S.=Surface mount
6 - 5
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[PA UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[PA UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
Q701 1560001230 S.FET RD07MVS1 B 22.6/8.3
Q702 1560001240 S.FET RD01MUS1 B 16/8.3
Q704 1530003260 S.TR 2SC5006-T1 T 3.8/10.3
D701 1750000580 S.DIO 1SV307 (TPH3) T 33.9/12.8
D702 1790001670 S.DIO RB706F-40T106 T 28.8/17.8
D703 1790001670 S.DIO RB706F-40T106 B 31.7/13.5
D704 1750000580 S.DIO 1SV307 (TPH3) B 28.4/16.6
D705 1790001240 S.DIO MA2S728-(TX) T 25.9/18.1
D706 1750000580 S.DIO 1SV307 (TPH3) B 30.1/16.6
L701 6200002860 S.COL NL 252018T-4R7J B 34.4/12.4
L702 6200007910 S.COL ELJRF 18NJF2 (18) B 18/12.6
L703 6200008490 S.COL 0.30-0.9-3TR 7.5N T 28/13.7
L704 6200008510 S.COL 0.30-0.9-4TR 10.5N T 24.2/14
L705 6200009760 S.COL 0.30-0.9-9TR T 19.2/13.7
L706 6200003590 S.COL EXCCL3225U1 B 10.7/15.9
L707 6200010990 S.COL ELJRF 47NJF2 (47) T 2.3/11.7
L708 6200008280 S.COL 0.30-1.7-7TL 50N T 32.8/10.5
L709 6200008170 S.COL 0.35-1.6-8TL 54N T 33.5/16.8
L712 6200009290 S.COL LQW18AN47NG00D B 33.2/16.3
R701 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) B 29.7/10.4
R703 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 25.4/16.7
R704 7030007250 S.RES ERJ2GEJ 220 X (22
Ω
) B 19.3/5.2
R705 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 19.1/2.3
R706 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 18.1/2.3
R708 7030005590 S.RES ERJ2GEJ 680 X (68
Ω
) B 12.2/11
R709 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 9.9/11.5
R710 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 9.9/9.9
R715 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 4.9/7.7
R726 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 28.9/14.2
R730 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 3.3/8.7
R732 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 5.8/10.7
R733 7030010040 S.RES ERJ2GE-JPW T 3.2/5.7
R734 7030010040 S.RES ERJ2GE-JPW T 4.2/14.2
R735 7030010040 S.RES ERJ2GE-JPW T 6.4/14.6
R736 7030010040 S.RES ERJ2GE-JPW B 14.2/13.5
R737 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) T 3.2/6.7
R738 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 18/11.6
C701 4030017460 S.CER ECJ0EB1E102K T 35/11
C702 4030017430 S.CER ECJ0EC1H101J B 31.3/10.5
C703 4030017420 S.CER ECJ0EC1H470J B 32.3/10.5
C704 4030017390 S.CER ECJ0EC1H180J B 31.8/9.2
C705 4030007040 S.CER C1608 CH 1H 180J-T T 31.3/14.5
C706 4030007050 S.CER C1608 CH 1H 220J-T T 29.7/14
C707 4030017460 S.CER ECJ0EB1E102K T 26.9/16.6
C708 4030017510 S.CER ECJ0EC1H680J T 27.9/15.2
C711 4030007100 S.CER C1608 CH 1H 560J-T T 26.2/14
C715 4030017420 S.CER ECJ0EC1H470J T 15.7/13.5
