9 - 1
SECTION 9 BOARD LAYOUTS
9-1 FRONT UNIT (IC-F310/F320)
¡¡
TOP VIEW
8V
17
28
AFO
MICE
GND
CLONE
PTT
MIC
HANGER
to Microphone
J1
