Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
July 2013
(Additional page)
6
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
R99 7030010040 S.RES ERJ2GEJ-JPW [USA] T 112.4/43.0
7030010430 S.RES ERJ2GEJ 120 X (12) [UK]
7030010430 S.RES ERJ2GEJ 120 X (12) [EUR]
7030010430 S.RES ERJ2GEJ 120 X (12) [HOL]
7030010430 S.RES ERJ2GEJ 120 X (12) [FRG]
7030010040 S.RES ERJ2GEJ-JPW [USA-01]
7030010430 S.RES ERJ2GEJ 120 X (12) [UK-01]
7030010430 S.RES ERJ2GEJ 120 X (12) [EUR-01]
7030010430 S.RES ERJ2GEJ 120 X (12) [HOL-01]
7030010430 S.RES ERJ2GEJ 120 X (12) [FRG-01]
7030010040 S.RES ERJ2GEJ-JPW [USA-02]
7030010430 S.RES ERJ2GEJ 120 X (12) [EUR-02]
R100 7030009280 S.RES ERJ2GEJ 391 X [UK] T 112.9/44.3
7030009280 S.RES ERJ2GEJ 391 X [EUR]
7030009280 S.RES ERJ2GEJ 391 X [HOL]
7030009280 S.RES ERJ2GEJ 391 X [FRG]
7030009280 S.RES ERJ2GEJ 391 X [UK-01]
7030009280 S.RES ERJ2GEJ 391 X [EUR-01]
7030009280 S.RES ERJ2GEJ 391 X [HOL-01]
7030009280 S.RES ERJ2GEJ 391 X [FRG-01]
7030009280 S.RES ERJ2GEJ 391 X [EUR-02]
R101 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 104.7/25.7
R102 7030005030 S.RES ERJ2GEJ 152 X (1.5K) B 104.3/24.3
R103 7030005050 S.RES ERJ2GEJ 103 X (10K) B 104.0/19.6
R104 7030005120 S.RES ERJ2GEJ 102 X (1K) B 104.0/17.9
R116 7410001150 S.ARR EXB28V471JX T 57.9/14.8
R117 7030005050 S.RES ERJ2GEJ 103 X (10K) T 69.8/11.8
R118 7030010040 S.RES ERJ2GEJ-JPW T 68.5/12.2
R119 7030005240 S.RES ERJ2GEJ 473 X (47K) T 60.9/8.7
R120 7030005050 S.RES ERJ2GEJ 103 X (10K) T 61.3/10.1
R201 7030005110 S.RES ERJ2GEJ 224 X (220K) T 119.0/44.1
R202 7030005090 S.RES ERJ2GEJ 104 X (100K) T 119.0/46.9
R203 7030005240 S.RES ERJ2GEJ 473 X (47K) T 121.7/42.7
R204 7030005090 S.RES ERJ2GEJ 104 X (100K) T 120.8/42.7
R205 7030005710 S.RES ERJ2GEJ 121 X (120) T 126.0/46.5
R206 7030004990 S.RES ERJ2GEJ 221 X (220) T 125.8/44.5
R207 7030005580 S.RES ERJ2GEJ 560 X (56) T 121.0/46.9
R211 7030008300 S.RES ERJ2GEJ 184 X (180K) T 118.9/31.7
R212 7030007350 S.RES ERJ2GEJ 393 X (39K) T 118.9/32.6
R213 7030008300 S.RES ERJ2GEJ 184 X (180K) T 114.8/31.4
R214 7030005240 S.RES ERJ2GEJ 473 X (47K) T 114.3/33.0
R221 7030005530 S.RES ERJ2GEJ 100 X (10) T 119.9/28.1
R222 7030007290 S.RES ERJ2GEJ 222 X (2.2K) [USA] T 111.8/28.4
7030007300 S.RES ERJ2GEJ 332 X (3.3K) [UK]
7030007300 S.RES ERJ2GEJ 332 X (3.3K) [EUR]
7030007300 S.RES ERJ2GEJ 332 X (3.3K) [HOL]
7030007300 S.RES ERJ2GEJ 332 X (3.3K) [FRG]
7030007290 S.RES ERJ2GEJ 222 X (2.2K) [USA-01]
7030007300 S.RES ERJ2GEJ 332 X (3.3K) [UK-01]
7030007300 S.RES ERJ2GEJ 332 X (3.3K) [EUR-01]
7030007300 S.RES ERJ2GEJ 332 X (3.3K) [HOL-01]
7030007300 S.RES ERJ2GEJ 332 X (3.3K) [FRG-01]
7030007290 S.RES ERJ2GEJ 222 X (2.2K) [USA-02]
7030007300 S.RES ERJ2GEJ 332 X (3.3K) [EUR-02]
R223 7030007570 S.RES ERJ2GEJ 122 X (1.2K) T 110.9/26.5
R224 7030005030 S.RES ERJ2GEJ 152 X (1.5K) T 93.1/23.9
