Icom IC-M400BB Service Manual

10
July 2013
(Additional page)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[CONNECT UNIT]
C1 4030016790 S.CER C1005 JB 1E 103K-T B 2.1/11.9
J1 6510022440 CON LTW-8MP-C NUTGASKET <LIA>
J2 6510025142 S.CON 10FLT-SM2-TB(LF)(SN)(M) B 4.3/15.0
EP2 6910019100 S.BEA MPZ1608S101AT B 4.5/19.1
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[LOGIC UNIT]
C5 4030016930 S.CER C1005 JB 1A 104K-T B 92.3/31.0
C6 4030016930 S.CER C1005 JB 1A 104K-T B 80.5/15.0
C7 4030016930 S.CER C1005 JB 1A 104K-T B 75.5/16.7
C8 4030016930 S.CER C1005 JB 1A 104K-T B 65.7/26.5
C9 4030016930 S.CER C1005 JB 1A 104K-T B 65.3/32.0
C10 4030016930 S.CER C1005 JB 1A 104K-T B 76.0/43.3
C11 4030016930 S.CER C1005 JB 1A 104K-T B 81.0/43.3
C12 4030016930 S.CER C1005 JB 1A 104K-T B 92.3/36.0
C13 4030017460 S.CER C1005 JB 1H 102K-T B 70.5/15.7
C14 4030017460 S.CER C1005 JB 1H 102K-T B 64.8/38.5
C15 4030017460 S.CER C1005 JB 1H 102K-T B 87.7/44.3
C16 4030017460 S.CER C1005 JB 1H 102K-T B 88.7/15.7
C17 4030016790 S.CER C1005 JB 1E 103K-T B 93.3/31.0
C18 4030016790 S.CER C1005 JB 1E 103K-T B 80.5/14.0
C19 4030016790 S.CER C1005 JB 1E 103K-T B 64.7/26.5
C20 4030016790 S.CER C1005 JB 1E 103K-T B 76.0/44.3
C24 4030017460 S.CER C1005 JB 1H 102K-T B 67.0/45.2
C25 4030016930 S.CER C1005 JB 1A 104K-T B 63.8/45.2
C26 4030020300 S.CER GRM21BB31C475KA87L B 92.8/20.9
C27 4030016790 S.CER C1005 JB 1E 103K-T B 94.2/20.4
C31 4030016950 S.CER C1005 JB 1A 473K-T B 85.5/15.3
C32 4030016950 S.CER C1005 JB 1A 473K-T B 84.5/16.3
C33 4030016950 S.CER C1005 JB 1A 473K-T B 85.1/13.9
C35 4030016950 S.CER C1005 JB 1A 473K-T B 92.8/23.2
C36 4030016950 S.CER C1005 JB 1A 473K-T B 92.8/24.2
C37 4030016950 S.CER C1005 JB 1A 473K-T B 92.8/25.2
C38 4030016950 S.CER C1005 JB 1A 473K-T B 92.8/26.2
C43 4030017410 S.CER C1005 CH 1H 240J-T B 94.3/28.5
C44 4030017410 S.CER C1005 CH 1H 240J-T B 94.3/26.7
C57 4030016930 S.CER C1005 JB 1A 104K-T B 87.3/48.5
C61 4030016790 S.CER C1005 JB 1E 103K-T B 106.8/27.1
C62 4030017760 S.CER C1005 JB 1H 222K-T B 39.3/41.3
C63 4030019990 S.CER C1005 JB 1C 104K-T B 40.3/41.3
C64 4030016790 S.CER C1005 JB 1E 103K-T B 37.0/40.4
C65 4030018890 S.CER C1005 JB 0J 224K-T B 35.3/40.8
C66 4030017760 S.CER C1005 JB 1H 222K-T B 30.5/50.8
C67 4030016930 S.CER C1005 JB 1A 104K-T B 29.1/50.4
C68 4030016790 S.CER C1005 JB 1E 103K-T B 32.8/51.8
C69 4340000310 S.MYL ECHU 1C 333JX5 B 38.2/50.7
C71 4030017920 S.CER C1005 JB 1A 683K-T B 43.0/13.3
C72 4030017480 S.CER C1608 JB 1A 474K-T B 41.4/11.2
C74 4030017460 S.CER C1005 JB 1H 102K-T B 44.0/9.1
C81 4030016930 S.CER C1005 JB 1A 104K-T B 37.6/33.6
C82 4030017460 S.CER C1005 JB 1H 102K-T B 39.2/30.0
C83 4030019990 S.CER C1005 JB 1C 104K-T B 34.0/33.1
C84 4030017460 S.CER C1005 JB 1H 102K-T B 33.6/34.1
C85 4030020300 S.CER GRM21BB31C475KA87L B 38.8/8.8
C86 4030017460 S.CER C1005 JB 1H 102K-T B 40.3/8.9
C87 4030016790 S.CER C1005 JB 1E 103K-T B 38.4/11.6
C88 4030020240 S.CER GRM31CR11C475KA01L B 36.8/10.5
C89 4030017460 S.CER C1005 JB 1H 102K-T B 41.5/33.8
C91 4030016930 S.CER C1005 JB 1A 104K-T B 56.4/13.8
C92 4030017460 S.CER C1005 JB 1H 102K-T B 57.1/20.0
C95 4030016790 S.CER C1005 JB 1E 103K-T B 49.5/40.8
C96 4030016930 S.CER C1005 JB 1A 104K-T B 55.5/34.8
C101 4030017460 S.CER C1005 JB 1H 102K-T B 120.2/36.9
C102 4030016930 S.CER C1005 JB 1A 104K-T B 121.2/36.9
C103 4030016790 S.CER C1005 JB 1E 103K-T B 122.2/36.9
C104 4030017920 S.CER C1005 JB 1A 683K-T B 131.4/32.0
C105 4030017460 S.CER C1005 JB 1H 102K-T B 131.4/30.0
C106 4030017460 S.CER C1005 JB 1H 102K-T B 128.2/30.6
C107 4030016930 S.CER C1005 JB 1A 104K-T B 136.9/34.6
C108 4030017460 S.CER C1005 JB 1H 102K-T B 134.5/27.9
C111 4030016790 S.CER C1005 JB 1E 103K-T B 45.8/26.5
C112 4030020310 S.CER GRM31CB31C106KA88L B 44.6/29.6
C113 4030016790 S.CER C1005 JB 1E 103K-T B 26.3/19.4
C114 4030017460 S.CER C1005 JB 1H 102K-T B 27.3/19.4
C115 4030017460 S.CER C1005 JB 1H 102K-T B 24.1/26.2
C116 4030017460 S.CER C1005 JB 1H 102K-T B 23.2/22.1
C155 4030016790 S.CER C1005 JB 1E 103K-T B 27.7/26.9
C162 4030016930 S.CER C1005 JB 1A 104K-T B 7.2/16.3
C165 4030017460 S.CER C1005 JB 1H 102K-T B 16.2/15.3
C166 4030017460 S.CER C1005 JB 1H 102K-T B 16.2/16.3
J1 6510022472 S.CON 40FLT-SM2-TB(LF)(SN)(M) B 35.0/23.0
J4 6510018971 S.CON B4B-PH-SM4-TB(LF)(SN) B 127.0/22.5
EP11 6910016330 S.BEA MMZ1005S 601CT-S B 129.6/31.0
