7 - 2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN-A UNIT]
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R27 7030005000 S.RES ERJ2GEJ 471 X (470) B 77.9/40.6
R28 7030010430 S.RES ERJ2GEJ 120 X (12) B 78.5/39.3
R29 7030005570 S.RES ERJ2GEJ 820 X (82) B 73.5/40.6
R30 7030005000 S.RES ERJ2GEJ 471 X (470) B 70.5/40.6
R31 7030004980 S.RES ERJ2GEJ 101 X (100) B 65.8/40.6
R32 7030010040 S.RES ERJ2GEJ-JPW T 68.3/40.2
R33 7030009160 S.RES ERJ2GEJ 181 X (180) T 65.3/29.5
R34 7030005090 S.RES ERJ2GEJ 104 X (100K) T 66.3/27.8
R35 7030004980 S.RES ERJ2GEJ 101 X (100) T 67.3/27.8
R36 7030008410 S.RES ERJ2GEJ 392 X (3.9K) B 57.1/25.7
R37 7030009140 S.RES ERJ2GEJ 272 X (2.7K) T 56.4/19
R38 7030005090 S.RES ERJ2GEJ 104 X (100K) T 59.3/19.2
R39 7030004970 S.RES ERJ2GEJ 470 X (47) B 58.2/22.2
R40 7030005030 S.RES ERJ2GEJ 152 X (1.5K) B 60.4/24.8
R41 7030010040 S.RES ERJ2GEJ-JPW T 60.2/17.8
R42 7030007340 S.RES ERJ2GEJ 153 X (15K) T 50.4/26.1
R43 7030005000 S.RES ERJ2GEJ 471 X (470) T 55.2/19.6
R44 7030005110 S.RES ERJ2GEJ 224 X (220K) T 53.9/26.1
R45 7030005310 S.RES ERJ2GEJ 124 X (120K) T 52.1/26.1
R46 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 53.9/24.3
R48 7030008300 S.RES ERJ2GEJ 184 X (180K) [USA-01] T 56.8/53.2
7030008300 S.RES ERJ2GEJ 184 X (180K) [EXP-02]
7030008300 S.RES ERJ2GEJ 184 X (180K) [CHN-01]
R49 7520000230 S.POS PRF18BD471QB1RB [USA-01] T 42/53.2
7520000230 S.POS PRF18BD471QB1RB [EXP-02]
7520000230 S.POS PRF18BD471QB1RB [CHN-01]
R50 7030005000 S.RES ERJ2GEJ 471 X (470) B 80.7/38
R51 7030008310 S.RES ERJ2GEJ 564 X (560K) T 61.5/52.1
R52 7030007340 S.RES ERJ2GEJ 153 X (15K) T 58.7/52.1
R53 7030004990 S.RES ERJ2GEJ 221 X (220) T 57.8/53.2
R54 7030005050 S.RES ERJ2GEJ 103 X (10K) B 58.8/55.7
R55 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 64.3/51.1
R56 7030005100 S.RES ERJ2GEJ 154 X (150K) T 63.8/54.9
R57 7030005050 S.RES ERJ2GEJ 103 X (10K) B 58.8/54.8
R58 7030005000 S.RES ERJ2GEJ 471 X (470) T 64.7/54.9
R59 7030008290 S.RES ERJ2GEJ 183 X (18K) T 59.7/52.1
R67 7030004980 S.RES ERJ2GEJ 101 X (100) B 83.3/49.1
R68 7030005050 S.RES ERJ2GEJ 103 X (10K) B 81.7/49.1
R69 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 84/38
R70 7030004980 S.RES ERJ2GEJ 101 X (100) B 94/36.2
R71 7030004980 S.RES ERJ2GEJ 101 X (100) B 95.9/34.4
R73 7030004980 S.RES ERJ2GEJ 101 X (100) B 97.7/35.3
R74 7030005310 S.RES ERJ2GEJ 124 X (120K) B 100.7/34.3
R75 7030005110 S.RES ERJ2GEJ 224 X (220K) B 97.7/32.6
R76 7030004980 S.RES ERJ2GEJ 101 X (100) B 97.7/33.5
R77 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 105.6/35.6
R78 7030005120 S.RES ERJ2GEJ 102 X (1K) B 103.1/32.9
R79 7030008340 S.RES RR0510P-182-D (1.8K) B 98.8/25.3
R80 7030005800 S.RES RR0510P-102-D (1K) B 99.7/28.1
R83 7030008340 S.RES RR0510P-182-D (1.8K) B 106.1/30.8
R84 7030011000 S.RES RR0510P-392-D (3.9K) B 103/30.2