R225 7030005090 S.RES ERJ2GEJ 104 X (100K) T 93.1/22.1
R226 7030007300 S.RES ERJ2GEJ 332 X (3.3K) T 94.9/22.1
R227 7030004990 S.RES ERJ2GEJ 221 X (220) T 93.7/18.5
R229 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 107.2/33.5
R231 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 92.8/10.1
R232 7030005000 S.RES ERJ2GEJ 471 X (470) T 94.2/9.7
R233 7030004970 S.RES ERJ2GEJ 470 X (47) T 88.6/18.8
R234 7030005030 S.RES ERJ2GEJ 152 X (1.5K) T 88.2/17.6
R235 7030005050 S.RES ERJ2GEJ 103 X (10K) T 97.3/16.6
R236 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 99.7/18.1
R237 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 98.8/18.1
R238 7030004980 S.RES ERJ2GEJ 101 X (100) T 100.6/18.1
R239 7030005050 S.RES ERJ2GEJ 103 X (10K) T 101.5/18.1
R242 7030008410 S.RES ERJ2GEJ 392 X (3.9K) T 71.5/12.7
R251 7030005170 S.RES ERJ2GEJ 474 X (470K) T 86.4/12.0
R252 7030009270 S.RES ERJ2GEJ 821 X (820) T 86.8/8.9
R253 7030005060 S.RES ERJ2GEJ 333 X (33K) T 85.9/8.9
R256 7030005050 S.RES ERJ2GEJ 103 X (10K) T 75.9/7.0
R257 7030005050 S.RES ERJ2GEJ 103 X (10K) T 75.9/8.9
R261 7030003860 S.RES ERJ3GE JPW V T 127.9/40.8
R262 7030003860 S.RES ERJ3GE JPW V T 127.9/39.3
R263 7030003860 S.RES ERJ3GE JPW V T 127.9/36.8
R264 7030003860 S.RES ERJ3GE JPW V T 124.4/31.4
R301 7030005170 S.RES ERJ2GEJ 474 X (470K) B 127.2/34.0
R302 7030005090 S.RES ERJ2GEJ 104 X (100K) B 127.2/32.2
R303 7030005100 S.RES ERJ2GEJ 154 X (150K) B 128.9/28.6
R304 7030007350 S.RES ERJ2GEJ 393 X (39K) B 127.5/28.2
R305 7030005530 S.RES ERJ2GEJ 100 X (10) B 124.7/33.6
R306 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 124.6/27.2
R311 7030005010 S.RES ERJ2GEJ 681 X (680) B 126.0/25.8
R312 7030005010 S.RES ERJ2GEJ 681 X (680) B 111.2/17.6
R313 7030005090 S.RES ERJ2GEJ 104 X (100K) B 113.4/16.3
R314 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 118.8/16.3
R315 7030007280 S.RES ERJ2GEJ 331 X (330) B 116.6/14.8
R321 7030004970 S.RES ERJ2GEJ 470 X (47) T 113.0/18.0
R322 7030009140 S.RES ERJ2GEJ 272 X (2.7K) T 112.5/10.1
R323 7030005000 S.RES ERJ2GEJ 471 X (470) T 113.8/9.7
R324 7030005220 S.RES ERJ2GEJ 223 X (22K) T 110.0/18.0
R401 7030004970 S.RES ERJ2GEJ 470 X (47) T 119.3/13.0
R402 7030005160 S.RES ERJ2GEJ 105 X (1M) T 120.9/13.9
R403 7030006610 S.RES ERJ2GEJ 394 X (390K) T 122.2/14.4
R404 7030005060 S.RES ERJ2GEJ 333 X (33K) T 120.9/10.3
R405 7030007340 S.RES ERJ2GEJ 153 X (15K) T 123.2/10.3
R406 7030004980 S.RES ERJ2GEJ 101 X (100) T 125.8/14.4
R407 7030004970 S.RES ERJ2GEJ 470 X (47) T 123.1/14.4
R408 7030009290 S.RES ERJ2GEJ 562 X (5.6K) T 120.9/11.2
R411 7030005160 S.RES ERJ2GEJ 105 X (1M) T 128.3/18.6
R412 7030006610 S.RES ERJ2GEJ 394 X (390K) T 129.8/19.5
R413 7030005720 S.RES ERJ2GEJ 563 X (56K) T 131.2/21.6
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
R414 7030005240 S.RES ERJ2GEJ 473 X (47K) T 129.7/24.7
R415 7030005530 S.RES ERJ2GEJ 100 X (10) T 124.9/19.8
