8
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
July 2013
(Additional page)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
C714 4030017760 S.CER C1005 JB 1H 222K-T B 83.7/3.0
C715 4030017790 S.CER C1005 JB 1H 682K-T B 81.0/3.0
C716 4030016790 S.CER C1005 JB 1E 103K-T B 80.1/4.7
C717 4030016790 S.CER C1005 JB 1E 103K-T B 85.5/6.3
C718 4030016930 S.CER C1005 JB 1A 104K-T B 84.6/6.3
C721 4030017680 S.CER C1005 CH 1H 820J-T B 88.2/14.1
C722 4030016790 S.CER C1005 JB 1E 103K-T B 89.1/6.3
C724 4030017730 S.CER C1005 JB 1H 471K-T T 33.2/13.3
C725 4030017680 S.CER C1005 CH 1H 820J-T T 60.0/4.8
C726 4030017460 S.CER C1005 JB 1H 102K-T T 86.5/3.2
C727 4030017460 S.CER C1005 JB 1H 102K-T T 38.3/14.1
C728 4030016790 S.CER C1005 JB 1E 103K-T T 37.3/14.1
C732 4030017460 S.CER C1005 JB 1H 102K-T T 36.7/4.5
C734 4030017440 S.CER C1005 CH 1H 221J-T T 35.7/4.5
C742 4030011600 S.CER C1608 JB 1E 104K-T B 19.0/14.0
C743 4030017440 S.CER C1005 CH 1H 221J-T T 31.7/17.7
C744 4030011600 S.CER C1608 JB 1E 104K-T B 11.2/10.8
C745 4030017460 S.CER C1005 JB 1H 102K-T B 7.1/9.2
C746 4030017490 S.CER C1608 JB 1A 105K-T B 18.1/18.4
C748 4030017460 S.CER C1005 JB 1H 102K-T T 5.0/9.4
C751 4030017440 S.CER C1005 CH 1H 221J-T B 19.6/20.5
C752 4030011600 S.CER C1608 JB 1E 104K-T B 17.8/21.9
C753 4030011600 S.CER C1608 JB 1E 104K-T B 9.3/12.7
C754 4030017460 S.CER C1005 JB 1H 102K-T B 8.0/14.2
C761 4030017460 S.CER C1005 JB 1H 102K-T B 7.1/11.8
C762 4510009920 S.ELE 16 CE 100 LH T 11.2/13.7
C763 4030020310 S.CER GRM31CB31C106KA88L T 5.2/15.1
C764 4030017480 S.CER C1608 JB 1A 474K-T B 7.9/20.3
C765 4510010300 S.ELE 16 CE 470 AX T 13.3/29.6
C766 4030011600 S.CER C1608 JB 1E 104K-T T 6.5/28.8
C767 4030017460 S.CER C1005 JB 1H 102K-T T 7.6/27.1
C768 4030017460 S.CER C1005 JB 1H 102K-T T 7.6/26.2
C769 4030017460 S.CER C1005 JB 1H 102K-T B 11.5/39.1
C770 4030011600 S.CER C1608 JB 1E 104K-T B 12.6/39.2
C772 4030011600 S.CER C1608 JB 1E 104K-T B 8.9/29.5
C773 4030011600 S.CER C1608 JB 1E 104K-T B 8.9/32.3
C775 4030017440 S.CER C1005 CH 1H 221J-T B 21.4/33.6
C776 4030017440 S.CER C1005 CH 1H 221J-T B 21.4/32.1
C777 4030017440 S.CER C1005 CH 1H 221J-T B 24.5/33.6
C778 4030017440 S.CER C1005 CH 1H 221J-T B 24.5/32.1
C782 4030011600 S.CER C1608 JB 1E 104K-T B 8.9/22.9
C783 4030011600 S.CER C1608 JB 1E 104K-T B 8.9/25.7
C785 4030017440 S.CER C1005 CH 1H 221J-T B 13.1/24.5
C786 4030017440 S.CER C1005 CH 1H 221J-T B 13.8/26.8
C787 4030017440 S.CER C1005 CH 1H 221J-T B 16.4/32.1
C788 4030017440 S.CER C1005 CH 1H 221J-T B 18.1/32.1
C791 4030017460 S.CER C1005 JB 1H 102K-T T 5.5/10.7
C792 4030016930 S.CER C1005 JB 1A 104K-T T 6.4/10.7
C806 4030017460 S.CER C1005 JB 1H 102K-T T 37.7/4.5
C811 4030017460 S.CER C1005 JB 1H 102K-T T 40.3/14.1
