SPECIFICATIONS AND OPTIONS
23
■ Specifications
GENERAL
• Frequency coverage:
Receive 500 kHz–29.999 MHz
Transmit 1.6– 2.9999 MHz 4.0– 4.9999 MHz
6.0– 6.9999 MHz 8.0– 8.9999 MHz
12.0– 13.9999 MHz 16.0–17.9999 MHz
18.0– 19.9999 MHz 22.0–22.9999 MHz
25.0– 27.5000 MHz
• Mode: USB, AM, CW, FSK and AFSK
(
available modes differ with version)
• Number of channels: 150 channels (max.)—
3 groups of 50
channels each
• Antenna impedance: 50 Ω nominal
• Usable temp. range: –30°C to +60°C (–22°F to +140°F)
• Frequency stability: ±10 Hz
(–30°C to +60°C; –22°F to +140°F)
(±20 Hz above 15 MHz for General and
Marine versions)
• Power supply requirement: 13.6 V DC±15%
(negative and floating grounds
available depending on version)
• Current drain:
Transmit
(max. output power) 30 A
Receive
(max. audio output) 2.5 A (negative ground)
• Dimensions: 291.4(W)×116.4(H)×315(D) mm
11.3(W)×4.4(H)×12.8(D) in
• Weight: 7.9 kg; 17.4 lb
(negative ground)
TRANSMITTER
• Output power: 150 W
PEP
(60 W above 24 MHz)
• Spurious emissions: –75 dB
typical
• Carrier suppression: 65 dB
typical
• Unwanted sideband suppression: 70 dB typical
• Microphone impedance: 600 Ω
RECEIVER
• Sensitivity
USB, CW, AFSK, FSK,
(for 12 dB SINAD):
0.35 µV
typical (1.8–29.9999 MHz)
1.0 µV (1.6–1.7999 MHz)
6.3 µV (0.5–1.5999 MHz)
AM (for 10 dB S/N)
:
2.2 µV
typical (1.8–29.9999 MHz)
6.3 µV (1.6–1.7999 MHz)
32 µV (0.5–1.5999 MHz)
• Spurious response rejection: 80 dB
typical (1.6–29.9999 MHz)
• Audio output power: 5.0 W (at 10% distortion with a 4 Ω load)
• Audio impedance: 4 to 8 Ω
• Clarity variable range: ±150 Hz
■ Options
AT-130 AUTOMATIC
ANTENNA TUNER
MN-100
ANTENNA MATCHER
MN-100L
ANTENNA MATCHER
HS-50 HANDSET
Matches the transceiver to a
long wire antenna with a mini-
mum of insertion loss.
Matches the transceiver to a
dipole antenna. Covers all HF
bands from 1.5 to 30 MHz.
8m × 2 antenna wires come
attached.
Matches the transceiver to a
long wire antenna. Covers all
HF bands from 1.5 to 30 MHz.
15 m × 1 antenna wire comes
attached.
Provides better audio recep-
tion during offshore conditions
and comes in handy for listen-
ing privacy on board.
PS-60 DC POWER SUP-
PLY
PS-66 DC-DC CON-
VERTER
FL-100
CW/FSK NARROW FILTER
Provides 13.6 V DC (30 A)
output from an AC outlet.
Provides 13.6 V DC (30 A)
output from a 19–32 V DC
power source.
Allows better receiver selectiv-
ity for CW and FSK.
Bandwidth: 500 Hz/–6 dB
UT-95 2-TONE ALARM UNIT
Provides an alarm transmis-
sion for emergency use during
maritime operation.
All stated specifications are subject to change without notice
or obligation.
