S.=Surface mount
6 - 2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
Q24 1590000430 S.TR DTC144EUA T106 T 16.7/68.3
Q25 1540000550 S.TR 2SD1664 T100Q B 26.2/58.6
Q26 1540000550 S.TR 2SD1664 T100Q B 31.2/58.6
Q27 1520000460 S.TR 2SB1132 T100 R B 36.2/58.6
Q28 1590001190 S.TR XP6501-(TX) .AB B 39.2/61.9
Q29 1590000430 S.TR DTC144EUA T106 T 26.5/56.9
Q30 1590000430 S.TR DTC144EUA T106 T 34.7/56.3
Q31 1590001450 S.FET 2SJ144-GR (TE85R) B 13.7/28.7
Q32 1590000430 S.TR DTC144EUA T106 B 11.4/16.6
Q33 1590000430 S.TR DTC144EUA T106 B 11.1/13.9
Q34 1530002850 S.TR 2SC4116-BL (TE85R) T 100.7/41.7
Q35 1590001400 S.TR XP1214 (TX) T 84.7/27.1
Q36 1530002850 S.TR 2SC4116-BL (TE85R) T 113.5/37.4
Q37 1530002850 S.TR 2SC4116-BL (TE85R) T 89.4/15.8
Q38 1590000430 S.TR DTC144EUA T106 T 92/18.2
Q39 1590000990 S.TR DTC363EK T146 B 12/56.2
Q40 1590000430 S.TR DTC144EUA T106 B 12.9/50.6
Q41 1590000720 S.TR DTA144EUA T106 T 40.6/43.4
Q42 1590000430 S.TR DTC144EUA T106 T 37.9/45.2
Q43 1590000430 S.TR DTC144EUA T106 B 85.8/7.2
Q44 1590000430 S.TR DTC144EUA T106 T 46.8/27.1
Q48 1590000430 S.TR DTC144EUA T106 B 3.5/18.6
Q49 1590000430 S.TR DTC144EUA T106 B 90.3/26.5
Q50 1590000430 S.TR DTC144EUA T106 B 87.1/19.8
Q51 1530002850 S.TR 2SC4116-BL (TE85R) [45W] only T 61/61.5
D1 1790000660 S.DIO MA728 (TX) B 113.6/88.8
D2 1750000510 S.DIO UM9401F [25W] only T 100/69.7
D3 1710001060 DIO XB15A407 [45W] only
D4 1750000710 S.VCP HVC350BTRF B 91.2/56.9
D5 1750000510 S.DIO UM9401F T 95.7/65.6
D6 1790000620 S.DIO MA77 (TX) T 88/63.8
D8 1750000710 S.VCP HVC350BTRF B 94.7/59.4
D9 1750000710 S.VCP HVC350BTRF B 85.9/57.3
D10 1750000710 S.VCP HVC350BTRF B 83.5/56.1
D11 1790000660 S.DIO MA728 (TX) B 108.6/74
D14 1790000620 S.DIO MA77 (TX) B 57.9/57.8
D15 1790000620 S.DIO MA77 (TX) B 61.9/48.2
D16 1750000710 S.VCP HVC350BTRF T 73.9/32.7
D17 1750000710 S.VCP HVC350BTRF T 59.4/32.7
D18 1720000570 S.VCP MA368 (TX) B 63.1/37.4
D19 1790001250 S.DIO MA2S111-(TX) B 55.8/50.4
D20 1790001250 S.DIO MA2S111-(TX) B 94.3/37
D21 1750000830 S.VCP HVC362TRF B 104.2/37.8
D22 1790000700 DIO DSA3A1
D23 1750000370 S.DIO DA221 TL B 26.2/63.4
D24 1750000370 S.DIO DA221 TL B 31.2/63.4
D25 1790001250 S.DIO MA2S111-(TX) T 94.5/53.5
D26 1790001250 S.DIO MA2S111-(TX) B 11.9/30.6
D27 1790000620 S.DIO MA77 (TX) T 49.4/38.9
D28 1750000520 S.DIO DAN222TL T 34.1/41.8
D30 1790001250 S.DIO MA2S111-(TX) B 13.1/53.3
D31 1750000520 S.DIO DAN222TL B 13.5/47.5
D32 1790001250 S.DIO MA2S111-(TX) T 57.5/72.4
D33 1790001250 S.DIO MA2S111-(TX) T 60.3/63.4
D34 1790001250 S.DIO MA2S111-(TX) T 49.8/8.2
D35 1750000520 S.DIO DAN222TL T 44.4/27.1
D36 1750000520 S.DIO DAN222TL T 36.8/18.6
D37 1750000520 S.DIO DAN222TL T 36.9/20.8
FI1 2010002450 S.XTL FL-313 (46.35 MHz) [USA], [GEN] T 86.2/46.6
2030000150 S.MLH FL-335 (46.350 MHz) [EUR] T 86.2/46.6
FI2 2020001840 CER ALFYM450F=K
FI3 2040001440 S.LC NFE31PT152Z1E9L B 65.3/70
FI4 2040001440 S.LC NFE31PT152Z1E9L B 65.3/66.7
FI5 2040001440 S.LC NFE31PT152Z1E9L [45W] only B 65.3/63.4
X1 6070000190 S.DCR CDBCB450KCAY24-R0 T 104.1/57.4
X2 6050011120 S.XTL CR-671A (15.300 MHz) B 98.6/37.5
X3 6050009910 S.XTL CR-563 (3.579545 MHz) T 108.7/10.9