R85 7030011000 S.RES RR0510P-392-D (3.9K) B 97.9/28.1
R86 7030005310 S.RES ERJ2GEJ 124 X (120K) B 105.1/25.9
R89 7030005050 S.RES ERJ2GEJ 103 X (10K) T 80/25.1
R90 7030005240 S.RES ERJ2GEJ 473 X (47K) T 95.4/12.9
R91 7030005220 S.RES ERJ2GEJ 223 X (22K) T 93.8/12
R92 7030005090 S.RES ERJ2GEJ 104 X (100K) T 93.8/12.9
R93 7030005120 S.RES ERJ2GEJ 102 X (1K) T 78.8/33.4
R95 7030005120 S.RES ERJ2GEJ 102 X (1K) T 84.2/27.4
R96 7030007570 S.RES ERJ2GEJ 122 X (1.2K) T 82.6/27.4
R97 7030004990 S.RES ERJ2GEJ 221 X (220) T 82.3/28.7
R98 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 109.5/33.8
R100 7030005050 S.RES ERJ2GEJ 103 X (10K) T 78.1/22.2
R101 7030005120 S.RES ERJ2GEJ 102 X (1K) T 79/22.2
R103 7030005100 S.RES ERJ2GEJ 154 X (150K) T 77.9/33.4
R104 7030005080 S.RES ERJ2GEJ 823 X (82K) B 81/21.2
R105 7030008300 S.RES ERJ2GEJ 184 X (180K) B 84.7/21.2
R106 7030005080 S.RES ERJ2GEJ 823 X (82K) B 82.7/20.3
R110 7030005700 S.RES ERJ2GEJ 274 X (270K) B 82.7/21.2
R111 7030007300 S.RES ERJ2GEJ 332 X (3.3K) T 30.5/29.6
R112 7030005240 S.RES ERJ2GEJ 473 X (47K) T 29.6/29.6
R113 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 31.4/29.6
R114 7030008010 S.RES ERJ2GEJ 123 X (12K) T 19.2/21.6
R115 7030008410 S.RES ERJ2GEJ 392 X (3.9K) B 13.4/23.3
R116 7030008010 S.RES ERJ2GEJ 123 X (12K) B 15.1/22.4
R117 7030008300 S.RES ERJ2GEJ 184 X (180K) B 20.7/15.3
R118 7030008010 S.RES ERJ2GEJ 123 X (12K) T 19.2/20.7
R119 7030009290 S.RES ERJ2GEJ 562 X (5.6K) T 18.8/23.5
R120 7030005050 S.RES ERJ2GEJ 103 X (10K) B 16.3/22.8
R121 7030005240 S.RES ERJ2GEJ 473 X (47K) B 15.1/23.3
R122 7030005210 S.RES ERJ2GEJ 822 X (8.2K) T 28.1/24.3
R123 7030005090 S.RES ERJ2GEJ 104 X (100K) B 27.6/22.9
R124 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 28.5/18
R125 7030005090 S.RES ERJ2GEJ 104 X (100K) B 27.6/21.3
R126 7030005000 S.RES ERJ2GEJ 471 X (470) B 27.6/19.6
R127 7030005230 S.RES ERJ2GEJ 334 X (330K) B 25.8/19.6
R128 7030005050 S.RES ERJ2GEJ 103 X (10K) B 26.7/18
R129 7030004980 S.RES ERJ2GEJ 101 X (100) T 30.9/16.2
R130 7030005220 S.RES ERJ2GEJ 223 X (22K) T 29/24.3
R133 7030005090 S.RES ERJ2GEJ 104 X (100K) T 30.8/24.3
R134 7030005060 S.RES ERJ2GEJ 333 X (33K) T 14.6/19.9
R135 7030005700 S.RES ERJ2GEJ 274 X (270K) T 29.9/26
R137 7030005070 S.RES ERJ2GEJ 683 X (68K) T 11.8/16.1
R138 7030005090 S.RES ERJ2GEJ 104 X (100K) B 33.3/12
R139 7030005090 S.RES ERJ2GEJ 104 X (100K) B 33.3/11.1
R142 7410001130 S.ARR EXB28V102JX T 69.7/14.8
R143 7030005120 S.RES ERJ2GEJ 102 X (1K) T 64.8/16.2
R144 7030005120 S.RES ERJ2GEJ 102 X (1K) T 74.3/14.1
R145 7030005120 S.RES ERJ2GEJ 102 X (1K) T 72.9/15.3
R146 7030005120 S.RES ERJ2GEJ 102 X (1K) T 70.1/6.3
R147 7410001130 S.ARR EXB28V102JX T 56.8/6.7
R148 7410001130 S.ARR EXB28V102JX T 61.7/6.1
R149 7410001130 S.ARR EXB28V102JX T 65.8/6.1
R150 7410001130 S.ARR EXB28V102JX T 75.3/6
S.=Surface mount
[MAIN-A UNIT]
