9
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
July 2013
(Additional page)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[LOGIC UNIT]
IC1 1140016243 S.IC STM32F100ZET6B(FX3338A3) B 79.0/30.0
IC2 1110006740 S.IC LMV358IPWR B 37.0/36.0
IC3 1130009981 S.IC TC7W53FK(TE85LF) B 38.5/31.8
IC4 1180003570 S.REG NJM2830U1-33-TE1-#ZZZB B 33.0/10.5
IC5 1130016110 S.IC TC7WH14FK(TE85LF) B 54.6/13.3
IC6 1130008711 S.IC TC7SET04FU(T5LJF) B 47.7/40.2
IC7 1130016110 S.IC TC7WH14FK(TE85LF) B 54.5/39.0
IC8 1170000352 S.IC PC357N6J000F B 127.0/36.0
IC9 1130016810 S.IC GT24C256-2GLI-TR <MSK> B 84.0/49.5
IC10 1110007620 S.IC NJU7704F3-42A-TE1-#ZZZB B 43.3/11.2
IC11 1110003650 S.IC NJM2211M-TE1-#ZZZB B 34.5/45.5
IC12 1130009301 S.IC TC7SET08FU(T5LJF) B 46.1/53.7
Q3 1590001330 S.TRA DTA114EUA T106 B 54.9/16.9
Q4 1530004140 S.TRA L2SC4081RT1G <SLVJ> B 53.9/20.8
Q5 1530004140 S.TRA L2SC4081RT1G <SLVJ> B 50.2/36.5
Q6 1510001151 S.TRA L2SA1576AST1G <SLVJ> B 47.4/36.8
Q7 1560000541 S.FET 2SK880-Y(T5RICOMF) B 53.0/35.3
Q8 1530004140 S.TRA L2SC4081RT1G <SLVJ> B 134.2/36.7
Q9 1590000710 S.TRA DTC124EUA T106 B 132.2/38.9
D3 1750001810 S.DIO L1SS400T1G <SLVJ> B 55.9/19.6
D4 1750001810 S.DIO L1SS400T1G <SLVJ> B 130.5/33.2
D5 1750001180 S.DIO KDS122 RTK/P B 134.2/33.6
D7 1790001990 S.VAR EZJP0V080DA B 134.5/29.7
X1 6050012460 S.XTA CR-834(SMD-49/7.9872 MHz)
<JJE> B 97.5/27.5
R1 7030005120 S.RES ERJ2GEJ 102 X (1K) B 65.3/34.8
R2 7030005240 S.RES ERJ2GEJ 473 X (47K) B 65.3/35.8
R3 7410001130 S.ARR EXB28V102JX B 49.5/30.5
R5 7030004970 S.RES ERJ2GEJ 470 X (47) B 61.5/22.1
R7 7030010040 S.RES ERJ2GEJ-JPW B 64.8/20.9
R11 7030005090 S.RES ERJ2GEJ 104 X (100K) B 72.0/43.3
R12 7410001230 S.ARR EXB28V101JX B 58.5/32.5
R16 7030005120 S.RES ERJ2GEJ 102 X (1K) B 82.4/43.7
R17 7030005050 S.RES ERJ2GEJ 103 X (10K) B 46.3/51.8
R21 7030005090 S.RES ERJ2GEJ 104 X (100K) B 72.3/16.7
R22 7030005120 S.RES ERJ2GEJ 102 X (1K) B 73.7/16.3
R23 7410001130 S.ARR EXB28V102JX B 58.8/26.0
R24 7410001140 S.ARR EXB28V104JX B 64.0/24.4
R25 7030005120 S.RES ERJ2GEJ 102 X (1K) B 79.1/16.7
R26 7030005600 S.RES ERJ2GEJ 273 X (27K) B 86.3/16.7
R27 7030007290 S.RES ERJ2GEJ 222 X (2.2K) [USA] B 86.9/14.7
7030009290 S.RES ERJ2GEJ 562 X (5.6K) [UK]
7030008010 S.RES ERJ2GEJ 123 X (12K) [EUR]
7030009710 S.RES ERJ2GEJ 203 X (20K) [HOL]
7030005060 S.RES ERJ2GEJ 333 X (33K) [FRG]
7030007290 S.RES ERJ2GEJ 222 X (2.2K) [USA-01]
7030009290 S.RES ERJ2GEJ 562 X (5.6K) [UK-01]
7030008010 S.RES ERJ2GEJ 123 X (12K) [EUR-01]
7030009710 S.RES ERJ2GEJ 203 X (20K) [HOL-01]
7030005060 S.RES ERJ2GEJ 333 X (33K) [FRG-01]
7030007290 S.RES ERJ2GEJ 222 X (2.2K) [USA-02]
7030008010 S.RES ERJ2GEJ 123 X (12K) [EUR-02]
R28 7030011670 S.RES ERJ2RKF 3902 (39K) B 85.1/12.9
R29 7030012320 S.RES ERJ2RKD 2203X (220K) B 85.1/11.9
