S.=Surface mount
6 - 3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R62 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) [25W] T 50/64.7
7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) [45W] T 50/64.7
R65 7030003340 S.RES ERJ3GEYJ 151 V (150
Ω
) [45W] B 52.6/56.9
7030003360 S.RES ERJ3GEYJ 221 V (220
Ω
) [25W] B 52.6/56.9
R66 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 53.1/63.9
R67 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 57.1/60
R68 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 56.3/58.1
R69 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 58.6/53.4
R70 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 63.2/44.1
R71 7030003260 S.RES ERJ3GEYJ 330 V (33
Ω
) T 63.9/46.7
R72 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) T 66.5/45.4
R73 7030003360 S.RES ERJ3GEYJ 221 V (220
Ω
) T 63.9/45.4
R74 7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω
) [M], [H] T 65.1/42.8
7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) [L] T 65.1/42.8
R75 7030003700 S.RES ERJ3GEYJ 154 V (150 k
Ω
) T 69.7/47.3
R76 7030003360 S.RES ERJ3GEYJ 221 V (220
Ω
) T 67.8/48
R77 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 75.2/25.7
R78 7030003410 S.RES ERJ3GEYJ 561 V (560
Ω
) B 66/39.7
R79 7030005341 S.RES ERA3YED 332V T 64.5/38.6
R80 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 68.8/40.5
R81 7030003200 S.RES ERJ3GEYJ 100 V (10
Ω
) T 62.1/39.1
R82 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7
Ω
) T 69.7/39.7
R83 7030005341 S.RES ERA3YED 332V T 68.4/40.1
R84 7030005341 S.RES ERA3YED 332V T 67.8/38.2
R85 7030005341 S.RES ERA3YED 332V T 65.8/36.7
R86 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) B 66.6/36.6
R88 7030003580 S.RES ERJ3GEYJ 153 V (15 k
Ω
) T 86.5/37
R89 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 76.8/30.1
R90 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 66.2/29
R91 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) [L] B 69.4/27.6
7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) [M], [H] B 69.4/27.6
R92 7030003690 S.RES ERJ3GEYJ 124 V (120 k
Ω
) B 78.9/28.2
R93 7030003280 S.RES ERJ3GEYJ 470 V (47
Ω
) B 68.1/32
R94 7030003280 S.RES ERJ3GEYJ 470 V (47
Ω
) B 66/32.7
R95 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) B 75.8/38
R96 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 75.5/36
R97 7030003200 S.RES ERJ3GEYJ 100 V (10
Ω
) B 76.8/36
R98 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) B 55.8/49.1
R99 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 81.7/31.5
R100 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 83/31.5
R101 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 83.6/29.5
R102 7030003580 S.RES ERJ3GEYJ 153 V (15 k
Ω
) T 89.1/37
R104 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k
Ω
) B 93/42.2
R105 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 94.3/39.6
R106 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) B 96.3/40.3
R107 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 106.3/37
R108 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) B 110.5/40.7
R109 7410000950 S.ARY EXB-V8V 102JV T 87.3/41.5
R110 7030003280 S.RES ERJ3GEYJ 470 V (47
Ω
) B 99.1/42.2
R111 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 99.2/20.3
R112 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 101.8/20.3
R113 7030003750 S.RES ERJ3GEYJ 394 V (390 k
Ω
) T 106.5/17.7
R115 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) B 108.4/22.5
R116 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
) B 107.7/25.7
R117 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k
Ω
) B 105.8/25.1
R118 7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω
) B 111.6/25.4
R119 7030003710 S.RES ERJ3GEYJ 184 V (180 k
Ω
) B 111.6/24.1
R120 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 116.6/24.1
R121 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 118.4/24.9
R122 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 115.8/26.2
R123 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 118.2/21.3
R124 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) T 114.4/20.8
R125 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 111/23.1
R126 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) B 118.7/19.4
R127 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) B 115.4/15.6
R128 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 111/21.7
R129 7030003760 S.RES ERJ3GEYJ 474 V (470 k
Ω
) T 109.1/17.7
R130 7030003610 S.RES ERJ3GEYJ 273 V (27 k
Ω
) B 106.4/19.9
R131 7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω
) T 104.6/17
R132 7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω
) B 102.4/17.5
R133 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) B 100.7/15.6
R134 7030003700 S.RES ERJ3GEYJ 154 V (150 k
Ω
) B 98.1/12.6
R135 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 100.7/11.5
R136 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 102.1/10.8
R137 7410000770 S.ARY EXB-V4V 102JV (1 k
Ω
) T 104.1/5.8
R138 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 27.7/15.8
R139 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 26.4/15.8
R140 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 25.1/15.8
R141 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) B 21.7/7.6
R142 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) B 25/10.7
R143 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) T 45.8/17
R144 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) T 41.7/8
R145 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) T 43.8/8
R146 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 88/5.4
R147 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) T 40.6/41.1
R148 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 40/30.1
R149 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 89.7/23.9
R150 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 72.3/26.5
R151 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) T 49.8/26.6
R152 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) T 37/16.1
R153 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 49.3/29.1
R154 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) B 23.1/41.1
R155 7410000750 S.ARY EXB-V4V 104JV (100 k
Ω
) B 23.4/46.2