X4 6050009520 S.XTL CR-520 (19.6608 MHz) T 44.1/34.4
L1 6110001520 COL LA-232 [25W]
6110002110 COL LA-382 [45W]
L2 6110001520 COL LA-232
L3 6110002110 COL LA-382
L4 6200008330 S.COL 0.45-1.4-4TL 15N T 99.6/66.6
L5 6170000230 COL LW-25
L6 6200008330 S.COL 0.45-1.4-4TL 15N T 92.7/64.9
L7 6200007230 S.COL LQW2BHN15NJ01L [L] T 96.1/59
6200007670 S.COL LQW2BHN10NJ01L [M], [H] T 96.1/59
L8 6200007670 S.COL LQW2BHN10NJ01L [M], [H] T 93.5/57.6
6200007680 S.COL LQW2BHN12NJ01L [L] T 93.5/57.6
L9 6200007670 S.COL LQW2BHN10NJ01L [M], [H] T 86.1/55
6200007680 S.COL LQW2BHN12NJ01L [L] T 86.1/55
L11 6200007670 S.COL LQW2BHN10NJ01L [M], [H] T 82.4/55
6200007680 S.COL LQW2BHN12NJ01L [L] T 82.4/55
L12 6200005700 S.COL ELJRE 22NG-F [EUR-M] B 77.7/55.2
6200005720 S.COL ELJRE 33NG-F except [EUR-M] B 77.7/55.2
L13 6200003350 S.COL ELJNC R27K-F B 81.2/49.7
L16 6110001520 COL LA-232 [25W]
6110002110 COL LA-382 [45W]
L18 6200005680 S.COL ELJRE 15NG-F [M], [H] T 40.3/67.5
6200005690 S.COL ELJRE 18NG-F [L] T 40.3/67.5
L19 6200005680 S.COL ELJRE 15NG-F [M], [H] B 46.5/59.9
6200005690 S.COL ELJRE 18NG-F [L] B 46.5/59.9
L20 6200005700 S.COL ELJRE 22NG-F [M], [H] B 51.8/60.1
6200005710 S.COL ELJRE 27NG-F [L] B 51.8/60.1
L21 6200005700 S.COL ELJRE 22NG-F [M], [H] T 58.7/44.7
6200005710 S.COL ELJRE 27NG-F [L] T 58.7/44.7
L22 6200005710 S.COL ELJRE 27NG-F T 72.3/47.3
L23 6200004950 S.COL NL 252018T-1R8J B 63/39.7
L24 6200004950 S.COL NL 252018T-1R8J B 71.3/40.7
L25 6200009360 S.COL 0.45-1.4-3TL 11N T 67.9/36.1
L26 6200009360 S.COL 0.45-1.4-3TL 11N T 65.2/33.2
L27 6200004950 S.COL NL 252018T-1R8J B 70.4/32.7
L28 6200004950 S.COL NL 252018T-1R8J B 62.9/32.7
L29 6200004950 S.COL NL 252018T-1R8J T 84.6/34.6
L31 6200007740 S.COL LQW2BHN47NJ01L B 94.8/65
L32 6200005680 S.COL ELJRE 15NG-F [M], [H] B 75.5/42.8
6200005690 S.COL ELJRE 18NG-F [L] B 75.5/42.8
L33 6200002850 S.COL NL 252018T-R82J T 105.3/44.1
L35 6200002840 S.COL NL 252018T-R22J T 97.8/43.2
L36 6200002860 S.COL NL 252018T-4R7J T 49.2/46
L37 6200006980 S.COL ELJRE R10G-F T 46.6/71.2
L38 6200005690 S.COL ELJRE 18NG-F B 71/48.6
L39 6200007720 S.COL LQW2BHN33NJ01L [EUR] only B 99/59.8
R1 7030000620 S.RES MCR10EZHJ 100 k
Ω
B 107.3/98.2
R2 7030000260 S.RES MCR10EZHJ 100
Ω
(101) B 102.5/87.9
R3 7030000220 S.RES MCR10EZHJ 47
Ω
(470) [25W] B 119.5/75.1
7030000280 S.RES MCR10EZHJ 150
Ω
(151) [45W] B 119.5/75.1
R4 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 111.5/89.8
R5 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 115.7/89.8
R6 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 106.5/73
R7 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) [25W] B 110.7/73
7030003340 S.RES ERJ3GEYJ 151 V (150
Ω
) [45W] B 110.7/73
R8 7030001170 S.RES MCR50JZHJ 220
Ω
(221) B 83.5/67.1
R9 7030001170 S.RES MCR50JZHJ 220
Ω
(221) B 83.5/64.1
R10 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k
Ω
) T 93.2/53.3
R11 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) B 93.4/59.3
R12 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 91.5/61.1
R13 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) B 89.9/56.9
R14 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 88.8/59.6