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R156 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 116.6/21.9
R159 7030005050 S.RES ERJ2GEJ 103 X (10K) B 117/17.4
R183 7030008300 S.RES ERJ2GEJ 184 X (180K) T 29.9/24.3
R184 7030005060 S.RES ERJ2GEJ 333 X (33K) B 15.1/19.7
R185 7030005310 S.RES ERJ2GEJ 124 X (120K) B 15.1/18.8
R186 7030005090 S.RES ERJ2GEJ 104 X (100K) T 17.1/19.9
R187 7030005050 S.RES ERJ2GEJ 103 X (10K) B 16.8/17.9
R188 7030008370 S.RES ERJ2GEJ 561 X (560) B 16.8/17
R191 7030005110 S.RES ERJ2GEJ 224 X (220K) B 28.8/7.3
R192 7030005110 S.RES ERJ2GEJ 224 X (220K) B 29.8/7.3
R193 7030005170 S.RES ERJ2GEJ 474 X (470K) B 34.2/9.3
R194 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 27.8/5.7
R195 7030005120 S.RES ERJ2GEJ 102 X (1K) B 123.7/17.8
R197 7030005050 S.RES ERJ2GEJ 103 X (10K) B 125.5/16
R198 7030005050 S.RES ERJ2GEJ 103 X (10K) T 128.6/24.1
R199 7030005050 S.RES ERJ2GEJ 103 X (10K) T 133.3/49.2
R200 7030005240 S.RES ERJ2GEJ 473 X (47K) T 114.7/49
R201 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 110.5/46.6
R202 7030000480 S.RES MCR10EZHJ 6.8K (682) B 129.4/48.8
R203 7030000480 S.RES MCR10EZHJ 6.8K (682) B 129.4/47
R204 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 107.7/41.4
R205 7030005050 S.RES ERJ2GEJ 103 X (10K) T 107.7/42.3
R209 7510001730 S.THE ERTJOEP 473J T 77.4/15.3
R210 7030008270 S.RES RR0510P-104-D (100K) T 75.4/15.3
R211 7030004970 S.RES ERJ2GEJ 470 X (47) T 82.6/30.5
R212 7030004980 S.RES ERJ2GEJ 101 X (100) T 83.1/61.1
R213 7030005050 S.RES ERJ2GEJ 103 X (10K) T 84.1/61.1
R215 7030005000 S.RES ERJ2GEJ 471 X (470) B 37.4/30
R218 7030005220 S.RES ERJ2GEJ 223 X (22K) T 60.9/19.2
R220 7030005050 S.RES ERJ2GEJ 103 X (10K) B 79.4/19.4
R221 7030010040 S.RES ERJ2GEJ-JPW B 84.7/22.1
R222 7030005240 S.RES ERJ2GEJ 473 X (47K) B 81/20.3
R223 7030005120 S.RES ERJ2GEJ 102 X (1K) B 116.7/10.8
R224 7030004970 S.RES ERJ2GEJ 470 X (47) B 114.5/15.1
R225 7030010040 S.RES ERJ2GEJ-JPW B 111.6/13.1
R226 7030005090 S.RES ERJ2GEJ 104 X (100K) B 116.7/13.1
R227 7030005160 S.RES ERJ2GEJ 105 X (1M) T 111.2/12.9
R228 7030005090 S.RES ERJ2GEJ 104 X (100K) B 115.4/15.1
R229 7030005160 S.RES ERJ2GEJ 105 X (1M) B 116.7/14
R230 7030005090 S.RES ERJ2GEJ 104 X (100K) T 95.4/12
R231 7030005120 S.RES ERJ2GEJ 102 X (1K) B 37.9/21.1
R232 7030005170 S.RES ERJ2GEJ 474 X (470K) B 35.4/8.9
R234 7030005050 S.RES ERJ2GEJ 103 X (10K) B 94/35.3
R235 7030005050 S.RES ERJ2GEJ 103 X (10K) B 81.6/38
R236 7030007570 S.RES ERJ2GEJ 122 X (1.2K) B 67.1/21.5
R237 7030007060 S.RES ERJ2GEJ 684X (680K) B 67.1/23.3
R238 7030005090 S.RES ERJ2GEJ 104 X (100K) T 113.7/28.4
R240 7030005090 S.RES ERJ2GEJ 104 X (100K) B 25.8/22.9
R241 7030005090 S.RES ERJ2GEJ 104 X (100K) B 26.7/24.6
R242 7030007350 S.RES ERJ2GEJ 393 X (39K) B 25.8/24.6
R243 7030005080 S.RES ERJ2GEJ 823 X (82K) B 24.9/22.9
