1E102K B 62.4/47.9
C546 4030017600 S.CER ECJ0EC1H080C [H] T 67.6/48.3
4030017640 S.CER ECJ0EC1H150J [L] T 67.6/48.3
C547 4030017460 S.CER ECJ0EB1E102K T 61/49.3
C548 4030017420 S.CER ECJ0EC1H470J T 61/48.3
C549 4030017420 S.CER ECJ0EC1H470J T 53/55.8
C550 4030017420 S.CER ECJ0EC1H470J B 66.5/51.2
C551 4030011050 S.CER GRM31M3C2H3R0CY21L [H] T 11.3/91.5
4030011060 S.CER GRM31M2C2H4R0CY21L
[F2710-L], [F2810-L] T 11.3/91.5
4030011070 S.CER GRM31M2C2H5R0CY21L
[F2721/D-L], [F2821/D-L] T 11.3/91.5
C552 4030011030 S.CER GRM31M4C2H1R5CY21L
[Other] T 6.5/91.5
4030011060 S.CER GRM31M2C2H4R0CY21L
[F2710-H], [F2810-H] T 6.5/91.5
4030011070 S.CER GRM31M2C2H5R0CY21L
[F2721/D-L], [F2821/D-L] T 6.5/91.5
C554 4030017550 S.CER ECJ0EC1H1R5B [H] T 62.7/46.3
4030017570 S.CER ECJ0EC1H040B [L] T 62.7/46.3
C555 4550007080 S.TAN TEESVA 1C 106M8R B 66.6/53
C556 4030016930 S.CER ECJ0EB1A104K T 28.7/21.1
C557 4030017460 S.CER ECJ0EB1E102K T 55.8/8.5
C568 4030017720 S.CER ECJ0EB1H331K T 118.7/54.6
C569 4030017420 S.CER ECJ0EC1H470J T 75.3/34.7
C570 4030016930 S.CER ECJ0EB1A104K B 66.2/15.3
C571 4030017520 S.CER ECJ0EC1H0R3B [H] B 69/90.5
4030017530 S.CER ECJ0EC1H0R5B [L] B 69/90.5
C572 4030016790 S.CER ECJ0EB1C103K B 64.8/34.2
C573 4030011060 S.CER GRM31M2C2H4R0CY21L [L] T 5.8/103.3
4030011070 S.CER GRM31M2C2H5R0CY21L [H] T 5.8/103.3
C575 4030017550 S.CER ECJ0EC1H1R5B B 76.2/96.1
C576 4030016930 S.CER ECJ0EB1A104K T 51.1/45.7
C577 4030016930 S.CER ECJ0EB1A104K T 51.1/54.6
C578 4030017420 S.CER ECJ0EC1H470J B 13.7/60.7
C580 4030016930 S.CER ECJ0EB1A104K B 115.7/100.8
C581 4030016940 S.CER ECJ0EB1A393K B 69.3/40.7
C582 4030016930 S.CER ECJ0EB1A104K B 71.6/39.5
C583 4030017790 S.CER ECJ0EB1E682K B 71.6/41.7
C584 4030016970 S.CER ECJ0EB1C223K B 79.4/40.5
C585 4030016930 S.CER ECJ0EB1A104K B 62.6/24.2
C586 4030016930 S.CER ECJ0EB1A104K
J1 6510024520 S.CNR 12FLT-SM1-TB T 72.5/12.1
J2 6510018430 S.CNR AXN330C038P T 139.7/8.3
J3 6510021300 S.CNR 52365-1091
[F2721D], [F2821D] only T 96/41.5
J4 6510018430 S.CNR AXN330C038P
except [F2721D], [F2821D] only T 91.5/8.5
J5 6450000140 CNR HSJ0807-01-010
J6 6510014960 S.CNR B2B-ZR-SM3-TF T 147.7/79.4
J7 6510021300 S.CNR 52365-1091 T 88/77.7
J8 6510019250 S.CNR B11B-ZR-SM3-TF T 155.6/27.9
J10 6510019270 S.CNR 52365-0691 T 88/71
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
J11 6510023210 CNR CD6125SA1J0 <CVI>
J13 6510021300 S.CNR 52365-1091 T 84.9/93.5
W2 7120000470 JMP ERDS2T0
W3 8900013680 CBL OPC-1414 <CMI>T!
EP5 6910015370 S.BEA ACZ1005Y-102-T B 85.7/40.7
EP6 6910015370 S.BEA ACZ1005Y-102-T T 53/54.8
EP7 6910011560 BEA HF70BB4.5X5X1.6
EP8 6910011560 BEA HF70BB4.5X5X1.6
EP9 6910015370 S.BEA ACZ1005Y-102-T B 62.4/50.7
EP10 6910010280 BEA HF70BB9.5X10.4X4.9
EP11 6910010280 BEA HF70BB9.5X10.4X4.9
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
6 - 11
[CHASSIS UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
J1 6510004880 CNR MR-DS-E 01
