S.=Surface mount
6 - 7
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R367 7030000020 S.RES MCR10EZHJ 1
Ω
(010) B 151.5/57.9
R368 7030000020 S.RES MCR10EZHJ 1
Ω
(010) B 151.5/47.4
R370 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) T 96.9/76.1
R371 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 84.7/74.5
R372 7030005651 S.RES ERA3YKD 304V (300 k
Ω
) B 131/70.2
R373 7030005871 S.RES ERA3YKD 104V (100 k
Ω
) B 131/67.6
R374 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 93/78.7
R375 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 35/46.9
R376 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) B 36.1/46.9
R377 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 142.9/36
R378 7540000290 ABSB ERZV10D220
R383 7030006610 S.RES ERJ2GEJ 394 X (390 k
Ω
) T 29.6/28.7
R387 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 101.2/67.8
R391 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 97.4/77.2
R392 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 103.2/54.2
R393 7410000730 S.ARY EXB-V8V 104JV (100 k
Ω
) B 94.4/49.2
R394 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) B 68/8.1
R395 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 70.8/9.8
R396 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 68/6.1
R397 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 65.7/6.6
R398 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 90.1/58.7
R399 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 132.6/58.1
R400 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) T 62.6/7.4
R401 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) T 61.3/6.9
R402 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 132.4/14.3
R405 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 130.1/106.1
R406 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 126/106.1
R407 7030000100 S.RES MCR10EZHJ 4.7
Ω
(4R7) T 110.5/106.8
R408 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
)
[F1721D], [F1821D] only T 118/19.2
R409 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 105.9/106.7
R410 7030000100 S.RES MCR10EZHJ 4.7
Ω
(4R7) B 116.3/106
R411 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 124.2/106.1
R413 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 128.5/106.1
R414 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 109.5/106.1
R415 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 131.9/106.1
R416 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 133.7/106.1
R417 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 103.9/106.7
R419 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 110.3/88.1
R420 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 103.1/95.3
R421 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 45.9/21.9
R422 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 52.1/61.6
R424 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 151.7/79.8
R425 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 28.3/21.4
R426 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) B 27.3/21.4
R427 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 72.9/9.1
R428 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) B 73.2/53.9
R429 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
Ω
) B 74.6/53.8
