APCO P25 Trunking –
Cloning Software Setup
Coverage Type
Select the coverage type for the area that the radio
is allowed to roam from UNRESTRICTED, SYSTEM,
RFSS, SITE and CHANNEL.
When a CH ID list with no valid channel is selected,
"X" appears in the cell and "System Registration" in
the tree view screen.
Scan Timeout Enter the time period for the radio to
scan a control channel while trying to detect a
synchronized frame within the range of 0 to 60 sec
(in 0 001 sec steps) The value should not be 0
UNRESTRICTED The roaming area is unrestricted
for the radio.
SYSTEM The Home WACN ID and the
Home System ID need to match
001 sec steps) The value should not be 0
.
Scan Threshold (dBm)
Set the minimum quality level for a control channel
within the range of -120 to -70 (in 1 steps).
When the Received Signal Strength Indication (RSSI)
level is higher than this set level, the receiving signal
is recognized as a control channel.
Home System ID need to match
to the repeater.
RFSS The Home WACN ID, Home
System ID and RFSS ID need to
match to the repeater.
SITE The Home WACN ID, Home
System ID, RFSS ID and Site ID
need to match to the repeater.
Mode Timeout Enter the time period for the radio to
scan a frequency while trying to get control channel
information within the range of 0 to 60 sec (in 0.001
sec steps).
¾Back Ground Scan Setting
CHANNEL The Home WACN ID, Home
System ID, RFSS ID and Site ID
need to match to the repeater.
Hunt List
Select the desired Hunt List from 1 to 4.
When the radio is powered on, changes trunking
system, or goes out of range, the radio will find a
control channel in a valid area with the hunt list.
List control channels in the Hunt List screen.
Enable the background scan is designed to monitor a
control channel of the adjacent site while waiting to
register a control channel. Select "Enable" to
activate the function.
When a hunt list with no valid channel is selected,
"X" appears in the cell and "System Registration" in
the tree view screen.
Roaming List
Select the desired Roaming List from 1 to 4.
The radio will move to a system using the roaming
list to find a channel that has higher quality, or
Interval (Sec) (Available only when "Enable" is
selected in Enable above)
Enter the interval time for back ground scan function
within the range of 0 to 60 sec (in 0.001 sec steps).
Interval determines how often the radio monitors a
control channel of the adjacent site.
list to find a channel that has higher quality, or
provides better services. A list of roaming addresses
will be displayed on the Roaming List screen.
When a roaming list with no valid area is selected,
"X" appears in the cell and "System Registration“ is
displayed on the tree view screen.
(Available only when Enable is
selected in Enable above)
Enter the duration for back ground scan function
within the range of 0 to 60 sec (in 0.001 sec steps).
The radio monitors the adjacent channel and checks
whether there is a valid signal or not for up to this
duration.
69
Select the desired CH ID List from 1 to 4.
List channel identifiers in the CH ID List screen.
