Icom IC-F4261DS User Manual

(Replacement page)
October 2012
7 - 2
[CHASSIS PARTS] [CHASSIS PARTS]
REF ORDER
DESCRIPTION QTY.
NO. NO.
MP2 8210027840 3401 T-FRONT PANEL ASSEMBLY [1] 1
8210027840 3401 T-FRONT PANEL ASSEMBLY [2] 1
8210027840 3401 T-FRONT PANEL ASSEMBLY [3] 1
8210027840 3401 T-FRONT PANEL ASSEMBLY [4] 1
8210027840 3401 T-FRONT PANEL ASSEMBLY [5] 1
8210027840 3401 T-FRONT PANEL ASSEMBLY [6] 1
8210027840 3401 T-FRONT PANEL ASSEMBLY [7] 1
8210027840 3401 T-FRONT PANEL ASSEMBLY [8] 1
8210027900 3401 S-FRONT PANEL ASSEMBLY [9] 1
8210027900 3401 S-FRONT PANEL ASSEMBLY [10] 1
8210027900 3401 S-FRONT PANEL ASSEMBLY [11] 1
8210027900 3401 S-FRONT PANEL ASSEMBLY [12] 1
8210027900 3401 S-FRONT PANEL ASSEMBLY [13] 1
8210027900 3401 S-FRONT PANEL ASSEMBLY [14] 1
8210027900 3401 S-FRONT PANEL ASSEMBLY [15] 1
8210027840 3401 T-FRONT PANEL ASSEMBLY [16] 1
8210027840 3401 T-FRONT PANEL ASSEMBLY [17] 1
8210027900 3401 S-FRONT PANEL ASSEMBLY [18] 1
8210027900 3401 S-FRONT PANEL ASSEMBLY [19] 1
8210027840 3401 T-FRONT PANEL ASSEMBLY [20] 1
8210027840 3401 T-FRONT PANEL ASSEMBLY [21] 1
8210027840 3401 T-FRONT PANEL ASSEMBLY [22] 1
8210027840 3401 T-FRONT PANEL ASSEMBLY [23] 1
8210027840 3401 T-FRONT PANEL ASSEMBLY [24] 1
8210027900 3401 S-FRONT PANEL ASSEMBLY [25] 1
8210027900 3401 S-FRONT PANEL ASSEMBLY [26] 1
8210027900 3401 S-FRONT PANEL ASSEMBLY [27] 1
8210027900 3401 S-FRONT PANEL ASSEMBLY [28] 1
8210027840 3401 T-FRONT PANEL ASSEMBLY [29] 1
8210027840 3401 T-FRONT PANEL ASSEMBLY [30] 1
8210027840 3401 T-FRONT PANEL ASSEMBLY [31] 1
8210027900 3401 S-FRONT PANEL ASSEMBLY [32] 1
8210027900 3401 S-FRONT PANEL ASSEMBLY [33] 1
8210027900 3401 S-FRONT PANEL ASSEMBLY [34] 1
MP3 8210027800 3401 REAR PANEL 1
MP4 8310080040 3401 WINDOW PLATE 1
MP7 8930085060 3401 LENS 1
MP8 8610014190 KNOB N-390 1
MP10 8610014510 KNOB N-405 1
MP12 8930085090 3401 KEYBOARD <SEP> [1] 1
8930085090 3401 KEYBOARD <SEP> [2] 1
8930085090 3401 KEYBOARD <SEP> [3] 1
8930085090 3401 KEYBOARD <SEP> [4] 1
8930085090 3401 KEYBOARD <SEP> [5] 1
8930085090 3401 KEYBOARD <SEP> [6] 1
8930085090 3401 KEYBOARD <SEP> [7] 1
8930085090 3401 KEYBOARD <SEP> [8] 1
8930085290 3401 4-KEY <SEP> [9] 1
8930085290 3401 4-KEY <SEP> [10] 1
8930085290 3401 4-KEY <SEP> [11] 1
8930085290 3401 4-KEY <SEP> [12] 1
8930085290 3401 4-KEY <SEP> [13] 1
8930085290 3401 4-KEY <SEP> [14] 1
8930085290 3401 4-KEY <SEP> [15] 1
8930085090 3401 KEYBOARD <SEP> [16] 1