R244 7030006610 S.RES ERJ2GEJ 394 X (390K) B 24/24.6
R245 7030008300 S.RES ERJ2GEJ 184 X (180K) B 23.1/24.6
R247 7030005220 S.RES ERJ2GEJ 223 X (22K) T 29.7/17.3
R248 7030005220 S.RES ERJ2GEJ 223 X (22K) T 29.1/19.5
R249 7030005220 S.RES ERJ2GEJ 223 X (22K) T 27.5/19.5
R250 7030005050 S.RES ERJ2GEJ 103 X (10K) T 26.2/21.6
R251 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 24.9/21.6
R252 7030005090 S.RES ERJ2GEJ 104 X (100K) T 25.2/17.7
R253 7030005240 S.RES ERJ2GEJ 473 X (47K) T 22.9/19.5
R254 7030008370 S.RES ERJ2GEJ 561 X (560) T 22.9/20.4
R255 7030005050 S.RES ERJ2GEJ 103 X (10K) T 27.5/20.4
R256 7030005050 S.RES ERJ2GEJ 103 X (10K) T 29.1/20.4
R261 7030005160 S.RES ERJ2GEJ 105 X (1M) T 23.8/13.4
R262 7030005160 S.RES ERJ2GEJ 105 X (1M) T 24.7/13.4
R263 7030005160 S.RES ERJ2GEJ 105 X (1M) T 25.6/13.4
R269 7030005090 S.RES ERJ2GEJ 104 X (100K) B 25.7/8.4
R270 7030005090 S.RES ERJ2GEJ 104 X (100K) B 26.8/8.4
R271 7030004980 S.RES ERJ2GEJ 101 X (100) T 16.8/12.8
R285 7030004980 S.RES ERJ2GEJ 101 X (100) T 14.6/18.1
R287 7030005050 S.RES ERJ2GEJ 103 X (10K) B 117.5/20.2
R290 7030005010 S.RES ERJ2GEJ 681 X (680) T 66.3/26
R291 7030005090 S.RES ERJ2GEJ 104 X (100K) T 93.8/13.8
R297 7030005651 S.RES ERA3YKD 304V (300K) B 72.5/9.4
R298 7030008270 S.RES RR0510P-104-D (100K) B 73.9/10.4
R299 7030008300 S.RES ERJ2GEJ 184 X (180K) B 74.6/38.5
R300 7030005720 S.RES ERJ2GEJ 563 X (56K) B 76.8/40.6
R301 7030005100 S.RES ERJ2GEJ 154 X (150K) B 66.7/40.6
R302 7030005720 S.RES ERJ2GEJ 563 X (56K) B 66.3/38
R304 7030005050 S.RES ERJ2GEJ 103 X (10K) B 31.9/9.8
R310 7030005050 S.RES ERJ2GEJ 103 X (10K) B 95.4/35.7
R311 7030004990 S.RES ERJ2GEJ 221 X (220) B 96.3/33.2
R313 7030005160 S.RES ERJ2GEJ 105 X (1M) T 32/6.8
R314 7030005090 S.RES ERJ2GEJ 104 X (100K) T 11.8/9.3
R315 7030005090 S.RES ERJ2GEJ 104 X (100K) T 11.8/10.3
R316 7030005120 S.RES ERJ2GEJ 102 X (1K) T 105.6/36.5
R317 7030005120 S.RES ERJ2GEJ 102 X (1K) T 105.6/37.4
R319 7030005050 S.RES ERJ2GEJ 103 X (10K) T 37.3/37.9
R320 7030005170 S.RES ERJ2GEJ 474 X (470K) T 35.5/36.2
R322 7030005090 S.RES ERJ2GEJ 104 X (100K) B 30.3/8.9
R323 7030005050 S.RES ERJ2GEJ 103 X (10K) T 107.3/35.6
R325 7030005120 S.RES ERJ2GEJ 102 X (1K) T 63.8/16.2
R326 7030005120 S.RES ERJ2GEJ 102 X (1K) B 61.7/12.3
R327 7030005120 S.RES ERJ2GEJ 102 X (1K) T 54.6/8.3
R328 7030010040 S.RES ERJ2GEJ-JPW B 104.9/30.8
R329 7030000480 S.RES MCR10EZHJ 6.8K (682) B 129.4/45.2
R330 7030009290 S.RES ERJ2GEJ 562 X (5.6K) B 13.4/20.6
R332 7030010040 S.RES ERJ2GEJ-JPW T 90.3/61.6
R333 7030010090 S.RES ERJ2GEJ 180 X (18) T 89.4/63.7
R334 7030008280 S.RES ERJ2GEJ 271 X (270) T 90.7/63.2
R336 7030005060 S.RES ERJ2GEJ 333 X (33K) T 14.6/17.2
R337 7030010040 S.RES ERJ2GEJ-JPW T 84.1/63.7
R338 7030008280 S.RES ERJ2GEJ 271 X (270) T 90.7/64.1
R339 7030010040 S.RES ERJ2GEJ-JPW B 98.4/26.7
To Next Page
Loading...
Need help?
General
