S.=Surface mount
6 - 4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R267 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) B 53.1/28.8
R268 7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω
) B 53.1/27.5
R269 7030003710 S.RES ERJ3GEYJ 184 V (180 k
Ω
) B 53.1/26.2
R270 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 84.9/14.1
R271 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 86.2/14.1
R272 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 87.5/14.1
R273 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 92.1/13.8
R274 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 91.4/15.7
R275 7030003610 S.RES ERJ3GEYJ 273 V (27 k
Ω
)
except [LTR] T 92.9/15.7
R276 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) T 50.5/36.8
R277 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) T 49/40.8
R278 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) T 45.8/39.7
R280 7030003200 S.RES ERJ3GEYJ 100 V (10
Ω
) T 42.8/39
R281 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 53.5/24.1
R282 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 51.1/20
R284 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 29.4/16.1
R285 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 94.5/20.9
R286 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 52.8/9
R287 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 15.4/51.3
R288 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 50.5/42.1
R289 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 89.1/54.1
R290 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) B 95.2/48.6
R291 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 64/26.8
R292 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k
Ω
) B 62.4/29.6
R293 7410000950 S.ARY EXB-V8V 102JV B 42.5/8
R294 7410000950 S.ARY EXB-V8V 102JV T 46.7/8
R295 7410000950 S.ARY EXB-V8V 102JV B 43/17.4
R296 7410000770 S.ARY EXB-V4V 102JV (1 k
Ω
) B 46/17.4
R297 7030005651 S.RES ERA3YKD 304V (300 k
Ω
) B 35.5/55.1
R298 7030005871 S.RES ERA3YKD 104V (100 k
Ω
) B 40.7/47.2
R299 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 43.9/43
R302 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 76.6/59.3
R303 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 11.1/10.4
R304 7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω
) B 18.4/53.6
R305 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) B 107.2/38.3
R306 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 106.3/43.3
R307 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) B 109.3/37.9
R308 7030003380 S.RES ERJ3GEYJ 331 V (330
Ω
) B 104.4/59
R309 7030003380 S.RES ERJ3GEYJ 331 V (330
Ω
) [25W] T 43.8/64.3
7030003430 S.RES ERJ3GEYJ 821 V (820
Ω
) [45W] T 43.8/64.3
R310 7030003230 S.RES ERJ3GEYJ 180 V (18
Ω
) [25W] T 43/66.2
7030004030 S.RES ERJ3GEYJ 5R6 V (5.6
Ω
) [45W] T 43/66.2
R311 7030003380 S.RES ERJ3GEYJ 331 V (330
Ω
) [25W] T 42.5/64.3
7030003430 S.RES ERJ3GEYJ 821 V (820
Ω
) [45W] T 42.5/64.3
R312 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k
Ω
) T 83.6/11.5
R316 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 44.5/21.2
R317 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 89.1/29
R318 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) B 14.4/53.9
R319 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 96.3/17.8
R320 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
) B 97.1/15.7
R321 7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω
) B 86.5/22.4
R322 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 34.1/40.1