R430 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
Ω
) B 78.9/52.6
R431 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 69.7/51.2
R432 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 73.2/46.7
R433 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
Ω
) T 74.1/46.7
R434 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 57/9.8
R435 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 64/6.6
R436 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 102.1/95.3
R437 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F1721D], [F1821D] only T 123.3/7.4
R438 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
)
[F1721D], [F1821D] only T 124.2/7.4
R439 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 82.1/86
R440 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 79.2/89.2
R441 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
)
[F1721D], [F1821D] only T 123/24.4
R442 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 94.3/52.5
R444 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 143.2/13.1
R445 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 142.2/13.1
R446 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
)
[F1721D], [F1821D] only B 90/36.8
R447 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
)
[F1721D], [F1821D] only B 94.1/30.8
R448 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
)
[F1721D], [F1821D] only B 94.1/31.8
R449 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 109.3/54.5
R450 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 103.2/66.7
R451 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 16.9/29.1
C1 4030017420 S.CER ECJ0EC1H470J T 77.2/10.4
C2 4030017420 S.CER ECJ0EC1H470J T 78.2/10.4
C3 4030017460 S.CER ECJ0EB1E102K T 75.9/67.5
C4 4030017330 S.CER ECJ0EF1C104Z T 81.4/61.8
C5 4030017420 S.CER ECJ0EC1H470J T 81/64.9
C6 4030017420 S.CER ECJ0EC1H470J T 80.1/65.3
C7 4030017460 S.CER ECJ0EB1E102K B 83.1/33.3
C10 4030017460 S.CER ECJ0EB1E102K T 48.3/36.2
C11 4550000460 S.TAN TEESVA 1C 105M8L T 49.8/37.3
C12 4030016930 S.CER ECJ0EB1A104K T 148.2/9.1
C13 4550000460 S.TAN TEESVA 1C 105M8L T 51.9/37.3
C14 4030017420 S.CER ECJ0EC1H470J T 44.8/35.2
C15 4030017420 S.CER ECJ0EC1H470J T 42.7/24.7
C16 4030017420 S.CER ECJ0EC1H470J T 45.4/33.4
C17 4030017420 S.CER ECJ0EC1H470J T 43.7/24.7
C18 4030017420 S.CER ECJ0EC1H470J T 46.1/35.2
C19 4030016970 S.CER ECJ0EB1C223K T 52.8/23.2
C20 4030017420 S.CER ECJ0EC1H470J T 46.8/33.4
C21 4030016930 S.CER ECJ0EB1A104K T 50.5/16
C22 4030017420 S.CER ECJ0EC1H470J B 50.3/31.4
C24 4030017420 S.CER ECJ0EC1H470J B 135.2/8.5
C25 4030017460 S.CER ECJ0EB1E102K B 143.1/16.1
C26 4030017420 S.CER ECJ0EC1H470J T 72.7/8.7
C27 4030017420 S.CER ECJ0EC1H470J T 68.8/8.7
C28 4030017420 S.CER ECJ0EC1H470J T 70.2/15.4
C29 4030017420 S.CER ECJ0EC1H470J B 74.7/39.4
C30 4030017510 S.CER ECJ0EC1H680J B 80.5/37.9
C31 4030017330 S.CER ECJ0EF1C104Z T 71.4/60.7
C32 4510004630 S.ELE ECEV1CA100SR T 73.3/64.6
C33 4030017420 S.CER ECJ0EC1H470J T 79.2/66.9
C34 4030017620 S.CER ECJ0EC1H100C B 40.1/29
C35 4030017730 S.CER ECJ0EB1E471K B 80.5/34.3
C36 4550005980 S.TAN TEESVA 1A 475M8L B 85.3/34.9
C37 4030017710 S.CER ECJ0EC1H181J T 53/25.9
C38 4030017400 S.CER ECJ0EC1H220J B 44.2/14.8
C39 4030017760 S.CER ECJ0EB1H222K B 50.8/34.5
