Icom IC-F320 Service Manual

[MAIN UNIT][MAIN UNIT]
S.=Surface mount
C217 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C218 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C219 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C220 4510004510 ELECTROLYTIC 25 MV 470 HC
C221 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C222 4030011340 S.CERAMIC C1608 CH 1H 471J-T-A
C223 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C224 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C225 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C226 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C227 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C228 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C229 4550006150 S.TANTALUM ECST1CY105R
C230 4030011810 S.CERAMIC C1608 JB 1A 224K-T-N
C231 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C232 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C233 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C234 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C235 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C236 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C237 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C238 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C240 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C241 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C242 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C243 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C244 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C245 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C246 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C248 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C249 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C250 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C251 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C252 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C253 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C254 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C255 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C256 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C257 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C258 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C259 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C260 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C261 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C262 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C263 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C264 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C265 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C266 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C267 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C268 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C269 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C270 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C271 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C272 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C273 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C274 4030011340 S.CERAMIC C1608 CH 1H 471J-T-A
C275 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C276 4550002830 S.TANTALUM TESVD2 1V 685M-12R
C277 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C278 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C279 4030011340 S.CERAMIC C1608 CH 1H 471J-T-A
C280 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C281 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C282 4550006700 S.TANTALUM ECST1AY106R
C283 4030009970 S.CERAMIC C1608 JB 1H 182K-T-A
C284 4030011330 S.CERAMIC C1608 CH 1H 391J-T-A
C285 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C286 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C287 4030007130 S.CERAMIC C1608 CH 1H 101J-T-A
C288 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C290 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C291 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C292 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C293 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C294 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C295 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C296 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C297 4510004590 ELECTROLYTIC 16 MV 470 HC
C298 4550006200 S.TANTALUM ECST0JY106R
C299 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C301 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
Ò only
J1 6510020510 S.CONNECTOR FH12-40S-0.5SV
J2 6510018430 S.CONNECTOR AXN330C038P
J3 6510019250 S.CONNECTOR B11B-ZR-SM3-TF
J4 6510007080 CONNECTOR PI28A-02M
J5 6450000140 CONNECTOR HSJ0807-01-010
J6 6510014960 S.CONNECTOR B2B-ZR-SM3-TF
W1 7120000470 JUMPER ERDS2T0
W6 7030003860 S.JUMPER ERJ3GE JPW V
W7 8900007960 CABLE OPC-780
∏-[EUR, ITA]
8900004540 CABLE OPC-453 other
EP1 0910049332 PCB B 5043B ∏
0910049860 PCB B 5124 Ò
6 - 7
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
∏: PMR (F310/F310S), Ò: LMR (F320/F320S)