C812 4030017460 S.CER C1005 JB 1H 102K-T T 40.7/4.5
C813 4030017460 S.CER C1005 JB 1H 102K-T T 41.7/15.3
C814 4030017460 S.CER C1005 JB 1H 102K-T T 41.7/4.5
C816 4030017460 S.CER C1005 JB 1H 102K-T T 42.7/4.5
C818 4030017460 S.CER C1005 JB 1H 102K-T T 43.7/4.5
C820 4030017460 S.CER C1005 JB 1H 102K-T T 44.7/4.5
C821 4030017460 S.CER C1005 JB 1H 102K-T T 45.3/14.1
C823 4030017460 S.CER C1005 JB 1H 102K-T T 46.3/14.1
C825 4030017460 S.CER C1005 JB 1H 102K-T T 47.3/14.1
C827 4030017460 S.CER C1005 JB 1H 102K-T T 48.3/14.1
C830 4030017400 S.CER C1005 CH 1H 220J-T T 49.7/4.5
C832 4030017400 S.CER C1005 CH 1H 220J-T T 50.7/4.5
C834 4030017460 S.CER C1005 JB 1H 102K-T T 51.7/4.5
C836 4030017460 S.CER C1005 JB 1H 102K-T T 52.7/4.5
C838 4030017460 S.CER C1005 JB 1H 102K-T T 53.7/4.5
C841 4030017490 S.CER C1608 JB 1A 105K-T B 40.8/25.9
C842 4030017460 S.CER C1005 JB 1H 102K-T B 50.7/25.6
C843 4030016930 S.CER C1005 JB 1A 104K-T B 42.3/21.4
C901 4030016930 S.CER C1005 JB 1A 104K-T T 53.3/23.3
C902 4030017460 S.CER C1005 JB 1H 102K-T T 51.5/19.5
C903 4030016930 S.CER C1005 JB 1A 104K-T B 44.1/31.8
C904 4030016930 S.CER C1005 JB 1A 104K-T B 51.0/28.2
C905 4030016930 S.CER C1005 JB 1A 104K-T B 49.2/28.2
C906 4030016930 S.CER C1005 JB 1A 104K-T B 43.2/31.8
C907 4030019620 S.CER GRM188B31C225KE14D B 38.5/37.4
C908 4030016790 S.CER C1005 JB 1E 103K-T B 36.1/37.0
C910 4030019560 S.CER GRM21BB31C106KE15L B 41.6/29.3
C911 4550008240 S.TAN F930G476MAA B 40.3/39.7
C912 4030016930 S.CER C1005 JB 1A 104K-T B 59.7/34.7
C913 4030016930 S.CER C1005 JB 1A 104K-T B 60.1/41.5
C914 4030016930 S.CER C1005 JB 1A 104K-T B 52.1/43.9
C915 4030017770 S.CER C1005 JB 1H 332K-T B 59.7/39.3
C916 4030017040 S.CER C1005 JB 1A 333K-T B 61.5/40.2
C917 4030016930 S.CER C1005 JB 1A 104K-T B 43.2/37.4
C918 4030016930 S.CER C1005 JB 1A 104K-T B 44.1/35.6
C919 4030019560 S.CER GRM21BB31C106KE15L B 46.6/27.8
C921 4030016930 S.CER C1005 JB 1A 104K-T B 52.6/28.2
C922 4030016930 S.CER C1005 JB 1A 104K-T B 59.7/33.0
C923 4030016930 S.CER C1005 JB 1A 104K-T B 60.6/39.3
C924 4030016930 S.CER C1005 JB 1A 104K-T B 54.6/43.9
C925 4030019560 S.CER GRM21BB31C106KE15L B 53.6/26.8
C931 4030018920 S.CER C1005 JB 1H 392K-T T 57.3/28.6
C932 4030018080 S.CER C1005 JB 1H 182K-T T 59.1/28.6
C933 4030020010 S.CER C1005 CH 1H 271J-T T 60.3/28.1
C934 4030016790 S.CER C1005 JB 1E 103K-T T 60.2/23.3
J1 6510025142 S.CON 10FLT-SM2-TB(LF)(SN)(M) T 40.9/47.3
J2 6510022472 S.CON 40FLT-SM2-TB(LF)(SN)(M) T 45.0/9.3
J3 6510018971 S.CON B4B-PH-SM4-TB(LF)(SN) B 20.7/25.8
F1 5210001160 S.FUS ERBRE3R00V T 3.8/48.8
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
C405 4030017760 S.CER C1005 JB 1H 222K-T T 124.0/14.4
