ii
TABLE OF CONTENTS
IMPORTANT ........................................................................ i
EXPLICIT DEFINITIONS ..................................................... i
CAUTIONS .......................................................................... i
TABLE OF CONTENTS ...................................................... ii
1 PANEL DESCRIPTION ............................................. 1–5
■ Front panel ............................................................................ 1
■ Function display .................................................................... 2
■ Programmable function keys ................................................ 3
2 OPERATION ............................................................. 6–8
■ Turning power ON ................................................................ 6
■ Channel selection ................................................................. 6
■ Receiving and transmitting ................................................... 7
D Transmitting notes .......................................................... 7
D Tx code channel selection .............................................. 8
D Tx code number selection .............................................. 8
D DTMF transmission ........................................................ 8
3 CONNECTION AND MAINTENANCE .................... 9–12
■ Rear panel and connection ................................................... 9
■ Unpacking ........................................................................... 10
■ Mounting the transceiver...................................................... 11
■ Optional UT-96/UT-105 installation ..................................... 11
■ Optional OPC-617 installation ............................................. 12
■ Antenna ............................................................................... 12
■ Fuse replacement ............................................................... 12
■ Cleaning ............................................................................. 12
4 OPTIONAL SmarTrunk II™ OPERATION ........... 13–15
■ SmarTrunk II™ and conventional modes ........................... 13
■ SmarTrunk II™ operation ................................................... 13
5 OPTIONS .................................................................... 16
DO NOT use or place the transceiver in areas with tem-
peratures below –30°C or above +60°C or, in areas subject
to direct sunlight, such as the dashboard.
AVOID operate the transceiver without running the vehi-
cle’s engine. The vehicle’s battery will quickly run out if the
transceiver is in transmission while the vehicle’s engine OFF.
AVOID placing the transceiver in excessively dusty envi-
ronments.
AVOID placing the transceiver against walls. This will ob-
struct heat dissipation.
AVOID the use of chemical agents such as benzine or al-
cohol when cleaning, as they damage the transceiver sur-
faces.
BE CAREFUL! The transceiver will become hot when
operating continuously for long periods.
For U.S.A. only
CAUTION: Changes or modifications to this transceiver, not ex-
pressly approved by Icom Inc., could void your authority to operate
this transceiver under FCC regulations.
