7
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
July 2013
(Additional page)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
C161 4030017460 S.CER C1005 JB 1H 102K-T T 60.3/17.5
C162 4030016930 S.CER C1005 JB 1A 104K-T T 67.3/19.3
C163 4030017680 S.CER C1005 CH 1H 820J-T T 69.0/10.9
C164 4030017500 S.CER C1005 CH 1H 560J-T T 67.2/12.6
C165 4030017640 S.CER C1005 CH 1H 150J-T T 62.9/7.6
C166 4030018070 S.CER C1005 CH 1H 300J-T T 60.9/7.6
C167 4030016790 S.CER C1005 JB 1E 103K-T T 60.4/10.1
C168 4030017550 S.CER C1005 CH 1H 1R5B-T T 62.9/6.6
C201 4030017410 S.CER C1005 CH 1H 240J-T T 113.8/43.7
C202 4030017610 S.CER C1005 CH 1H 090C-T T 115.2/43.3
C203 4030017360 S.CER C1005 CH 1H 030B-T T 118.6/45.4
C204 4030017460 S.CER C1005 JB 1H 102K-T T 119.9/42.7
C205 4030017400 S.CER C1005 CH 1H 220J-T T 120.1/46.9
C206 4030017370 S.CER C1005 CH 1H 3R5B-T T 124.9/44.5
C207 4030016930 S.CER C1005 JB 1A 104K-T T 123.8/46.9
C208 4030017460 S.CER C1005 JB 1H 102K-T T 124.7/46.9
C209 4030017400 S.CER C1005 CH 1H 220J-T T 121.9/46.9
C210 4030017760 S.CER C1005 JB 1H 222K-T T 122.8/46.9
C211 4030017590 S.CER C1005 CH 1H 070C-T T 123.6/42.0
C213 4030017360 S.CER C1005 CH 1H 030B-T T 125.3/43.1
C221 4030017360 S.CER C1005 CH 1H 030B-T T 117.8/35.3
C222 4030017460 S.CER C1005 JB 1H 102K-T T 117.3/34.0
C223 4030017560 S.CER C1005 CH 1H 2R5B-T T 115.9/33.7
C224 4030017760 S.CER C1005 JB 1H 222K-T T 119.8/30.8
C231 4030016790 S.CER C1005 JB 1E 103K-T T 120.8/29.1
C232 4030017500 S.CER C1005 CH 1H 560J-T T 113.6/28.4
C233 4030017550 S.CER C1005 CH 1H 1R5B-T T 112.7/28.4
C234 4030017400 S.CER C1005 CH 1H 220J-T T 116.8/28.4
C235 4030017460 S.CER C1005 JB 1H 102K-T T 117.7/28.4
C236 4030016930 S.CER C1005 JB 1A 104K-T T 118.6/28.4
C237 4030017460 S.CER C1005 JB 1H 102K-T T 110.9/28.4
C242 4030017360 S.CER C1005 CH 1H 030B-T [USA] T 101.4/24.0
4030017570 S.CER C1005 CH 1H 040B-T [UK]
4030017570 S.CER C1005 CH 1H 040B-T [EUR]
4030017570 S.CER C1005 CH 1H 040B-T [HOL]
4030017570 S.CER C1005 CH 1H 040B-T [FRG]
4030017360 S.CER C1005 CH 1H 030B-T [USA-01]
4030017570 S.CER C1005 CH 1H 040B-T [UK-01]
4030017570 S.CER C1005 CH 1H 040B-T [EUR-01]
4030017570 S.CER C1005 CH 1H 040B-T [HOL-01]
4030017570 S.CER C1005 CH 1H 040B-T [FRG-01]
4030017360 S.CER C1005 CH 1H 030B-T [USA-02]
4030017570 S.CER C1005 CH 1H 040B-T [EUR-02]
C245 4030017460 S.CER C1005 JB 1H 102K-T T 93.1/23.0
C251 4030017640 S.CER C1005 CH 1H 150J-T T 94.9/23.0
C252 4030016790 S.CER C1005 JB 1E 103K-T T 92.1/18.5
C253 4030017460 S.CER C1005 JB 1H 102K-T T 92.1/17.6
C254 4030016790 S.CER C1005 JB 1E 103K-T T 93.7/17.6
C262 4030017580 S.CER C1005 CH 1H 060C-T T 111.6/33.3
C264 4030017460 S.CER C1005 JB 1H 102K-T T 107.6/34.7
C271 4030017420 S.CER C1005 CH 1H 470J-T T 92.8/11.0