R15 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) B 93.1/53.5
R16 7030003340 S.RES ERJ3GEYJ 151 V (150
Ω
) B 87.8/55
R17 7030004050 S.RES ERJ3GEYJ 1R0 V (1
Ω
) B 87.7/52.3
R18 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 89.2/50.7
R19 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) B 92.3/51.6
R20 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 84.4/55
R21 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) B 84.6/58
R22 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 83.8/59.9
R23 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) B 83.3/58
R24 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 80.1/58.8
R25 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 80.8/54.7
R29 7030003330 S.RES ERJ3GEYJ 121 V (120
Ω
) [W/N] B 75.8/51.7
7030003360 S.RES ERJ3GEYJ 221 V (220
Ω
) [M/N] B 75.8/51.7
R30 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 81.6/47.8
R31 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 84.6/51.4
R32 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 80.5/48.2
R33 7030003340 S.RES ERJ3GEYJ 151 V (150
Ω
) B 89.7/45.9
R34 7030003690 S.RES ERJ3GEYJ 124 V (120 k
Ω
) B 94.2/46.7
R35 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 94.2/51.8
R36 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k
Ω
) T 108.2/53.4
R37 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
) [W/N] T 95.8/53.7
7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) [M/N] T 95.8/53.7
R38 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 100.1/47.5
R39 7030003280 S.RES ERJ3GEYJ 470 V (47
Ω
) T 101.5/45.1
R40 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
) T 103/46.4
R41 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 98.3/55.7
R42 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 99.8/57.5
R43 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) B 99.8/53.7
R44 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 103.7/52
R45 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) B 103.7/55.4
R46 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
) B 107.1/54.5
R47 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
) B 107/57.7
R50 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 64.2/45.9
R52 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 60.3/65.3
R53 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 54.6/65
R54 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 58.3/69.2
R55 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) [M], [H] T 54.9/72.4
7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) [L] T 54.9/72.4
R56 7030003700 S.RES ERJ3GEYJ 154 V (150 k
Ω
) T 56.2/69.8
R57 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 58.8/71.1
R58 7030003280 S.RES ERJ3GEYJ 470 V (47
Ω
) [L] T 53.6/69.8
7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) [M], [H] T 53.6/69.8
R59 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) [25W] T 60.3/66.6
7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) [45W] T 60.3/66.6
R61 7030003290 S.RES ERJ3GEYJ 560 V (56
Ω
) [25W] B 49.1/56.9
7030003340 S.RES ERJ3GEYJ 151 V (150
Ω
) [45W] B 49.1/56.9
To Next Page