R323 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
)
[45W] only T 57.8/64
R324 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 60.9/69.2
R325 7520000160 S.POS PRF21BD471QB3RA [45W] only B 74.7/75.1
R326 7030003730 S.RES ERJ3GEYJ 274 V (270 k
Ω
) B 62.7/26.8
C1 4030011090 S.CER GRM31M2C2H7R0DV01L B 106.9/100.2
C2 4030011090 S.CER GRM31M2C2H7R0DV01L B 101/94.5
C3 4030006860 S.CER C1608 JB 1H 102K-T B 109.6/89.1
C4 4030011770 S.CER C1608 CH 1H 060B-T B 111.9/75.6
C5 4030006860 S.CER C1608 JB 1H 102K-T B 112.6/73.7
C6 4030011050 S.CER GRM31M3C2H3R0CY21L T 114.9/71
C7 4030011080 S.CER GRM31M2C2H6R0DV01L [M], [H] B 113.4/69
4030011090 S.CER GRM31M2C2H7R0DV01L [L] B 113.4/69
C8 4030011040 S.CER GRM31M4C2H2R0CY21L T 108.9/70
C9 4030011080 S.CER GRM31M2C2H6R0DV01L T 99.7/64.1
C10 4030006860 S.CER C1608 JB 1H 102K-T B 117.6/89
C11 4030006860 S.CER C1608 JB 1H 102K-T B 104.6/73.8
C12 4030006850 S.CER C1608 JB 1H 471K-T B 88.8/66.4
C13 4030007090 S.CER C1608 CH 1H 470J-T B 79/63
C14 4030011240 S.CER GRM31M2C2H470JV01L [25W] only B 105.5/63.5
C15 4030011100 S.CER GRM31M2C2H8R0DV01L T 88.8/65.9
C16 4030011020 S.CER GRM31M4C2H1R0CY21L [M], [H] B 111.5/62.5
4030011040 S.CER GRM31M4C2H2R0CY21L [L] B 111.5/62.5
C17 4030007000 S.CER C1608 CH 1H 090D-T [45W] B 89/63
4030007010 S.CER C1608 CH 1H 100D-T [25W] B 89/63
C18 4030009530 S.CER C1608 CH 1H 030B-T [M], [H] B 92.6/65.8
4030009910 S.CER C1608 CH 1H 040B-T [L] B 92.6/65.8
C19 4030006860 S.CER C1608 JB 1H 102K-T B 92.6/63.8
C20 4030007010 S.CER C1608 CH 1H 100D-T [M], [H] B 96.6/58.9
4030009920 S.CER C1608 CH 1H 050B-T [L] B 96.6/58.9
C21 4030009540 S.CER C1608 CH 1H 1R5B-T [L] B 96.6/60.2
4030009560 S.CER C1608 CH 1H R75B-T [M], [H] B 96.6/60.2
C22 4030009560 S.CER C1608 CH 1H R75B-T B 95.7/57.6
C23 4030006860 S.CER C1608 JB 1H 102K-T B 93.4/61.9
C24 4030006860 S.CER C1608 JB 1H 102K-T T 83.3/66.2
C25 4030009550 S.CER C1608 CH 1H 2R5B-T B 97.3/62.1
C26 4030006990 S.CER C1608 CH 1H 080D-T [L] B 93.1/56.1
4030007010 S.CER C1608 CH 1H 100D-T [M], [H] B 93.1/56.1
C27 4030006860 S.CER C1608 JB 1H 102K-T B 90.7/58.8
C28 4030006860 S.CER C1608 JB 1H 102K-T T 82/66.2
C29 4030009510 S.CER C1608 CH 1H 010B-T [M], [H] B 93.1/57.4
4030009530 S.CER C1608 CH 1H 030B-T [L] B 93.1/57.4
C30 4030009920 S.CER C1608 CH 1H 050B-T B 93.1/54.8
C32 4030006860 S.CER C1608 JB 1H 102K-T B 87.7/53.7
C33 4030007090 S.CER C1608 CH 1H 470J-T T 90.4/53.3
C34 4030006860 S.CER C1608 JB 1H 102K-T T 91.7/53.3
C35 4030006860 S.CER C1608 JB 1H 102K-T B 90.5/50.7
C36 4030009520 S.CER C1608 CH 1H 020B-T [M], [H] T 87.8/54.1
4030009530 S.CER C1608 CH 1H 030B-T [L] T 87.8/54.1
C37 4030006860 S.CER C1608 JB 1H 102K-T T 87.8/56.7
C38 4030006860 S.CER C1608 JB 1H 102K-T B 73.3/46.4
C39 4030006990 S.CER C1608 CH 1H 080D-T [L] B 85.8/54.7
4030007010 S.CER C1608 CH 1H 100D-T [M], [H] B 85.8/54.7
C40 4030009500 S.CER C1608 CH 1H 0R5B-T [L], [H] B 85.1/52.3
4030009560 S.CER C1608 CH 1H R75B-T [M] B 85.1/52.3
C41 4030007050 S.CER C1608 CH 1H 220J-T B 80.8/53.4
C42 4030006860 S.CER C1608 JB 1H 102K-T B 86.5/59.1
C43 4030006860 S.CER C1608 JB 1H 102K-T T 80.7/66.2
C44 4030009350 S.CER C1608 CH 1H 3R5B-T [L] B 82.7/54.2
4030009550 S.CER C1608 CH 1H 2R5B-T [M], [H] B 82.7/54.2
C45 4030006990 S.CER C1608 CH 1H 080D-T [L] B 84.3/54.2
4030007010 S.CER C1608 CH 1H 100D-T [M], [H] B 84.3/54.2
C46 4030006860 S.CER C1608 JB 1H 102K-T T 79.4/66.2
C47 4030006860 S.CER C1608 JB 1H 102K-T B 82/58
C48 4030007050 S.CER C1608 CH 1H 220J-T B 77.6/49.8