C272 4030018910 S.CER C1608 JB 0J 475K-T T 89.7/10.8
C273 4030016790 S.CER C1005 JB 1E 103K-T T 91.5/10.5
C274 4030018890 S.CER C1005 JB 0J 224K-T T 97.3/15.7
C275 4030017460 S.CER C1005 JB 1H 102K-T T 94.6/11.0
C276 4030017460 S.CER C1005 JB 1H 102K-T T 95.1/9.7
C281 4030017440 S.CER C1005 CH 1H 221J-T T 86.8/10.6
C282 4030017440 S.CER C1005 CH 1H 221J-T T 85.9/10.6
C283 4030017400 S.CER C1005 CH 1H 220J-T T 86.4/7.6
C284 4030016930 S.CER C1005 JB 1A 104K-T T 86.4/13.4
C285 4030016930 S.CER C1005 JB 1A 104K-T T 86.4/14.3
C286 4030016930 S.CER C1005 JB 1A 104K-T T 86.4/15.2
C287 4030017460 S.CER C1005 JB 1H 102K-T T 89.9/17.6
C288 4030016930 S.CER C1005 JB 1A 104K-T T 89.9/18.5
C289 4030016930 S.CER C1005 JB 1A 104K-T T 95.2/18.0
C291 4030017350 S.CER C1005 CH 1H 020B-T T 81.1/15.9
C292 4030017350 S.CER C1005 CH 1H 020B-T T 82.0/18.0
C293 4030017460 S.CER C1005 JB 1H 102K-T T 69.8/12.7
C301 4030017550 S.CER C1005 CH 1H 1R5B-T B 128.1/42.0
C302 4030017360 S.CER C1005 CH 1H 030B-T B 129.8/42.0
C303 4030017380 S.CER C1005 CH 1H 050B-T B 129.0/41.0
C304 4030017540 S.CER C1005 CH 1H R75B-T B 127.2/39.6
C305 4030017540 S.CER C1005 CH 1H R75B-T B 127.2/37.9
C306 4030017560 S.CER C1005 CH 1H 2R5B-T B 128.6/37.8
C307 4030017380 S.CER C1005 CH 1H 050B-T B 128.6/36.9
C308 4030017340 S.CER C1005 CH 1H 010B-T B 127.2/36.2
C311 4030017460 S.CER C1005 JB 1H 102K-T B 128.6/32.5
C312 4030017460 S.CER C1005 JB 1H 102K-T B 126.3/32.2
C321 4030017500 S.CER C1005 CH 1H 560J-T B 124.7/30.0
C323 4030017400 S.CER C1005 CH 1H 220J-T B 124.7/30.9
C324 4030017460 S.CER C1005 JB 1H 102K-T B 124.7/31.8
C325 4030016930 S.CER C1005 JB 1A 104K-T B 124.7/32.7
C331 4030017460 S.CER C1005 JB 1H 102K-T B 126.0/27.5
C333 4030017610 S.CER C1005 CH 1H 090C-T B 120.5/18.6
C336 4030017460 S.CER C1005 JB 1H 102K-T B 112.9/17.6
C343 4030016790 S.CER C1005 JB 1E 103K-T B 117.0/16.3
C344 4030016790 S.CER C1005 JB 1E 103K-T B 113.9/14.8
C352 4030017390 S.CER C1005 CH 1H 180J-T B 127.5/26.4
C362 4030018910 S.CER C1608 JB 0J 475K-T T 109.3/10.8
C363 4030016790 S.CER C1005 JB 1E 103K-T T 111.2/10.5
C364 4030017420 S.CER C1005 CH 1H 470J-T T 112.5/11.0
C365 4030016930 S.CER C1005 JB 1A 104K-T T 115.9/15.8
C366 4030016930 S.CER C1005 JB 1A 104K-T T 116.8/15.8
C367 4030017460 S.CER C1005 JB 1H 102K-T T 114.2/11.0
C368 4030017460 S.CER C1005 JB 1H 102K-T T 114.7/9.7
C371 4030017390 S.CER C1005 CH 1H 180J-T T 108.2/18.0
C372 4030017660 S.CER C1005 CH 1H 330J-T T 109.1/18.0
C374 4030016930 S.CER C1005 JB 1A 104K-T T 111.2/18.0
C375 4030016930 S.CER C1005 JB 1A 104K-T T 106.2/13.9
C376 4030016930 S.CER C1005 JB 1A 104K-T T 106.2/15.3
C377 4030016930 S.CER C1005 JB 1A 104K-T T 106.7/12.5
C401 4030016790 S.CER C1005 JB 1E 103K-T T 117.6/13.0
C402 4030017460 S.CER C1005 JB 1H 102K-T T 120.9/13.0
C403 4030016930 S.CER C1005 JB 1A 104K-T T 125.8/19.8