8930085090 3401 KEYBOARD <SEP> [17] 1
8930085290 3401 4-KEY <SEP> [18] 1
8930085290 3401 4-KEY <SEP> [19] 1
8930085090 3401 KEYBOARD <SEP> [20] 1
8930085090 3401 KEYBOARD <SEP> [21] 1
8930085090 3401 KEYBOARD <SEP> [22] 1
8930085090 3401 KEYBOARD <SEP> [23] 1
8930085090 3401 KEYBOARD <SEP> [24] 1
8930085290 3401 4-KEY <SEP> [25] 1
8930085290 3401 4-KEY <SEP> [26] 1
8930085290 3401 4-KEY <SEP> [27] 1
8930085290 3401 4-KEY <SEP> [28] 1
8930085090 3401 KEYBOARD <SEP> [29] 1
8930085090 3401 KEYBOARD <SEP> [30] 1
8930085090 3401 KEYBOARD <SEP> [31] 1
8930085290 3401 4-KEY <SEP> [32] 1
8930085290 3401 4-KEY <SEP> [33] 1
8930085290 3401 4-KEY <SEP> [34] 1
MP14 8930085410 3401 MAIN SEAL (TOP) 1
MP15 8930059590 O-RING (AV) (TOP) 1
MP16 8930057690 O-RING (AQ) (TOP) 1
MP17 8930063061 2721 T-RUBBER-1 (TOT) 1
MP18 8930084250 2926 RELEASE PLATE Y1255 1
MP19 8930085160 3401 RELEASE BUTTON 1
MP20 8930056540 PUSH SPRING (AH) 2
MP21 8950007340 HCS076M0-H14A250PT (FX3062) CCP 1
MP22 8930085250 3401 14-PIN SHEET 1
MP23 8930075400 3062 CONNECTOR SHEET 1
MP24 8930075410 3062 CONNECTOR SEAL (OON) 1
MP26 8930085000 2926 VENT SHEET 1
MP28 8930085270 3401 SPONGE 1
MP29 8930085400 3401 TOP PLATE 1
MP30 8830001701 VR NUT (Q)-1 2
MP31 8830003440 3285 ANT NUT 1
MP32 8930085150 3401 MIC SEAL TOP 1
MP33 8810008971 BT M2 X3.5 NI-ZC3 6
MP34 8810008971 BT M2 X3.5 NI-ZC3 7
MP35 8810009511 PHBT M2 X 4 NI-ZC3 (3.6-4.0) 4
MP36 8810010430 TRUSS M3 X 5 SUS SSBC 1
MP37 8810009511 PHBT M2 X 4 NI-ZC3 (3.6-4.0) 1
REF ORDER
DESCRIPTION QTY.
NO. NO.
MP38 8810010750 PHBT M2 X 6 SUS SSBC 2
MP39 8810010850 PHBT B0 M2X8 SUS SSBC 2
MP40 8930085800 THERMAL SHEET (CD)TC200TXS (5.9X7.9) 1
MP41 8930085240 3401 WINDOW SHEET 1
MP42 8930084870 3384 REAR SHEET 1
MP43 8930030920 1301 SHEET 1
MP44 8930070010 2893 VOL RUBBER (TOT) 1
MP45 8930083700 DOUBLE SIDE TAPE (BM) [2] 1
8930083700 DOUBLE SIDE TAPE (BM) [3] 1
8930083700 DOUBLE SIDE TAPE (BM) [4] 1
8930083700 DOUBLE SIDE TAPE (BM) [6] 1
8930083700 DOUBLE SIDE TAPE (BM) [7] 1
8930083700 DOUBLE SIDE TAPE (BM) [10] 1
8930083700 DOUBLE SIDE TAPE (BM) [11] 1
8930083700 DOUBLE SIDE TAPE (BM) [12] 1
8930083700 DOUBLE SIDE TAPE (BM) [14] 1
8930083700 DOUBLE SIDE TAPE (BM) [15] 1
8930083700 DOUBLE SIDE TAPE (BM) [17] 1
8930083700 DOUBLE SIDE TAPE (BM) [19] 1
8930083700 DOUBLE SIDE TAPE (BM) [21] 1
8930083700 DOUBLE SIDE TAPE (BM) [23] 1
8930083700 DOUBLE SIDE TAPE (BM) [24] 1
8930083700 DOUBLE SIDE TAPE (BM) [26] 1