C41 4030017760 S.CER ECJ0EB1H222K T 67.1/12.2
C42 4030017460 S.CER ECJ0EB1E102K T 68.1/14.3
C43 4030017420 S.CER ECJ0EC1H470J T 137/12.8
C44 4030017460 S.CER ECJ0EB1E102K B 140.3/6.2
C45 4030017460 S.CER ECJ0EB1E102K T 131.1/6
C46 4030017420 S.CER ECJ0EC1H470J T 74.6/16.3
C47 4030017420 S.CER ECJ0EC1H470J T 72.2/15.4
C48 4030017460 S.CER ECJ0EB1E102K T 71.4/61.7
C49 4030017460 S.CER ECJ0EB1E102K T 72.8/51.3
C50 4030017420 S.CER ECJ0EC1H470J T 76.4/51.7
C51 4030016790 S.CER ECJ0EB1C103K B 38.5/26.1
C52 4030016930 S.CER ECJ0EB1A104K B 39.5/26.1
C53 4030016790 S.CER ECJ0EB1C103K B 37/26.6
C54 4030017500 S.CER ECJ0EC1H560J B 34.2/27.9
C55 4030017570 S.CER ECJ0EC1H040B B 32.7/28.4
C56 4030017590 S.CER ECJ0EC1H070C B 31.2/27.9
C57 4030016930 S.CER ECJ0EB1A104K B 69.2/34.5
C58 4030016790 S.CER ECJ0EB1C103K B 70.5/35.7
C59 4030016940 S.CER ECJ0EB1A393K B 66.1/34.2
C60 4510004630 S.ELE ECEV1CA100SR T 45.8/18.1
C61 4030017760 S.CER ECJ0EB1H222K B 56.4/19
C62 4030017460 S.CER ECJ0EB1E102K T 46.9/21
C63 4030017400 S.CER ECJ0EC1H220J B 45.7/24.9
C64 4030016930 S.CER ECJ0EB1A104K T 49.2/21.7
C65 4030016930 S.CER ECJ0EB1A104K B 53.9/33.2
C66 4030016930 S.CER ECJ0EB1A104K B 64.6/14.9
C67 4030016930 S.CER ECJ0EB1A104K T 10.1/23
C68 4030017640 S.CER ECJ0EC1H150J B 14.7/28.2
C69 4030017390 S.CER ECJ0EC1H180J B 14.7/24
C70 4030016930 S.CER ECJ0EB1A104K B 83.9/44.7
C71 4030017620 S.CER ECJ0EC1H100C B 76.6/45.2
C72 4030017460 S.CER ECJ0EB1E102K B 83.9/47.2
C73 4030017430 S.CER ECJ0EC1H101J T 77.9/51.2
C75 4030017460 S.CER ECJ0EB1E102K B 74.9/55.7
C76 4030017460 S.CER ECJ0EB1E102K T 75/33.5
C77 4030016930 S.CER ECJ0EB1A104K T 57/26.4
C78 4030017750 S.CER ECJ0EB1E122K T 55.7/25.9
C79 4030016930 S.CER ECJ0EB1A104K B 72/40.8
C80 4030017460 S.CER ECJ0EB1E102K B 73/40.8
C81 4030016930 S.CER ECJ0EB1A104K T 13.8/23.4
C82 4030016930 S.CER ECJ0EB1A104K T 86.2/49.6
C83 4030017460 S.CER ECJ0EB1E102K T 71.4/46.7
C84 4030017460 S.CER ECJ0EB1E102K T 74.7/49.1
C85 4030017570 S.CER ECJ0EC1H040B B 76.2/57.4
C86 4030017360 S.CER ECJ0EC1H030B B 73.9/57.4
C87 4030017360 S.CER ECJ0EC1H030B B 27.5/28.4
C88 4030016930 S.CER ECJ0EB1A104K B 25.5/15.3
C89 4030016930 S.CER ECJ0EB1A104K B 29.5/15.3
C90 4030016930 S.CER ECJ0EB1A104K T 76.5/27.8
C92 4030017710 S.CER ECJ0EC1H181J T 71.2/37.1
C93 4030016930 S.CER ECJ0EB1A104K B 68.5/38
C94 4030016930 S.CER ECJ0EB1A104K T 112.6/46.3
C95 4030016930 S.CER ECJ0EB1A104K T 63.7/14
C96 4030016930 S.CER ECJ0EB1A104K T 68.6/22.2
C98 4030016930 S.CER ECJ0EB1A104K
[F1721D], [F1821D] only T 83.3/37.1
C100 4030016930 S.CER ECJ0EB1A104K
[F1721D], [F1821D] only T 82/36.6
C104 4030017600 S.CER ECJ0EC1H080C B 72.1/57.4
C106 4030017360 S.CER ECJ0EC1H030B B 70.6/56.9
C107 4030016930 S.CER ECJ0EB1A104K T 23.9/23.7
C108 4030016930 S.CER ECJ0EB1A104K B 29.9/21.3
C109 4030016930 S.CER ECJ0EB1A104K T 111.6/65.2
C110 4030016930 S.CER ECJ0EB1A104K B 137.6/5.3
C111 4030016930 S.CER ECJ0EB1A104K T 77.5/23.8
C112 4030016930 S.CER ECJ0EB1A104K T 71/22.2
C113 4030016930 S.CER ECJ0EB1A104K T 118.5/48.5
C114 4030016930 S.CER ECJ0EB1A104K T 115.7/46.6
C115 4030017420 S.CER ECJ0EC1H470J T 116.7/47.6
C116 4030017720 S.CER ECJ0EB1H331K T 107.9/54
C119 4030016930 S.CER ECJ0EB1A104K
[F1721D], [F1821D] only B 81.4/20.3
C120 4030017460 S.CER ECJ0EB1E102K T 74.7/41.6