C404 4030017460 S.CER C1005 JB 1H 102K-T T 122.3/10.3
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
R707 7030005050 S.RES ERJ2GEJ 103 X (10K) B 81.0/12.5
R708 7030004970 S.RES ERJ2GEJ 470 X (47) B 86.4/14.1
R711 7030008290 S.RES ERJ2GEJ 183 X (18K) B 88.2/6.3
R712 7030005060 S.RES ERJ2GEJ 333 X (33K) B 85.5/4.7
R713 7030005050 S.RES ERJ2GEJ 103 X (10K) B 86.4/4.7
R714 7030005050 S.RES ERJ2GEJ 103 X (10K) B 85.5/3.0
R715 7030005050 S.RES ERJ2GEJ 103 X (10K) B 84.6/3.0
R716 7030005120 S.RES ERJ2GEJ 102 X (1K) B 81.9/3.0
R717 7030005050 S.RES ERJ2GEJ 103 X (10K) B 81.0/4.7
R718 7030004970 S.RES ERJ2GEJ 470 X (47) B 87.3/6.3
R721 7030005090 S.RES ERJ2GEJ 104 X (100K) B 42.5/24.7
R722 7030011150 S.RES ERJ2GEJ 2R7 X (2.7) T 39.3/14.1
R723 7510001661 S.THR NTCG16 4LH 473JT T 66.5/7.0
R724 7030005090 S.RES ERJ2GEJ 104 X (100K) T 65.7/5.4
R734 7030005060 S.RES ERJ2GEJ 333 X (33K) T 31.7/18.6
R735 7030007340 S.RES ERJ2GEJ 153 X (15K) T 33.0/19.0
R736 7030005220 S.RES ERJ2GEJ 223 X (22K) B 17.9/15.7
R737 7030005600 S.RES ERJ2GEJ 273 X (27K) B 17.9/14.1
R738 7030005050 S.RES ERJ2GEJ 103 X (10K) B 17.6/12.8
R739 7030005240 S.RES ERJ2GEJ 473 X (47K) B 14.7/11.6
R740 7030005240 S.RES ERJ2GEJ 473 X (47K) B 13.1/18.7
R751 7030007340 S.RES ERJ2GEJ 153 X (15K) B 20.5/21.8
R752 7030005060 S.RES ERJ2GEJ 333 X (33K) B 18.6/20.5
R753 7030005220 S.RES ERJ2GEJ 223 X (22K) B 15.6/21.6
R754 7030005600 S.RES ERJ2GEJ 273 X (27K) B 15.6/20.7
R755 7030005050 S.RES ERJ2GEJ 103 X (10K) B 17.3/20.7
R758 7030005050 S.RES ERJ2GEJ 103 X (10K) B 7.1/14.2
R761 7030011150 S.RES ERJ2GEJ 2R7 X (2.7) B 7.4/30.5
R762 7030011150 S.RES ERJ2GEJ 2R7 X (2.7) B 7.4/31.4
R763 7030011150 S.RES ERJ2GEJ 2R7 X (2.7) B 7.4/23.9
R764 7030011150 S.RES ERJ2GEJ 2R7 X (2.7) B 7.4/24.8
R901 7030005090 S.RES ERJ2GEJ 104 X (100K) T 50.6/19.5
R902 7410001140 S.ARR EXB28V104JX B 47.2/44.8
R903 7030005120 S.RES ERJ2GEJ 102 X (1K) B 43.2/35.6
R904 7030011210 S.RES ERJ2GEJ 1R0 X (1) B 38.1/33.1
R905 7030011210 S.RES ERJ2GEJ 1R0 X (1) B 38.1/32.2
R906 7030005010 S.RES ERJ2GEJ 681 X (680) B 60.1/40.6
R907 7030005000 S.RES ERJ2GEJ 471 X (470) B 59.7/36.6
R911 7030005050 S.RES ERJ2GEJ 103 X (10K) B 43.7/40.2
R912 7030005050 S.RES ERJ2GEJ 103 X (10K) B 43.7/38.6
R921 7030011210 S.RES ERJ2GEJ 1R0 X (1) T 60.2/22.0
R922 7030005050 S.RES ERJ2GEJ 103 X (10K) T 56.0/29.0
R923 7030005080 S.RES ERJ2GEJ 823 X (82K) T 58.2/28.6
R924 7030005060 S.RES ERJ2GEJ 333 X (33K) T 60.3/29.0
C1 4030016930 S.CER C1005 JB 1A 104K-T T 74.0/16.4
C2 4550007520 S.TAN F931A106MAABMA T 72.9/14.3
C3 4550008150 S.TAN F921V224MAA B 78.0/20.5
C10 4030016930 S.CER C1005 JB 1A 104K-T T 71.0/15.9
C17 4030017460 S.CER C1005 JB 1H 102K-T B 89.5/35.2
C18 4030017460 S.CER C1005 JB 1H 102K-T T 91.9/32.0
