Icom IC-F320 Service Manual

J1 6450001470 CONNECTOR 95003-2881
J2 6510020510 S.CONNECTOR FH12-40S-0.5SV
DS1 5030001540 LCD LD-HU10140J C only
DS2 5040002310 S.LED SML-311YTT86 C only
DS3 5040002310 S.LED SML-311YTT86 C only
DS4 5040002310 S.LED SML-311YTT86 C only
DS5 5040002310 S.LED SML-311YTT86 C only
DS6 5040002310 S.LED SML-311YTT86 C only
DS7 5040002310 S.LED SML-311YTT86 C only
DS8 5040002310 S.LED SML-311YTT86
DS9 5040002310 S.LED SML-311YTT86
DS10 5040002310 S.LED SML-311YTT86
DS11 5040002310 S.LED SML-311YTT86
DS12 5040001760 S.LED SEC 2422C E only
DS13 5040002310 S.LED SML-311YTT86 C only
DS14 5040002310 S.LED SML-311YTT86 C only
DS15 5040002310 S.LED SML-311YTT86 C only
DS16 5040002310 S.LED SML-311YTT86 C only
DS17 5040002310 S.LED SML-311YTT86 C only
W1 7030000010 S.JUMPER MCR10EZHJ JPW (000)
W2 7030003860 S.JUMPER ERJ3GE JPW V
W3 8900007680 CABLE OPC-741
EP1 0910049322 PCB B 5042B C
0910051231 PCB B 5289A E
EP2 8930044930 LCD CONTACT SRCN-2055-SP-N-W C only
[FRONT UNIT][FRONT UNIT]
S.=Surface mount
C1 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C2 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C3 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C4 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C5 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C6 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C7 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C8 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C9 4550006200 S.TANTALUM ECST0JY106R
C10 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C11 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C12 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C13 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C14 4550006140 S.TANTALUM ECST1EY474R
C15 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C16 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C17 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C18 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C19 4030009920 S.CERAMIC C1608 CH 1H 050B-T-A
C20 4030009990 S.CERAMIC C1608 CH 1H 200J-T-A
C21 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C22 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C23 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C24 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C25 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C26 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C27 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C28 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C29 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C30 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C32 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C33 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C34 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C35 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C36 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C37 4550006700 S.TANTALUM ECST1AY106R
C38 4030008880 S.CERAMIC C1608 JB 1C 223K-T-A
C39 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C40 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C41 4030008900 S.CERAMIC C1608 JB 1C 333K-T-A
C42 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C43 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C44 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C45 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C46 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C47 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C48 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C49 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C50 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C52 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C56 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C57 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C58 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C59 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C60 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C61 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C62 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C63 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C64 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C65 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C66 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C67 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C69 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C70 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C71 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C73 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C74 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C77 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C78 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C79 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C80 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C82 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C83 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A E only
C84 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A E only
C85 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A E only
C86 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A E only
C87 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A E only
C88 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A E only
C89 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A E only
C90 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A E only
C92 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A E only
6 - 2
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
C: LCD type (F310/F320), E: LED type (F310S/F320S)

Icom IC-F320 Specifications

General

Brand	Icom
Model	IC-F320
Category	Transceiver
Language	English
