Icom IC-PW1 Instruction Manual

IMPORTANT ...................................................... i
PRECAUTION ................................................... i
EXPLICIT DEFINITIONS ................................. ii
TABLE OF CONTENTS .................................. ii
SUPPLIED ACCESSORIES ............................ ii
1 PANEL DESCRIPTION ............................ 1–4
■ Front panel and remote controller ..................... 1
■ Rear panel ....................................................... 3
2 INSTALLATION AND CONNECTIONS 5–10
■ Unpacking ........................................................ 5
■ Ferrite core installation .................................... 5
■ OPC-853 AC cable with line filter .................... 5
■ Selecting a location ......................................... 5
■ AC power cable connection .............................. 5
■ Grounding ........................................................ 6
■ Antenna ........................................................... 6
■ System interconnections .................................. 7
■ Separating the remote controller ................... 11
3
OPERATION ......................................... 12–17
■ When first applying power (CPU resetting) ... 12
■ Setting the ALC levels ................................... 12
■ Programming the CI-V address ..................... 13
■ Initial settings for CI-V remote control operation
....................................................................... 14
■ Operation ....................................................... 16
■ Antenna tuner operation ................................ 17
■ Protection circuit ............................................ 17
4 MAINTENANCE ......................................... 18
■ Troubleshooting ............................................. 18
5 SPECIFICATIONS ..................................... 19
ABOUT CE ................................................ 20
EXPLICIT DEFINITIONS
SUPPLIED ACCESSORIES
TABLE OF CONTENTS
ii
qwerty
i
o
u
Accessories included with the IC-PW1/EURO: Qty.
q Accessory cable (OPC-104B) .............................. 1
w Coaxial cable (OPC-125B) .................................. 1
e Separation cable (OPC-730) ............................... 1
r Remote control (CI-V) cable (OPC-718) .............. 1
t Remote controller feet ......................................... 2
y Grounding lug ...................................................... 1
u Dummy panel screws .......................................... 2
i Dummy panel ...................................................... 1
o Cable ties ............................................................. 2
WORD DEFINITION
RWARNING
Personal injury, fire hazard or elec-
tric shock may occur.
CAUTION Equipment damage may occur.
NOTE
If disregarded, inconvenience only.
No risk of personal injury, fire or
electric shock.
The explicit definitions described at left apply to this in-
struction manual.

Icom IC-PW1 Specifications

General

Brand	Icom
Model	IC-PW1
Category	Amplifier
Language	English