R156 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 40.9/63.8
R157 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 41.4/18.7
R158 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 42.4/26.6
R159 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 15.1/54.6
R173 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 22/14
R174 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 23.3/12.7
R175 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 25.4/13.4
R176 7030003740 S.RES ERJ3GEYJ 334 V (330 k
Ω
) B 27.3/14
R177 7030003740 S.RES ERJ3GEYJ 334 V (330 k
Ω
) B 27.3/12.7
R178 7030003740 S.RES ERJ3GEYJ 334 V (330 k
Ω
) B 27.3/11.4
R179 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) B 109/20.6
R180 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k
Ω
) B 111.6/19.3
R181 7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω
) B 101.3/31
R182 7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω
) B 96.8/30.9
R185 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) B 103.9/31
R186 7030003630 S.RES ERJ3GEYJ 393 V (39 k
Ω
) B 105.8/29.8
R187 7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω
) B 110.3/30.9
R188 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
) B 110.3/28.3
R189 7030003610 S.RES ERJ3GEYJ 273 V (27 k
Ω
) B 110.3/29.6
R190 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7
Ω
) B 108.4/29.2
R191 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) B 20.5/56.8
R192 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) B 18.4/54.9
R193 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 15.7/56.5
R194 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) B 21.2/59.5
R195 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 14.1/58.4
R196 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) B 9.6/57.7
R197 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 9.1/55.4
R198 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 7/62.2
R199 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 3.6/89.6
R200 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 15.4/72.1
R201 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) T 16.7/71.2
R202 7030000460 S.RES MCR10EZHJ 4.7 k
Ω
T 26.6/60.1
R203 7030000460 S.RES MCR10EZHJ 4.7 k
Ω
T 28.4/60.1
R204 7030000460 S.RES MCR10EZHJ 4.7 k
Ω
T 32/60.1
R205 7030000460 S.RES MCR10EZHJ 4.7 k
Ω
T 33.8/60.1
R206 7030003760 S.RES ERJ3GEYJ 474 V (470 k
Ω
) T 94.5/50.9
R207 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) T 96.4/50.5
R208 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7
Ω
) T 90.5/50.7
R209 7510001470 S.TMR NTCG20 4AG 473JT B 91.6/35.5
R210 7030005871 S.RES ERA3YKD 104V (100 k
Ω
) B 91.8/38.5
R215 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k
Ω
) T 96.3/27.3
R216 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) T 96.3/28.8
R217 7030003610 S.RES ERJ3GEYJ 273 V (27 k
Ω
) T 34.4/43.7
R218 7030003610 S.RES ERJ3GEYJ 273 V (27 k
Ω
) B 37.8/43.5
R219 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 110.6/32.8
R220 7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω
) T 106.8/36
R222 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) T 77.1/61.2
R223 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 10.3/29.3
R224 7030003280 S.RES ERJ3GEYJ 470 V (47
Ω
) B 13.8/26.8
R225 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 14/21.2
R226 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 12.9/31.9
R227 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 15.3/30.6
R228 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 13.8/25.5
R229 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 10.3/31.9
R230 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 111/20.3
R231 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 97/35.7
R232 7030003290 S.RES ERJ3GEYJ 560 V (56
Ω
) B 79.3/39.7
R233 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 117.4/22.2
R234 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 61.3/44.9
R235 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 67.4/45.3
R236 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k
Ω
) T 97.5/45.1
R237 7030003780 S.RES ERJ3GEYJ 684 V (680 k
Ω
) T 95.6/41.1
R238 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 88.7/6.3
R239 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 23.9/56
R240 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 89.7/22.6
R241 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 93.4/21.3
R242 7030003630 S.RES ERJ3GEYJ 393 V (39 k
Ω
) B 93.4/22.6
R243 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) B 94.9/25.2
R244 7030003750 S.RES ERJ3GEYJ 394 V (390 k
Ω
) B 96.8/25.1
R245 7030003710 S.RES ERJ3GEYJ 184 V (180 k
Ω
) B 98.9/24.2
R246 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
) B 36.9/44.8
R247 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 91.4/24.6
R248 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 88.8/24.6
R249 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 88/22.5
R250 7030003690 S.RES ERJ3GEYJ 124 V (120 k
Ω
) T 75.1/20.7
R251 7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω
) T 81.8/16.6
R252 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) T 81.8/17.9
R253 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
)
except [LTR] T 80.6/19.2
7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) [LTR] T 80.6/19.2
R254 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 77.7/21.5
R255 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 76.4/20.7
R256 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 72.6/23.8
R257 7030003760 S.RES ERJ3GEYJ 474 V (470 k
Ω
) T 78.5/24
R258 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) B 40.1/44.4
R259 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k
Ω
) B 37.8/42.2
R260 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) T 117.4/41.9
R261 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) T 115.5/41.2
R262 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) T 115.5/38.6
R263 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 112.8/40
R264 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k
Ω
) T 115.1/34.7
R265 7030003630 S.RES ERJ3GEYJ 393 V (39 k
Ω
) T 111.9/32.8
R266 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k
Ω
) T 83.6/14.1
To Next Page
Loading...
Need help?
General