C51 4030017610 S.CER C1005 CH 1H 090C-T T 75.0/18.8
C52 4030017610 S.CER C1005 CH 1H 090C-T T 72.4/18.3
C53 4030017460 S.CER C1005 JB 1H 102K-T T 70.6/18.3
C61 4030017460 S.CER C1005 JB 1H 102K-T B 62.4/45.5
C62 4030017460 S.CER C1005 JB 1H 102K-T B 67.6/47.6
C63 4030020310 S.CER GRM31CB31C106KA88L B 66.0/47.6
C71 4030017460 S.CER C1005 JB 1H 102K-T T 83.0/43.4
C72 4030017570 S.CER C1005 CH 1H 040B-T T 67.5/45.9
C75 4030017460 S.CER C1005 JB 1H 102K-T T 65.7/50.4
C81 4030017420 S.CER C1005 CH 1H 470J-T T 67.1/49.0
C82 4030017460 S.CER C1005 JB 1H 102K-T T 66.2/49.0
C83 4030017620 S.CER C1005 CH 1H 100C-T T 63.0/47.3
C84 4030017620 S.CER C1005 CH 1H 100C-T T 61.7/47.7
C89 4550008160 S.TAN F931A226MAA T 69.6/52.8
C91 4030017440 S.CER C1005 CH 1H 221J-T T 69.1/54.6
C92 4030017460 S.CER C1005 JB 1H 102K-T T 70.0/54.6
C93 4030017420 S.CER C1005 CH 1H 470J-T T 73.0/53.5
C94 4030017730 S.CER C1005 JB 1H 471K-T T 73.0/52.6
C95 4030017460 S.CER C1005 JB 1H 102K-T T 78.4/54.8
C96 4030011600 S.CER C1608 JB 1E 104K-T T 72.6/54.6
C97 4030020240 S.CER GRM31CR11C475KA01L T 80.0/53.2
C98 4030020240 S.CER GRM31CR11C475KA01L B 55.6/55.9
C111 4030020380 S.CER GRM21A5C2E180JW01D T 88.8/56.5
C112 4030020380 S.CER GRM21A5C2E180JW01D T 91.5/56.5
C113 4030020420 S.CER GRM21A7U2E102JW31D T 105.8/53.8
C114 4030020380 S.CER GRM21A5C2E180JW01D T 106.8/56.9
C115 4030004810 S.CER C2012 CH 1H 040C-T T 110.1/58.3
C116 4030020390 S.CER GRM21A5C2E270JW01D T 113.5/59.3
C121 4030020390 S.CER GRM21A5C2E270JW01D T 108.3/50.6
C122 4030017400 S.CER C1005 CH 1H 220J-T T 107.4/49.2
C125 4030017460 S.CER C1005 JB 1H 102K-T [USA] T 105.5/44.4
4030017460 S.CER C1005 JB 1H 102K-T [USA-01]
4030017460 S.CER C1005 JB 1H 102K-T [USA-02]
C126 4030017460 S.CER C1005 JB 1H 102K-T [USA] T 99.3/45.1
4030017460 S.CER C1005 JB 1H 102K-T [USA-01]
4030017460 S.CER C1005 JB 1H 102K-T [USA-02]
C127 4030017460 S.CER C1005 JB 1H 102K-T T 110.6/43.0
C130 4030017460 S.CER C1005 JB 1H 102K-T T 94.5/44.3
C131 4030017460 S.CER C1005 JB 1H 102K-T T 82.7/51.8
C132 4030017460 S.CER C1005 JB 1H 102K-T T 88.5/48.0
C133 4030017460 S.CER C1005 JB 1H 102K-T T 80.3/46.0
C134 4030017460 S.CER C1005 JB 1H 102K-T T 83.4/49.5
C135 4030017460 S.CER C1005 JB 1H 102K-T T 81.2/47.6
C136 4030017730 S.CER C1005 JB 1H 471K-T T 77.4/44.5
C137 4030017460 S.CER C1005 JB 1H 102K-T T 76.3/48.1
C138 4030017460 S.CER C1005 JB 1H 102K-T T 76.9/50.3
C140 4030016790 S.CER C1005 JB 1E 103K-T T 71.5/47.3
C141 4030017460 S.CER C1005 JB 1H 102K-T T 70.6/47.3
C143 4030016790 S.CER C1005 JB 1E 103K-T T 74.6/44.9
C151 4030020310 S.CER GRM31CB31C106KA88L B 101.4/28.2
C152 4030017460 S.CER C1005 JB 1H 102K-T B 106.9/21.3
C153 4030019560 S.CER GRM21BB31C106KE15L B 106.2/22.7
C160 4030016790 S.CER C1005 JB 1E 103K-T T 61.2/17.5
To Next Page
Loading...
Need help?
General
