7 - 6
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[FRONT UNIT]
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R127 7030005160 S.RES ERJ2GEJ 105 X (1M) B 78/28.5
R128 7030005050 S.RES ERJ2GEJ 103 X (10K) B 30.9/25.2
C1 4030018100 S.CER ECJ0EB1H681K B 42.2/15.2
C2 4030017420 S.CER ECJ0EC1H470J B 84/7.7
C3 4030017420 S.CER ECJ0EC1H470J B 28.5/6.1
C4 4030017420 S.CER ECJ0EC1H470J B 47.2/5
C5 4030017420 S.CER ECJ0EC1H470J B 56.4/5.5
C6 4030017420 S.CER ECJ0EC1H470J B 81/27.6
C7 4030017420 S.CER ECJ0EC1H470J B 16.5/11.6
C8 4030017460 S.CER ECJ0EB1E102K B 13.7/17.1
C9 4030017460 S.CER ECJ0EB1E102K T 11.3/17.1
C10 4030017460 S.CER ECJ0EB1E102K T 20.3/13.1
C11 4030017420 S.CER ECJ0EC1H470J T 7.3/17.1
C12 4030017460 S.CER ECJ0EB1E102K T 18.3/13.1
C14 4030017460 S.CER ECJ0EB1E102K B 29.2/28.8
C15 4030016780 S.CER ECJ0EB1C153K B 29.2/27.9
C16 4030016930 S.CER ECJ0EB1A104K B 29.2/26.1
C17 4030017740 S.CER ECJ0EB1E821K B 26.9/28.8
C19 4030016930 S.CER ECJ0EB1A104K B 32.6/27
C20 4030017460 S.CER ECJ0EB1E102K B 30.9/19.7
C21 4030017460 S.CER ECJ0EB1E102K B 29.2/20.6
C22 4030018140 S.CER ECJ0EB1H391K B 26.2/18.3
C23 4030016790 S.CER ECJ0EB1C103K B 29.2/24.2
C24 4030017420 S.CER ECJ0EC1H470J B 24.4/18.3
C25 4030016790 S.CER ECJ0EB1C103K B 21.8/28.8
C26 4030016930 S.CER ECJ0EB1A104K B 20.1/27
C27 4030017450 S.CER ECJ0EB1E271K B 21.8/27.9
C28 4030016930 S.CER ECJ0EB1A104K B 25.3/18.3
C29 4550006050 S.TAN TEESVA 0J 106M8R B 25.5/16.1
C31 4030016930 S.CER ECJ0EB1A104K B 33.4/4.2
C34 4030017420 S.CER ECJ0EC1H470J B 56.4/4.5
C36 4030016930 S.CER ECJ0EB1A104K B 85.8/16.8
C37 4030017420 S.CER ECJ0EC1H470J B 85.6/20.1
C38 4030017420 S.CER ECJ0EC1H470J B 78.8/9.3
C41 4030017460 S.CER ECJ0EB1E102K B 20.1/28.8
C50 4030017420 S.CER ECJ0EC1H470J B 62.1/9.3
C54 4030017420 S.CER ECJ0EC1H470J B 63/9.3
C69 4030017420 S.CER ECJ0EC1H470J B 67.4/1.7
C74 4030017420 S.CER ECJ0EC1H470J B 61.7/1.7
C75 4030016930 S.CER ECJ0EB1A104K B 46.1/14.6
C76 4030016930 S.CER ECJ0EB1A104K B 25.2/28.8
C77 4030016950 S.CER ECJ0EB1A473K B 71.6/10.9
C78 4030017460 S.CER ECJ0EB1E102K B 8.9/17.1
C79 4030016930 S.CER ECJ0EB1A104K B 47.9/14.6
C80 4030016930 S.CER ECJ0EB1A104K B 43.4/14.6
C81 4030017460 S.CER ECJ0EB1E102K T 9.2/17.1
C82 4030017420 S.CER ECJ0EC1H470J B 33.1/26.1
C83 4030017420 S.CER ECJ0EC1H470J B 23.5/18.3
C84 4030017420 S.CER ECJ0EC1H470J B 21.8/26.1
C85 4030017420 S.CER ECJ0EC1H470J B 29.2/19.7
C87 4030016930 S.CER ECJ0EB1A104K B 30.9/18
C93 4030017460 S.CER ECJ0EB1E102K B 56.9/9.2
C101 4030016930 S.CER ECJ0EB1A104K B 76.1/13.3
C102 4030016930 S.CER ECJ0EB1A104K B 77.4/11.8
C103 4030016930 S.CER ECJ0EB1A104K B 75.2/13.3
C104 4030017400 S.CER ECJ0EC1H220J B 78.8/15.4
C105 4030017600 S.CER ECJ0EC1H080C B 77.4/16.7
C106 4030017640 S.CER ECJ0EC1H150J B 77.4/17.6
C107 4030017030 S.CER ECJ0EB1A273K B 91.3/18.5
C111 4030016930 S.CER ECJ0EB1A104K B 86.7/20.1
C112 4550006780 S.TAN TEESVB2 0J 476M8R B 56.2/16.8
C113 4030018910 S.CER C1608 JB 0J 475K-T B 78/18.9
C114 4030017420 S.CER ECJ0EC1H470J B 56.9/10.1
C115 4030016930 S.CER ECJ0EB1A104K B 75.8/18.9
C116 4030016930 S.CER ECJ0EB1A104K B 78/20
C117 4030016930 S.CER ECJ0EB1A104K B 78/20.9
C118 4030016930 S.CER ECJ0EB1A104K B 78/24.9
C119 4030016930 S.CER ECJ0EB1A104K B 78/23.1
C120 4030016930 S.CER ECJ0EB1A104K B 78/24
C123 4030017460 S.CER ECJ0EB1E102K B 76.2/29.4
C124 4030016930 S.CER ECJ0EB1A104K B 59.7/28.6
C125 4030016930 S.CER ECJ0EB1A104K B 53.8/5
C126 4030017460 S.CER ECJ0EB1E102K B 25.2/4.2
C128 4030016930 S.CER ECJ0EB1A104K T 14.6/19.3
C129 4030017460 S.CER ECJ0EB1E102K T 13.7/19.3
C130 4030017460 S.CER ECJ0EB1E102K B 85.7/8.6
C131 4030018860 S.CER ECJ0EB0J105K B 32.6/25.2
J1 6450002210 CON 3017-8821 <KIN>
J2 6510022472 S.CON 40FLT-SM2-TB(LF)(SN)(M) B 70.9/5.7
J3 6510022022 S.CON 14FLT-SM2-TB(LF)(SN)(M) B 51.8/28.5
DS1 5040002310 S.LED SML-311YTT86 T 64.8/23.5
DS2 5040002310 S.LED SML-311YTT86 T 58.2/23.5
DS3 5040002310 S.LED SML-311YTT86 T 51.6/23.5
DS4 5040002310 S.LED SML-311YTT86 T 31.8/23.5
DS5 5040002310 S.LED SML-311YTT86 T 38.4/23.5
DS6 5040002310 S.LED SML-311YTT86 T 45/23.5
DS7 5040002310 S.LED SML-311YTT86 T 82.5/22.1
DS8 5040002310 S.LED SML-311YTT86 T 65.2/5
DS9 5040002310 S.LED SML-311YTT86 T 36.2/5
DS11 5030003200 LCD A01B011X 3179 LCD
W1 8900010503 CAB OPC-1046B-1(P0.5,N40,L55)
<TJM>
EP2 8930059170 LCD SRCN-2622-SP-N-W (SHJ)
S.=Surface mount
