Icom IC-F320 Service Manual

[MAIN UNIT][MAIN UNIT]
S.=Surface mount
R194 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R195 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R196 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R197 7030001250 S.RESISTOR MCR50JZHJ 1 kΩ (102)
R198 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R199 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R200 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R201 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R202 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R203 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R204 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R205 7030005650 S.RESISTOR RR0816R-304-D (300 kΩ)
R206 7030005870 S.RESISTOR RR0816R-104-D (100 kΩ)
R207 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R208 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R209 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R210 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R211 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R212 7410000950 S.ARRAY EXB-V8V 102JV
R213 7410000950 S.ARRAY EXB-V8V 102JV
R214 7410000950 S.ARRAY EXB-V8V 102JV
R215 7410000950 S.ARRAY EXB-V8V 102JV
R216 7410000950 S.ARRAY EXB-V8V 102JV
R217 7410000950 S.ARRAY EXB-V8V 102JV
R218 7410000950 S.ARRAY EXB-V8V 102JV
R219 7410000950 S.ARRAY EXB-V8V 102JV
R220 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R221 7030000950 S.RESISTOR MCR18EZHJ 22 Ω (220)
R222 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R223 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R226 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ)
R227 7030003780 S.RESISTOR ERJ3GEYJ 684 V (680 kΩ)
R228 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R229 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R230 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R232 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R233 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R234 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R235 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R236 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R237 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R238 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R240 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R241 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R242 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R243 7030001730 S.RESISTOR MCR18EZHJ 68 Ω (680)
R245 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R246 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
∏
7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω) Ò
R247 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R248 7030005520 S.RESISTOR RR0816R-334-D (330 kΩ)
R249 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R251 7520000170 S.POSISTOR PTH9C32BB471Q-T Ò only
R252 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
Ò only
C1 4030011070 S.CERAMIC GRM42-6 CH 050C 500PT ∏
4030011040 S.CERAMIC GRM42-6 CK 020C 500PT Ò
C3 4030011080 S.CERAMIC GRM42-6 CH 060D 500PT ∏
4030011170 S.CERAMIC GRM42-6 CH 180J 500PT Ò
C4 4030011340 S.CERAMIC C1608 CH 1H 471J-T-A
C5 4030000810 S.CERAMIC GRM40 CK 0R5C 50PT
C7 4030011340 S.CERAMIC C1608 CH 1H 471J-T-A
C8 4030011140 S.CERAMIC GRM42-6 CH 120J 500PT
∏ only
C9 4030011120 S.CERAMIC GRM42-6 CH 100D 500PT
∏ [L-band]
4030011110 S.CERAMIC GRM42-6 CH 090D 500PT
∏ [H-band]
4030011100 S.CERAMIC GRM42-6 CH 080D 500PT Ò
C10 4030011160 S.CERAMIC GRM42-6 CH 150J 500PT ∏
4030011140 S.CERAMIC GRM42-6 CH 120J 500PT Ò
C11 4030011270 S.CERAMIC GRM42-6 CH 200J 500PT ∏
4030011160 S.CERAMIC GRM42-6 CH 150J 500PT Ò
C13 4030011220 S.CERAMIC GRM42-6 CH 360J 500PT
∏ [L-band]
4030011210 S.CERAMIC GRM42-6 CH 330J 500PT
∏ [H-band]
4030011170 S.CERAMIC GRM42-6 CH 180J 500PT Ò
C15 4030011260 S.CERAMIC GRM42-6 W5R 102K 500PT
C16 4030011340 S.CERAMIC C1608 CH 1H 471J-T-A
C17 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C18 4030011340 S.CERAMIC C1608 CH 1H 471J-T-A
C19 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C20 4030011180 S.CERAMIC GRM42-6 CH 220J 500PT
∏ [L-band]
4030011270 S.CERAMIC GRM42-6 CH 200J 500PT
∏ [H-band]
4030011170 S.CERAMIC GRM42-6 CH 180J 500PT Ò
C22 4030011180 S.CERAMIC GRM42-6 CH 220J 500PT
∏ [L-band]
4030011270 S.CERAMIC GRM42-6 CH 200J 500PT
∏ [H-band]
4030011170 S.CERAMIC GRM42-6 CH 180J 500PT Ò
C23 4030007040 S.CERAMIC C1608 CH 1H 180J-T-A
∏ [L-band]
4030006990 S.CERAMIC C1608 CH 1H 080D-T-A
Ò [L-band]
4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
[H-band]
C24 4030008750 S.CERAMIC C1608 CH 1H 360J-T-A
∏ [L-band]
4030007060 S.CERAMIC C1608 CH 1H 270J-T-A
[H-band]
C25 4030007040 S.CERAMIC C1608 CH 1H 180J-T-A
∏ [L-band]
4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
[H-band]
C26 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C27 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C28 4030011340 S.CERAMIC C1608 CH 1H 471J-T-A
C29 4030007040 S.CERAMIC C1608 CH 1H 180J-T-A
Ò [H-band]
4030007050 S.CERAMIC C1608 CH 1H 220J-T-A other
C30 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C31 4030011340 S.CERAMIC C1608 CH 1H 471J-T-A
C32 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C33 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A ∏
4030007040 S.CERAMIC C1608 CH 1H 180J-T-A
Ò [L-band]
4030006990 S.CERAMIC C1608 CH 1H 080D-T-A
Ò [H-band]
C35 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C36 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C37 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C38 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C39 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C40 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C41 4030007040 S.CERAMIC C1608 CH 1H 180J-T-A
C42 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C43 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C44 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C45 4030009920 S.CERAMIC C1608 CH 1H 050B-T-A
C46 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C47 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C48 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T-A
C49 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C50 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C51 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C52 4030009520 S.CERAMIC C1608 CH 1H 020B-T-A
C53 4030009540 S.CERAMIC C1608 CH 1H 1R5B-T-A
C54 4030008360 S.CERAMIC C1608 UJ 1H 101J-T-A
[L-band]
4030008330 S.CERAMIC C1608 UJ 1H 560J-T-A
[H-band]
C55 4030008300 S.CERAMIC C1608 UJ 1H 330J-T-A
C56 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C57 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C58 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C59 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C60 4550006170 S.TANTALUM ECST1AY225R
C61 4550006590 S.TANTALUM ECST1CY684R
C62 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C63 4550006200 S.TANTALUM ECST0JY106
C64 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C65 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C66 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C67 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C68 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C69 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C70 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
6 - 5
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
∏: PMR (F310/F310S), Ò: LMR (F320/F320S)