8930083700 DOUBLE SIDE TAPE (BM) [27] 1
8930083700 DOUBLE SIDE TAPE (BM) [28] 1
8930083700 DOUBLE SIDE TAPE (BM) [30] 1
8930083700 DOUBLE SIDE TAPE (BM) [31] 1
8930083700 DOUBLE SIDE TAPE (BM) [33] 1
8930083700 DOUBLE SIDE TAPE (BM) [34] 1
MP46 8930085740 3401 GPS SPONGE [2] 1
8930085740 3401 GPS SPONGE [3] 1
8930085740 3401 GPS SPONGE [4] 1
8930085740 3401 GPS SPONGE [6] 1
8930085740 3401 GPS SPONGE [7] 1
8930085740 3401 GPS SPONGE [10] 1
8930085740 3401 GPS SPONGE [11] 1
8930085740 3401 GPS SPONGE [12] 1
8930085740 3401 GPS SPONGE [14] 1
8930085740 3401 GPS SPONGE [15] 1
8930085740 3401 GPS SPONGE [17] 1
8930085740 3401 GPS SPONGE [19] 1
8930085740 3401 GPS SPONGE [21] 1
8930085740 3401 GPS SPONGE [23] 1
8930085740 3401 GPS SPONGE [24] 1
8930085740 3401 GPS SPONGE [26] 1
8930085740 3401 GPS SPONGE [27] 1
8930085740 3401 GPS SPONGE [28] 1
8930085740 3401 GPS SPONGE [30] 1
8930085740 3401 GPS SPONGE [31] 1
8930085740 3401 GPS SPONGE [33] 1
8930085740 3401 GPS SPONGE [34] 1
MP47 8930085730 SHIELD SPONGE (CY) [2] 1
8930085730 SHIELD SPONGE (CY) [3] 1
8930085730 SHIELD SPONGE (CY) [4] 1
8930085730 SHIELD SPONGE (CY) [6] 1
8930085730 SHIELD SPONGE (CY) [7] 1
8930085730 SHIELD SPONGE (CY) [10] 1
8930085730 SHIELD SPONGE (CY) [11] 1
8930085730 SHIELD SPONGE (CY) [12] 1
8930085730 SHIELD SPONGE (CY) [14] 1
8930085730 SHIELD SPONGE (CY) [15] 1
8930085730 SHIELD SPONGE (CY) [17] 1
8930085730 SHIELD SPONGE (CY) [19] 1
8930085730 SHIELD SPONGE (CY) [21] 1
8930085730 SHIELD SPONGE (CY) [23] 1
8930085730 SHIELD SPONGE (CY) [24] 1
8930085730 SHIELD SPONGE (CY) [26] 1
8930085730 SHIELD SPONGE (CY) [27] 1
8930085730 SHIELD SPONGE (CY) [28] 1
8930085730 SHIELD SPONGE (CY) [30] 1
8930085730 SHIELD SPONGE (CY) [31] 1
8930085730 SHIELD SPONGE (CY) [33] 1
8930085730 SHIELD SPONGE (CY) [34] 1
MP49 8810008971 BT M2 X3.5 NI-ZC3 [3] 2
8810008971 BT M2 X3.5 NI-ZC3 [11] 2
8810008971 BT M2 X3.5 NI-ZC3 [16] 2
8810008971 BT M2 X3.5 NI-ZC3 [17] 2
8810008971 BT M2 X3.5 NI-ZC3 [18] 2
8810008971 BT M2 X3.5 NI-ZC3 [19] 2
MP50 8930087660 3402 EARTH PLATE Y1287 [3] 1
8930087660 3402 EARTH PLATE Y1287 [11] 1
8930087660 3402 EARTH PLATE Y1287 [16] 1
8930087660 3402 EARTH PLATE Y1287 [17] 1
8930087660 3402 EARTH PLATE Y1287 [18] 1
8930087660 3402 EARTH PLATE Y1287 [19] 1
*: Refer to “BOARD LAYOUTS” for the location.
**: Refer to “GENERAL WIRING” for the connection
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