C716 4030016790 S.CER ECJ0EB1C103K T 14.7/13.5
C718 4030017460 S.CER ECJ0EB1E102K B 18/5.1
C719 4030017460 S.CER ECJ0EB1E102K T 13.7/13.5
C720 4030017680 S.CER ECJ0EC1H820J B 19/8.4
C722 4030017460 S.CER ECJ0EB1E102K B 12.9/12.9
C723 4030017460 S.CER ECJ0EB1E102K B 10.9/10.4
C724 4030017460 S.CER ECJ0EB1E102K B 8.3/16
C725 4030017460 S.CER ECJ0EB1E102K T 2.3/14.2
C727 4030017420 S.CER ECJ0EC1H470J T 3.8/13
C728 4030017380 S.CER ECJ0EC1H050B T 1.3/11.7
C729 4030017430 S.CER ECJ0EC1H101J B 11.6/12.2
C731 4030017640 S.CER ECJ0EC1H150J T 3.2/7.7
C732 4030017460 S.CER ECJ0EB1E102K T 9.9/19.9
C733 4030017420 S.CER ECJ0EC1H470J T 9.9/20.9
C734 4030018120 S.CER ECJ0EC1H110J T 16.8/2.3
C742 4030017460 S.CER ECJ0EB1E102K T 34.1/14.2
C744 4030017640 S.CER ECJ0EC1H150J T 31.6/16.9
C745 4030017550 S.CER ECJ0EC1H1R5B T 35.7/15.4
C746 4030017410 S.CER ECJ0EC1H240J T 31.3/18.4
C748 4030017420 S.CER ECJ0EC1H470J B 14.2/12.5
C750 4030018120 S.CER ECJ0EC1H110J B 31.8/15.4
C751 4030017390 S.CER ECJ0EC1H180J B 31.5/16.8
C752 4030017460 S.CER ECJ0EB1E102K B 26.7/17.9
C753 4030017460 S.CER ECJ0EB1E102K B 26.9/15.9
C754 4030017460 S.CER ECJ0EB1E102K B 29.9/14.2
C755 4030017420 S.CER ECJ0EC1H470J B 16.7/12.9
C756 4030017420 S.CER ECJ0EC1H470J B 15.7/12.9
C757 4030017460 S.CER ECJ0EB1E102K T 16.7/13.5
C758 4030017420 S.CER ECJ0EC1H470J T 15.8/2.3
C759 4030017460 S.CER ECJ0EB1E102K T 14.8/2.3
C760 4030017460 S.CER ECJ0EB1E102K T 6.1/9.4
C761 4030017460 S.CER ECJ0EB1E102K T 5.2/11.7
C763 4030016790 S.CER ECJ0EB1C103K T 1.3/14.2
C767 4030017460 S.CER ECJ0EB1E102K B 16.7/14.5
C768 4030017520 S.CER ECJ0EC1H0R3B T 29.4/15.8
C769 4030017520 S.CER ECJ0EC1H0R3B B 34.5/16.7
J701 6510024390 S.CNR IMSA-6176S-03Y900 B 6.3/9.7
J702 6910015890 CNR IMSA-9230B-1-02Z140-T
F701 5210000900 S.FUS 0434003.NRP B 10.9/19.6
EP710 0910058452 PCB B 6195B
EP711 6910015370 S.BEA ACZ1005Y-102-T T 1.7/12.9
[ANT UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
L801 6200008580 S.COL 0.30-1.4-6TL 32N T 5.7/12.4
L802 6200008280 S.COL 0.30-1.7-7TL 50N T 6.6/9
R801 7030005080 S.RES ERJ2GEJ 823 X (82 k
Ω
) T 3.2/14.1
C801 4030017460 S.CER ECJ0EB1E102K T 10/7
C802 4030017380 S.CER ECJ0EC1H050B T 6.5/7.1
C803 4030017410 S.CER ECJ0EC1H240J T 3.2/10.6
C807 4030017620 S.CER ECJ0EC1H100C T 4/11.9
EP810 0910058461 PCB B 6196A
[FUSE UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[CHASSIS UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
J1 6910015910 CNR ANT CONNECTOR-104
J2 6910015860 CNR IMSA-6277S-02A-G
SP1 2510001060 SP K036NA500-47
W1 8900009640 CBL OPC-963
L901 6200006190 S.COL BLM21PG300SN1D T 10.2/6
C901 4030017460 S.CER ECJ0EB1E102K T 6/6.6
J901 6910015880 CNR IMSA-9230B-1-02Z141-T
EP910 0910058660 PCB B 6238
