11
July 2013
(Additional page)
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[VCO UNIT]
Q2 1590004070 S.TRA LDTC144EET1G <SLVJ> T 13.4/9.3
Q3 1530002921 S.TRA 2SC4226-T1 Y25 (R25) T 11.9/2.8
Q4 1530002921 S.TRA 2SC4226-T1 Y25 (R25) T 18.6/2.3
Q5 1530003950 S.TRA KTC4080 Y-RTK/P T 7.1/6.9
Q6 1530003950 S.TRA KTC4080 Y-RTK/P T 4.9/2.6
Q7 1530003950 S.TRA KTC4080 Y-RTK/P T 5.4/11.3
Q8 1590004050 S.TRA LDTA144EET1G <SLVJ> T 11.4/12.5
D1 1750001790 S.DIO 1SS390 T 11.5/10.0
D2 1750001790 S.DIO 1SS390 T 13.3/7.7
D3 1750001780 S.VAR HVB350BYPTL-E T 14.4/5.6
L1 6200003711 S.COI NLV25T-2R7J T 18.2/9.2
L2 6200011410 S.COI C2520C-82NG-A T 17.9/5.9
L3 6200013750 S.COI MLK1005SR10JT T 5.7/8.3
L4 6200013750 S.COI MLK1005SR10JT T 3.5/4.0
L5 6200013750 S.COI MLK1005SR10JT T 4.0/12.7
R6 7030009320 S.RES ERJ2GEJ 4R7 X (4.7) T 7.5/10.8
R7 7030005120 S.RES ERJ2GEJ 102 X (1K) T 16.4/11.0
R8 7030005240 S.RES ERJ2GEJ 473 X (47K) T 16.2/9.8
R9 7030005120 S.RES ERJ2GEJ 102 X (1K) T 16.2/8.9
R11 7030005000 S.RES ERJ2GEJ 471 X (470) T 10.0/12.0
R12 7030005090 S.RES ERJ2GEJ 104 X (100K) T 18.5/13.7
R13 7030007340 S.RES ERJ2GEJ 153 X (15K) T 15.5/13.3
R14 7030005090 S.RES ERJ2GEJ 104 X (100K) T 18.5/12.8
R15 7030005090 S.RES ERJ2GEJ 104 X (100K) T 13.4/12.8
R16 7030005050 S.RES ERJ2GEJ 103 X (10K) T 9.4/13.2
R21 7030005050 S.RES ERJ2GEJ 103 X (10K) T 9.9/1.4
R22 7030005050 S.RES ERJ2GEJ 103 X (10K) T 20.7/1.7
R23 7030009160 S.RES ERJ2GEJ 181 X (180) T 15.6/2.2
R25 7030008370 S.RES ERJ2GEJ 561 X (560) T 9.9/3.2
R26 7030005010 S.RES ERJ2GEJ 681 X (680) T 6.9/9.6
R27 7030005070 S.RES ERJ2GEJ 683 X (68K) T 7.6/5.1
R31 7030005000 S.RES ERJ2GEJ 471 X (470) T 4.3/5.6
R32 7030005070 S.RES ERJ2GEJ 683 X (68K) T 6.8/1.7
R33 7030007270 S.RES ERJ2GEJ 151 X (150) T 2.9/5.3
R34 7030009200 S.RES ERJ2GEJ 390 X (39) T 1.8/4.4
R41 7030005000 S.RES ERJ2GEJ 471 X (470) T 3.5/9.5
R42 7030007350 S.RES ERJ2GEJ 393 X (39K) T 5.1/9.5
R43 7030003860 S.RES ERJ3GE JPW V T 16.1/3.7
C4 4030017460 S.CER C1005 JB 1H 102K-T T 18.3/11.3
C6 4030016790 S.CER C1005 JB 1E 103K-T T 3.5/7.5
C8 4030017460 S.CER C1005 JB 1H 102K-T T 15.2/10.8
C9 4030017460 S.CER C1005 JB 1H 102K-T T 15.0/9.5
C11 4030017460 S.CER C1005 JB 1H 102K-T T 12.8/10.8
C12 4030017460 S.CER C1005 JB 1H 102K-T T 14.0/11.3
C13 4030018860 S.CER C1005 JB 0J 105K-T T 13.4/13.7
C14 4030017460 S.CER C1005 JB 1H 102K-T T 14.6/13.3
C15 4030017460 S.CER C1005 JB 1H 102K-T T 17.3/13.3
C16 4030011810 S.CER C1608 JB 1A 224K-T T 10.3/9.9
C21 4030018010 S.CER C1005 CH 1H 360J-T T 16.2/8.0
C22 4030017670 S.CER C1005 CH 1H 390J-T T 15.0/7.6
C24 4030017760 S.CER C1005 JB 1H 222K-T T 11.6/7.0
C31 4030017350 S.CER C1005 CH 1H 020B-T T 12.2/4.7
C32 4030017550 S.CER C1005 CH 1H 1R5B-T T 20.4/3.3
C33 4030017440 S.CER C1005 CH 1H 221J-T T 15.6/1.3
C34 4030017460 S.CER C1005 JB 1H 102K-T T 9.9/4.1
C35 4030006860 S.CER C1608 JB 1H 102K-T T 14.1/2.7
C36 4030017340 S.CER C1005 CH 1H 010B-T T 9.9/2.3
C37 4030017460 S.CER C1005 JB 1H 102K-T T 7.0/8.7
C41 4030017380 S.CER C1005 CH 1H 050B-T T 6.8/3.3
C42 4030017460 S.CER C1005 JB 1H 102K-T T 4.8/4.4
C43 4030017400 S.CER C1005 CH 1H 220J-T T 2.5/3.1
C46 4030017630 S.CER C1005 CH 1H 120J-T T 4.8/8.3
C47 4030017460 S.CER C1005 JB 1H 102K-T T 3.5/8.4
C48 4030017460 S.CER C1005 JB 1H 102K-T T 5.4/13.1
C49 4030017650 S.CER C1005 CH 1H 270J-T T 3.3/11.3
J1 6910003831 CON IMSA-9230B-1-04Z003-PT1
J2 6910003831 CON IMSA-9230B-1-04Z003-PT1
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
To Next Page