C49 4030009920 S.CER C1608 CH 1H 050B-T B 72.8/54.3
C50 4030006860 S.CER C1608 JB 1H 102K-T B 76.3/49.8
C51 4030006860 S.CER C1608 JB 1H 102K-T B 78.9/49.8
C52 4030007090 S.CER C1608 CH 1H 470J-T B 80.8/51.6
C53 4030006900 S.CER C1608 JB 1H 103K-T T 80.8/51.6
C54 4030006860 S.CER C1608 JB 1H 102K-T T 80.8/50.3
C56 4030007050 S.CER C1608 CH 1H 220J-T T 84.2/50.1
C58 4030006860 S.CER C1608 JB 1H 102K-T B 91.6/46.7
C59 4030011600 S.CER C1608 JB 1E 104K-T T 87.9/50.7
C60 4030006860 S.CER C1608 JB 1H 102K-T B 94.2/50.5
C61 4030007130 S.CER C1608 CH 1H 101J-T T 97.4/46.7
C62 4030007120 S.CER C1608 CH 1H 820J-T T 99/53.7
C63 4030006860 S.CER C1608 JB 1H 102K-T T 96.4/51.8
C64 4030011340 S.CER C1608 CH 1H 471J-T T 99.1/58.5
C65 4030006860 S.CER C1608 JB 1H 102K-T T 95.8/48.6
C66 4030006860 S.CER C1608 JB 1H 102K-T B 99.8/51.8
C67 4030006860 S.CER C1608 JB 1H 102K-T T 100.4/46.4
C69 4030007170 S.CER C1608 CH 1H 221J-T B 102.4/53.9
C70 4030007170 S.CER C1608 CH 1H 221J-T B 105/53.9
C71 4030011600 S.CER C1608 JB 1E 104K-T B 102.5/49.9
C72 4030011600 S.CER C1608 JB 1E 104K-T B 95.7/32.8
C74 4030011600 S.CER C1608 JB 1E 104K-T B 89.7/31.8
C75 4550006050 S.TAN TEESVA 0J 106M8L T 109.8/57
C76 4030006900 S.CER C1608 JB 1H 103K-T T 53.6/67.2
C77 4030006860 S.CER C1608 JB 1H 102K-T T 54.6/63.7
C78 4030006860 S.CER C1608 JB 1H 102K-T T 59.6/69.2
C79 4030011600 S.CER C1608 JB 1E 104K-T [M], [H] T 56.2/71.1
4030011810 S.CER C1608 JB 1A 224K-T [L] T 56.2/71.1
C80 4030008920 S.CER C1608 JB 1H 473K-T [L] T 58.3/66.6
4030011600 S.CER C1608 JB 1E 104K-T [M], [H] T 58.3/66.6
C81 4030006860 S.CER C1608 JB 1H 102K-T T 50.5/70.2
C82 4030011060 S.CER GRM31M2C2H4R0CY21L [25W] only T 95.8/74
C83 4030011050 S.CER GRM31M3C2H3R0CY21L [25W] only T 76.8/73.9
C84 4030007090 S.CER C1608 CH 1H 470J-T T 65.9/70.9
C85 4030006860 S.CER C1608 JB 1H 102K-T T 65.9/69.6
C86 4030007090 S.CER C1608 CH 1H 470J-T T 46.6/73.8
C87 4030006860 S.CER C1608 JB 1H 102K-T T 46.6/72.5
C89 4030006980 S.CER C1608 CH 1H 070D-T [L] T 38.8/68.8
4030011770 S.CER C1608 CH 1H 060B-T [M], [H] T 38.8/68.8
C90 4030006980 S.CER C1608 CH 1H 070D-T [L] T 41.2/64.3
4030011770 S.CER C1608 CH 1H 060B-T [M], [H] T 41.2/64.3
C91 4510005630 S.ELE ECEV1EA330SP [L] T 67.1/65.4
4510005750 S.ELE ECEV1EA220SP [M], [H] T 67.1/65.4
C92 4030009920 S.CER C1608 CH 1H 050B-T T 45.7/65
C93 4030009350 S.CER C1608 CH 1H 3R5B-T [45W] B 50.4/63.1
4030009910 S.CER C1608 CH 1H 040B-T [25W] B 50.4/63.1
C94 4030007090 S.CER C1608 CH 1H 470J-T T 50.9/62.3
C95 4030006860 S.CER C1608 JB 1H 102K-T T 52.2/62.3
C96 4030006860 S.CER C1608 JB 1H 102K-T B 47.8/59.9
C97 4030007090 S.CER C1608 CH 1H 470J-T B 49.1/59.9
C98 4030009520 S.CER C1608 CH 1H 020B-T [25W] B 55.3/62.6
4030009920 S.CER C1608 CH 1H 050B-T [45W] B 55.3/62.6
C99 4030006860 S.CER C1608 JB 1H 102K-T B 55.6/61.3
C100 4030009920 S.CER C1608 CH 1H 050B-T T 58.7/47.3
C101 4030006860 S.CER C1608 JB 1H 102K-T B 53.7/59.5
C102 4030007020 S.CER C1608 CH 1H 120J-T T 66.5/46.7
C103 4030009520 S.CER C1608 CH 1H 020B-T T 68.4/46.1
C104 4030006860 S.CER C1608 JB 1H 102K-T T 66.4/43.5
C105 4030006860 S.CER C1608 JB 1H 102K-T T 71/47.3
C106 4030007090 S.CER C1608 CH 1H 470J-T B 51/55.4
C107 4030006860 S.CER C1608 JB 1H 102K-T B 47.3/57.3
C108 4030006900 S.CER C1608 JB 1H 103K-T B 55/58.1
C109 4030006860 S.CER C1608 JB 1H 102K-T T 63.9/48
C110 4030006850 S.CER C1608 JB 1H 471K-T B 61/43
C111 4030007090 S.CER C1608 CH 1H 470J-T B 71.5/27.5
C113 4030009500 S.CER C1608 CH 1H 0R5B-T T 63.8/41.3