R416 7030004970 S.RES ERJ2GEJ 470 X (47) T 128.5/19.8
R417 7030005530 S.RES ERJ2GEJ 100 X (10) T 125.3/21.0
R501 7030012300 S.RES ERJ2RKF 1502X (15K) B 9.0/49.8
R502 7030011660 S.RES ERJ2RKF 1002 (10K) B 10.7/49.8
R503 7030011660 S.RES ERJ2RKF 1002 (10K) B 12.1/50.8
R504 7030007280 S.RES ERJ2GEJ 331 X (330) B 12.1/52.6
R505 7030007280 S.RES ERJ2GEJ 331 X (330) B 12.1/51.7
R506 7030005120 S.RES ERJ2GEJ 102 X (1K) B 10.7/48.9
R511 7030011150 S.RES ERJ2GEJ 2R7 X (2.7) T 42.2/43.6
R512 7030011150 S.RES ERJ2GEJ 2R7 X (2.7) T 37.7/43.6
R513 7030011150 S.RES ERJ2GEJ 2R7 X (2.7) T 41.2/43.6
R514 7030011150 S.RES ERJ2GEJ 2R7 X (2.7) T 40.7/51.0
R515 7030011150 S.RES ERJ2GEJ 2R7 X (2.7) T 41.7/51.0
R517 7030005240 S.RES ERJ2GEJ 473 X (47K) T 77.8/16.0
R521 7030005160 S.RES ERJ2GEJ 105 X (1M) B 30.9/33.5
R522 7030005160 S.RES ERJ2GEJ 105 X (1M) B 31.8/33.5
R523 7030005160 S.RES ERJ2GEJ 105 X (1M) B 30.0/33.5
R524 7030005160 S.RES ERJ2GEJ 105 X (1M) B 34.3/23.0
R525 7030005160 S.RES ERJ2GEJ 105 X (1M) B 32.5/23.0
R526 7030005160 S.RES ERJ2GEJ 105 X (1M) B 57.5/6.5
R527 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 34.4/34.0
R528 7030005530 S.RES ERJ2GEJ 100 X (10) B 34.4/34.9
R529 7030005060 S.RES ERJ2GEJ 333 X (33K) B 65.4/4.7
R530 7030005600 S.RES ERJ2GEJ 273 X (27K) B 65.4/5.6
R531 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 28.7/30.8
R532 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 27.8/30.8
R533 7030005530 S.RES ERJ2GEJ 100 X (10) B 67.5/7.1
R535 7030005090 S.RES ERJ2GEJ 104 X (100K) B 33.4/23.0
R537 7030005090 S.RES ERJ2GEJ 104 X (100K) B 30.0/23.0
R539 7030005160 S.RES ERJ2GEJ 105 X (1M) B 53.0/25.1
R540 7030005160 S.RES ERJ2GEJ 105 X (1M) B 55.9/15.6
R541 7030005090 S.RES ERJ2GEJ 104 X (100K) B 57.8/21.4
R544 7030005090 S.RES ERJ2GEJ 104 X (100K) B 52.8/14.7
R545 7030005110 S.RES ERJ2GEJ 224 X (220K) B 50.7/23.9
R547 7030005110 S.RES ERJ2GEJ 224 X (220K) B 71.4/15.1
R548 7030005090 S.RES ERJ2GEJ 104 X (100K) B 78.1/9.1
R549 7030005090 S.RES ERJ2GEJ 104 X (100K) B 72.2/5.7
R550 7030005220 S.RES ERJ2GEJ 223 X (22K) B 60.1/8.5
R551 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 58.7/5.4
R552 7030005530 S.RES ERJ2GEJ 100 X (10) B 60.3/4.5
R553 7030005090 S.RES ERJ2GEJ 104 X (100K) B 62.0/4.5
R554 7030005090 S.RES ERJ2GEJ 104 X (100K) B 62.0/5.6
R555 7030008290 S.RES ERJ2GEJ 183 X (18K) B 59.5/11.5
R556 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 60.4/11.5
R557 7030008300 S.RES ERJ2GEJ 184 X (180K) B 60.4/13.2
R558 7030005240 S.RES ERJ2GEJ 473 X (47K) B 60.4/14.9
R559 7030005530 S.RES ERJ2GEJ 100 X (10) B 59.5/13.2
R560 7030005240 S.RES ERJ2GEJ 473 X (47K) B 59.5/14.9
R561 7030005210 S.RES ERJ2GEJ 822 X (8.2K) B 58.6/13.2
R562 7030008400 S.RES ERJ2GEJ 182 X (1.8K) B 63.4/16.9
R563 7030005100 S.RES ERJ2GEJ 154 X (150K) B 61.7/16.9
R564 7030008290 S.RES ERJ2GEJ 183 X (18K) B 61.7/16.0