R34 7030004980 S.RES ERJ2GEJ 101 X (100) B 92.8/27.2
R51 7030005530 S.RES ERJ2GEJ 100 X (10) B 38.3/40.4
R52 7030005090 S.RES ERJ2GEJ 104 X (100K) B 108.2/27.5
R53 7030005170 S.RES ERJ2GEJ 474 X (470K) B 35.3/39.8
R54 7030007350 S.RES ERJ2GEJ 393 X (39K) B 33.7/50.4
R55 7030012740 S.RES ERJ2RHD 1602X (16.0K) B 35.1/50.8
R56 7030008400 S.RES ERJ2GEJ 182 X (1.8K) B 34.1/51.8
R57 7030005090 S.RES ERJ2GEJ 104 X (100K) B 31.9/50.4
R61 7030005050 S.RES ERJ2GEJ 103 X (10K) B 87.7/46.3
R62 7030005050 S.RES ERJ2GEJ 103 X (10K) B 87.7/45.3
R65 7030008010 S.RES ERJ2GEJ 123 X (12K) B 45.7/8.3
R66 7030005240 S.RES ERJ2GEJ 473 X (47K) B 39.8/12.1
R67 7030005240 S.RES ERJ2GEJ 473 X (47K) B 40.2/10.7
R71 7030005050 S.RES ERJ2GEJ 103 X (10K) B 42.5/36.0
R73 7030005240 S.RES ERJ2GEJ 473 X (47K) B 32.5/36.2
R74 7030005090 S.RES ERJ2GEJ 104 X (100K) B 35.8/33.6
R75 7030004980 S.RES ERJ2GEJ 101 X (100) B 34.0/32.1
R81 7030005090 S.RES ERJ2GEJ 104 X (100K) B 57.4/13.8
R82 7030005120 S.RES ERJ2GEJ 102 X (1K) B 56.9/16.9
R83 7030005530 S.RES ERJ2GEJ 100 X (10) B 58.1/20.9
R84 7030005240 S.RES ERJ2GEJ 473 X (47K) B 54.4/18.7
R85 7030005240 S.RES ERJ2GEJ 473 X (47K) B 52.8/13.3
R90 7030005220 S.RES ERJ2GEJ 223 X (22K) B 50.9/39.4
R91 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 49.5/39.0
R92 7030004970 S.RES ERJ2GEJ 470 X (47) B 48.7/35.0
R95 7030005120 S.RES ERJ2GEJ 102 X (1K) B 54.0/32.5
R96 7030005240 S.RES ERJ2GEJ 473 X (47K) B 54.0/33.5
R97 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 55.5/35.8
R101 7030005120 S.RES ERJ2GEJ 102 X (1K) B 121.7/38.3
R102 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 122.2/35.1
R103 7030009270 S.RES ERJ2GEJ 821 X (820) B 129.6/32.0
R106 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 136.0/34.6
R107 7030010430 S.RES ERJ2GEJ 120 X (12) B 132.4/35.4
R108 7030005090 S.RES ERJ2GEJ 104 X (100K) B 134.5/28.8
R111 7030005050 S.RES ERJ2GEJ 103 X (10K) B 3.7/17.5
R113 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 5.7/18.0
R116 7030005240 S.RES ERJ2GEJ 473 X (47K) B 44.0/54.2
C1 4030016930 S.CER C1005 JB 1A 104K-T B 70.5/16.7
C2 4030016930 S.CER C1005 JB 1A 104K-T B 65.8/38.5
C3 4030016930 S.CER C1005 JB 1A 104K-T B 87.7/43.3
C4 4030016930 S.CER C1005 JB 1A 104K-T B 88.1/16.7
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
W1 7030012290 JUM RDS2T0R0
W2 8900014871 CAB OPC-1332A-1(P0.5N40L100)
W3 8900020400 CAB OPC-2216 <TJM>
EP401 6910016330 S.BEA MMZ1005S 601CT-S T 123.7/21.0
EP701 6910016330 S.BEA MMZ1005S 601CT-S B 8.2/10.1
EP702 6910016330 S.BEA MMZ1005S 601CT-S B 8.9/14.2
EP703 6910019100 S.BEA MPZ1608S101AT B 20.0/33.0
EP704 6910019100 S.BEA MPZ1608S101AT B 23.1/33.0
EP705 6910019100 S.BEA MPZ1608S101AT B 12.7/26.4
EP706 6910019100 S.BEA MPZ1608S101AT B 17.6/33.2
To Next Page
