5 - 4
: Transceiver's connection state
: Reload adjustment data
:
Receive sensitivity measurement
: Connected DC voltage
NOTE:
1
5
4
6
10
11
12
15
9
14
1
2
3
4
9
10
: PLL lock voltage
:
Operating channel select
: RF output power
: Modulation balance
5
6
7
8
11
12
: FM deviation
:
CTCSS/DTCS deviation
: Squelch level
: Receive sensitivity
(automatically)
13
:
Receive sensitivity (manually)
: Reference frequency
: S-meter
: LSD calibration
14
15
16
The above values for settings are example only.
Each transceiver has its own specific values for each setting.
3
2
8
7
13
16
• CS-F620TR ADJ'S SCREEN EXAMPLE
To Next Page