C406 4030017410 S.CER C1005 CH 1H 240J-T T 126.5/12.1
C407 4030017560 S.CER C1005 CH 1H 2R5B-T T 127.4/12.1
C408 4030017760 S.CER C1005 JB 1H 222K-T T 124.9/14.4
C411 4030017540 S.CER C1005 CH 1H R75B-T T 128.3/12.1
C412 4030017410 S.CER C1005 CH 1H 240J-T T 129.9/12.9
C413 4030017560 S.CER C1005 CH 1H 2R5B-T T 129.9/13.8
C414 4030017540 S.CER C1005 CH 1H R75B-T T 129.5/15.1
C415 4030017410 S.CER C1005 CH 1H 240J-T T 130.8/18.6
C416 4030017340 S.CER C1005 CH 1H 010B-T T 130.8/17.7
C417 4030017460 S.CER C1005 JB 1H 102K-T T 129.6/18.1
C421 4030017460 S.CER C1005 JB 1H 102K-T T 129.7/23.8
C422 4030017460 S.CER C1005 JB 1H 102K-T T 126.7/19.8
C423 4030017460 S.CER C1005 JB 1H 102K-T T 127.6/19.8
C424 4030017590 S.CER C1005 CH 1H 070C-T T 128.4/24.2
C425 4030016790 S.CER C1005 JB 1E 103K-T T 126.2/17.7
C501 4510010250 S.ELE 16 CE 22 LD T 11.9/51.2
C502 4030017460 S.CER C1005 JB 1H 102K-T T 44.3/50.6
C503 4030011600 S.CER C1608 JB 1E 104K-T T 44.8/51.7
C504 4030017460 S.CER C1005 JB 1H 102K-T T 5.9/52.8
C505 4030011600 S.CER C1608 JB 1E 104K-T T 7.0/52.9
C506 4030017730 S.CER C1005 JB 1H 471K-T B 42.5/53.8
C507 4030016790 S.CER C1005 JB 1E 103K-T B 43.4/53.8
C508 4030017430 S.CER C1005 CH 1H 101J-T T 44.3/49.7
C509 4030017730 S.CER C1005 JB 1H 471K-T T 22.2/53.8
C510 4030016790 S.CER C1005 JB 1E 103K-T T 23.1/53.8
C511 4030016790 S.CER C1005 JB 1E 103K-T T 43.5/42.5
C512 4030016790 S.CER C1005 JB 1E 103K-T T 39.6/44.0
C513 4030020250 S.CER GRM21BB11A225KA01L T 37.7/40.0
C514 4030017460 S.CER C1005 JB 1H 102K-T T 38.1/42.4
C516 4030017460 S.CER C1005 JB 1H 102K-T T 39.6/53.5
C517 4030017460 S.CER C1005 JB 1H 102K-T T 42.8/54.4
C521 4030017490 S.CER C1608 JB 1A 105K-T B 32.9/34.0
C522 4030018890 S.CER C1005 JB 0J 224K-T B 28.7/32.5
C523 4030018890 S.CER C1005 JB 0J 224K-T B 28.7/29.2
C524 4030018910 S.CER C1608 JB 0J 475K-T B 67.2/9.0
C525 4030017460 S.CER C1005 JB 1H 102K-T B 68.3/8.7
C526 4030017460 S.CER C1005 JB 1H 102K-T B 35.7/29.7
C528 4030017490 S.CER C1608 JB 1A 105K-T B 64.9/3.6
C530 4030017490 S.CER C1608 JB 1A 105K-T B 58.1/4.3
C531 4030019620 S.CER GRM188B31C225KE14D B 59.7/6.5
C532 4030017760 S.CER C1005 JB 1H 222K-T B 60.4/9.8
C533 4030018080 S.CER C1005 JB 1H 182K-T B 60.1/7.6
C535 4030018890 S.CER C1005 JB 0J 224K-T B 58.6/11.5
C536 4030017030 S.CER C1005 JB 1A 273K-T B 58.6/14.9
C537 4030017030 S.CER C1005 JB 1A 273K-T B 61.7/15.1
C538 4030016930 S.CER C1005 JB 1A 104K-T B 57.7/14.9
C539 4030017490 S.CER C1608 JB 1A 105K-T B 68.8/10.9
C541 4030017490 S.CER C1608 JB 1A 105K-T T 63.7/20.4
C560 4030019620 S.CER GRM188B31C225KE14D B 57.4/18.7
C571 4030016790 S.CER C1005 JB 1E 103K-T B 77.8/12.8
C576 4030018890 S.CER C1005 JB 0J 224K-T B 71.8/17.3
C578 4030017460 S.CER C1005 JB 1H 102K-T B 69.6/17.1
