Icom IC-F5220D

7-7
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[FRONT UNIT]
R784 7030005240 S.RES ERJ2GEJ 473 X (47K) B 26.5/18.8
R785 7030005240 S.RES ERJ2GEJ 473 X (47K) B 30.8/19.3
R786 7030010040 S.RES ERJ2GEJ-JPW B 74.6/29.4
R787 7030005050 S.RES ERJ2GEJ 103 X (10K) B 84.3/11.0
C2 4030017420 S.CER C1005 CH 1H 470J-T B 84.0/7.7
C3 4030017420 S.CER C1005 CH 1H 470J-T B 28.5/6.1
C4 4030017420 S.CER C1005 CH 1H 470J-T B 47.2/5.0
C5 4030017420 S.CER C1005 CH 1H 470J-T B 56.3/4.6
C8 4030017460 S.CER C1005 JB 1H 102K-T B 13.7/17.1
C9 4030017460 S.CER C1005 JB 1H 102K-T T 11.3/17.1
C10 4030017460 S.CER C1005 JB 1H 102K-T T 20.3/13.1
C12 4030017460 S.CER C1005 JB 1H 102K-T T 18.3/13.1
C25 4030016790 S.CER C1005 JB 1E 103K-T B 26.9/28.9
C26 4030016930 S.CER C1005 JB 1A 104K-T B 23.0/26.4
C27 4030018010 S.CER C1005 CH 1H 360J-T B 25.0/27.1
C28 4030016930 S.CER C1005 JB 1A 104K-T B 30.6/27.1
C31 4030016930 S.CER C1005 JB 1A 104K-T B 33.4/4.2
C34 4030017420 S.CER C1005 CH 1H 470J-T B 56.3/5.5
C41 4030017460 S.CER C1005 JB 1H 102K-T B 25.0/29.0
C50 4030017420 S.CER C1005 CH 1H 470J-T B 61.6/8.6
C75 4030016930 S.CER C1005 JB 1A 104K-T B 42.3/27.2
C76 4030016930 S.CER C1005 JB 1A 104K-T B 28.8/28.9
C78 4030017460 S.CER C1005 JB 1H 102K-T B 8.9/17.1
C84 4030017420 S.CER C1005 CH 1H 470J-T B 29.9/2.9
C87 4030016930 S.CER C1005 JB 1A 104K-T B 30.9/18.0
C93 4030017460 S.CER C1005 JB 1H 102K-T B 56.3/7.9
C114 4030017420 S.CER C1005 CH 1H 470J-T B 19.7/10.6
C126 4030017460 S.CER C1005 JB 1H 102K-T B 25.2/4.2
C128 4030016930 S.CER C1005 JB 1A 104K-T T 14.6/19.3
C129 4030017460 S.CER C1005 JB 1H 102K-T T 13.7/19.3
C130 4030017460 S.CER C1005 JB 1H 102K-T B 85.7/8.6
C131 4030017460 S.CER C1005 JB 1H 102K-T B 86.9/21.0
C132 4030017460 S.CER C1005 JB 1H 102K-T B 86.2/26.9
C626 4030017640 S.CER C1005 CH 1H 150J-T B 81.1/19.6
C627 4030017580 S.CER C1005 CH 1H 060C-T B 80.1/17.2
C628 4030017640 S.CER C1005 CH 1H 150J-T B 81.0/17.2
C629 4030016930 S.CER C1005 JB 1A 104K-T B 79.1/15.0
C630 4030016930 S.CER C1005 JB 1A 104K-T B 82.6/12.0
C631 4030016930 S.CER C1005 JB 1A 104K-T B 56.1/29.6
C797 4030016930 S.CER C1005 JB 1A 104K-T B 75.6/21.5
C799 4030016930 S.CER C1005 JB 1A 104K-T B 77.2/22.4
C800 4030016930 S.CER C1005 JB 1A 104K-T B 77.2/21.2
C802 4030016930 S.CER C1005 JB 1A 104K-T B 69.1/9.7
C803 4030019990 S.CER C1005 JB 1C 104K-T B 49.7/24.9
C804 4030017460 S.CER C1005 JB 1H 102K-T B 26.6/22.1
C805 4030018900 S.CER C1005 JB 0J 474K-T B 65.3/29.3
C806 4550008240 S.TAN F930G476MAA B 43.4/6.5
C807 4030016930 S.CER C1005 JB 1A 104K-T B 75.4/20.4
C808 4030016930 S.CER C1005 JB 1A 104K-T B 78.8/17.1
C809 4030016930 S.CER C1005 JB 1A 104K-T B 88.6/15.1
C810 4030016930 S.CER C1005 JB 1A 104K-T B 25.0/28.1
C811 4030017460 S.CER C1005 JB 1H 102K-T B 31.5/8.0
J1 6450002210 CON 3017-8821 <KIN>
J2 6510027960 S.CON 04-6294-040-000-800 B 71.0/5.7
DS1 5040003510 S.LED LNJ426W83RA T 64.8/23.5
DS2 5040003510 S.LED LNJ426W83RA T 58.2/23.5
DS3 5040003510 S.LED LNJ426W83RA T 51.6/23.5
DS4 5040003510 S.LED LNJ426W83RA T 31.8/23.5
DS5 5040003510 S.LED LNJ426W83RA T 38.4/23.5
DS6 5040003510 S.LED LNJ426W83RA T 45.0/23.5
DS7 5040003510 S.LED LNJ426W83RA T 82.6/22.1
DS8 5040003510 S.LED LNJ426W83RA T 65.3/5.0
DS9 5040003510 S.LED LNJ426W83RA T 36.3/5.0
DS11 5030003390 LCD TAK-35877 FX-3331<ITAK>
W1 8900010503 CAB OPC-1046B-1(P0.5N40L55)
<TJM>
EP2 8930059170 LCD SRCN-2622-SP-N-W (SHJ)
