29
7
OPTIONS
VOX gain and delay adjustment
q Attach the connector of the VS-1SC into the multi-connec-
tor on the transceiver and tighten the screw.
• Toggle the VOX/PTT select switch to [VOX].
w Enter user set mode. (p. 16)
e Push [P0] several times to select the “VOX Gain” or “VOX
Delay” items. Then, push [Side2] or [Side3] to set the de-
sired level/condition.
r Rotate [VOL] to turn the power OFF to exit user set mode.
• VOX Gain
The VOX sensitivity level can be adjusted from OFF or 1 to 6
(more sensitive).
VOX function is OFF
X
TXC
SET
CALA
SET
TXCU
TXC
CALA
SET
TXCU
TXC
VOX OFF VOX GAIN 3
VOX gain level 3
(default)
X
TXC
SET
[Side2]
Push
[Side3]
• VOX Delay
The VOX delay time can be set from 0.5 to 3.0 sec. (0.5 sec.
step) for a convenient interval before returning to receive.
0.5 sec (min.)
(default)
X
TXC
SET
CALA
SET
TXCU
TXC
CALA
SET
TXCU
TXC
VOX DLY0.5 VOX DLY3.0
3.0 sec (max.)
X
TXC
SET
[Side2]
Push
[Side3]
NOTE: MIC/VOX gain can be adjusted via the Adjusting
pot using a thin screw driver.