C602 4030016790 S.CER C1005 JB 1E 103K-T B 7.4/44.1
C603 4030016930 S.CER C1005 JB 1A 104K-T B 7.4/43.2
C604 4030016930 S.CER C1005 JB 1A 104K-T B 12.9/46.0
C605 4030016790 S.CER C1005 JB 1E 103K-T B 12.9/46.9
C607 4030020310 S.CER GRM31CB31C106KA88L B 11.0/46.0
C611 4510009920 S.ELE 16 CE 100 LH T 12.5/44.7
C612 4030016790 S.CER C1005 JB 1E 103K-T T 6.4/40.8
C613 4030016930 S.CER C1005 JB 1A 104K-T T 5.5/40.8
C614 4030011600 S.CER C1608 JB 1E 104K-T T 6.6/34.1
C615 4030016790 S.CER C1005 JB 1E 103K-T T 7.7/34.1
C616 4510009920 S.ELE 16 CE 100 LH T 12.5/37.6
C620 4030017460 S.CER C1005 JB 1H 102K-T B 9.7/43.0
C621 4510010300 S.ELE 16 CE 470 AX T 28.0/53.0
C622 4030011600 S.CER C1608 JB 1E 104K-T T 20.6/46.1
C623 4030017440 S.CER C1005 CH 1H 221J-T T 19.5/46.6
C624 4030017460 S.CER C1005 JB 1H 102K-T T 18.6/46.6
C625 4030017430 S.CER C1005 CH 1H 101J-T B 45.1/52.0
C626 4030017420 S.CER C1005 CH 1H 470J-T B 44.2/52.0
C627 4030017730 S.CER C1005 JB 1H 471K-T B 51.1/46.6
C628 4030017400 S.CER C1005 CH 1H 220J-T B 50.2/46.6
C629 4030017400 S.CER C1005 CH 1H 220J-T B 57.2/56.0
C630 4030017430 S.CER C1005 CH 1H 101J-T B 58.1/56.0
C631 4030017730 S.CER C1005 JB 1H 471K-T B 13.7/39.1
C636 4030016790 S.CER C1005 JB 1E 103K-T T 30.4/21.3
C637 4510010250 S.ELE 16 CE 22 LD T 28.7/26.5
C640 4030017460 S.CER C1005 JB 1H 102K-T B 25.6/21.0
C641 4030017510 S.CER C1005 CH 1H 680J-T B 27.4/20.9
C642 4030018920 S.CER C1005 JB 1H 392K-T B 24.7/19.3
C643 4030017460 S.CER C1005 JB 1H 102K-T B 22.4/19.0
C644 4030016790 S.CER C1005 JB 1E 103K-T B 26.4/10.3
C649 4030017460 S.CER C1005 JB 1H 102K-T B 27.7/9.8
C650 4030018910 S.CER C1608 JB 0J 475K-T B 27.4/8.7
C651 4030016790 S.CER C1005 JB 1E 103K-T B 27.5/7.2
C662 4030020270 S.CER GRM188B11A105KA61D B 33.9/16.7
C663 4030017460 S.CER C1005 JB 1H 102K-T B 29.0/20.4
C664 4030016790 S.CER C1005 JB 1E 103K-T T 27.0/20.1
C669 4030017460 S.CER C1005 JB 1H 102K-T B 29.8/8.0
C681 4030016790 S.CER C1005 JB 1E 103K-T T 52.0/27.4
C682 4030018910 S.CER C1608 JB 0J 475K-T T 51.6/25.6
C683 4030016790 S.CER C1005 JB 1E 103K-T T 39.1/30.4
C686 4030019460 S.CER C1608 JB 0J 106M-T T 57.1/31.0
C701 4030016930 S.CER C1005 JB 1A 104K-T B 87.3/12.4
C702 4030017790 S.CER C1005 JB 1H 682K-T B 86.4/10.7
C703 4030016970 S.CER C1005 JB 1E 223K-T B 82.8/10.7
C704 4030017760 S.CER C1005 JB 1H 222K-T B 83.7/10.7
C705 4030017790 S.CER C1005 JB 1H 682K-T B 81.0/10.7
C706 4030016790 S.CER C1005 JB 1E 103K-T B 80.1/10.7
C707 4030016790 S.CER C1005 JB 1E 103K-T B 85.5/14.1
C708 4030016930 S.CER C1005 JB 1A 104K-T B 84.6/14.1
C711 4030016930 S.CER C1005 JB 1A 104K-T B 88.7/5.1
C712 4030017790 S.CER C1005 JB 1H 682K-T B 86.4/3.0
C713 4030016970 S.CER C1005 JB 1E 223K-T B 82.8/3.0