R565 7030005030 S.RES ERJ2GEJ 152 X (1.5K) B 67.0/11.2
R566 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 67.0/12.9
R567 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 71.2/11.7
R568 7030005170 S.RES ERJ2GEJ 474 X (470K) B 63.8/19.1
R569 7030010040 S.RES ERJ2GEJ-JPW B 60.3/5.4
R571 7030005090 S.RES ERJ2GEJ 104 X (100K) B 70.5/17.8
R581 7030005530 S.RES ERJ2GEJ 100 X (10) B 50.7/19.5
R582 7030005530 S.RES ERJ2GEJ 100 X (10) B 50.7/22.2
R583 7030005530 S.RES ERJ2GEJ 100 X (10) B 70.5/15.1
R584 7030005160 S.RES ERJ2GEJ 105 X (1M) B 69.6/15.1
R585 7030005070 S.RES ERJ2GEJ 683 X (68K) B 71.8/16.4
R601 7030005090 S.RES ERJ2GEJ 104 X (100K) B 10.4/39.5
R602 7030005240 S.RES ERJ2GEJ 473 X (47K) B 10.4/37.8
R611 7030007340 S.RES ERJ2GEJ 153 X (15K) T 24.9/28.8
R612 7030007340 S.RES ERJ2GEJ 153 X (15K) T 25.8/30.6
R621 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 24.7/21.0
R622 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 22.4/19.9
R623 7030005080 S.RES ERJ2GEJ 823 X (82K) B 26.9/20.0
R624 7030005080 S.RES ERJ2GEJ 823 X (82K) B 23.8/19.3
R625 7030005070 S.RES ERJ2GEJ 683 X (68K) B 23.8/17.6
R626 7030005120 S.RES ERJ2GEJ 102 X (1K) B 22.9/15.8
R627 7030012750 S.RES ERJ2RHD 2202X (22.0K) B 22.0/17.6
R628 7030011120 S.RES ERJ2RHD 2702X (27.0K) B 22.9/17.6
R629 7030005050 S.RES ERJ2GEJ 103 X (10K) B 22.0/15.8
R630 7030005110 S.RES ERJ2GEJ 224 X (220K) B 24.7/13.1
R632 7030005530 S.RES ERJ2GEJ 100 X (10) B 27.7/10.7
R633 7030005170 S.RES ERJ2GEJ 474 X (470K) B 23.8/15.8
R634 7030005170 S.RES ERJ2GEJ 474 X (470K) B 24.7/16.7
R635 7030005030 S.RES ERJ2GEJ 152 X (1.5K) B 28.4/7.2
R641 7030005050 S.RES ERJ2GEJ 103 X (10K) B 31.7/17.5
R642 7030005120 S.RES ERJ2GEJ 102 X (1K) B 31.7/16.6
R643 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 32.5/19.3
R644 7030005530 S.RES ERJ2GEJ 100 X (10) B 32.5/18.4
R645 7030010040 S.RES ERJ2GEJ-JPW B 31.2/18.8
R647 7030007340 S.RES ERJ2GEJ 153 X (15K) B 29.8/10.7
R661 7030005000 S.RES ERJ2GEJ 471 X (470) T 50.7/27.1
R662 7030009280 S.RES ERJ2GEJ 391 X T 55.6/31.9
R663 7030005090 S.RES ERJ2GEJ 104 X (100K) T 54.2/31.5
R664 7410001150 S.ARR EXB28V471JX T 51.3/29.2
R671 7030005600 S.RES ERJ2GEJ 273 X (27K) T 39.2/21.9
R672 7030005220 S.RES ERJ2GEJ 223 X (22K) T 38.3/21.9
R673 7030005110 S.RES ERJ2GEJ 224 X (220K) T 38.8/20.6
R676 7030005600 S.RES ERJ2GEJ 273 X (27K) T 48.1/20.7
R677 7030005220 S.RES ERJ2GEJ 223 X (22K) T 49.0/20.7
R678 7030005110 S.RES ERJ2GEJ 224 X (220K) T 48.5/19.4
R701 7030008290 S.RES ERJ2GEJ 183 X (18K) B 87.3/14.1
R702 7030005060 S.RES ERJ2GEJ 333 X (33K) B 85.5/12.4
R703 7030005050 S.RES ERJ2GEJ 103 X (10K) B 86.4/12.4
R704 7030005050 S.RES ERJ2GEJ 103 X (10K) B 85.5/10.7
R705 7030005050 S.RES ERJ2GEJ 103 X (10K) B 84.6/10.7
R706 7030005120 S.RES ERJ2GEJ 102 X (1K) B 81.9/10.7
To Next Page
Loading...
Need help?
General
