1 - 1
SECTION 1 SPECIFICATIONS
■ GENERAL
• Frequency coverage :
Guaranteed frequency range: *144–148 MHz
• Mode : FM (F2, F3)
• Current drain
(at 9.6 V DC) : Transmit at 6.0 W 1.6 A (typical)
at 5.0 W 1.5 A (typical) [Thailand]
at 1.0 W 0.7 A (typical)
Receive max. audio 210 mA (typical)
power saved 25 mA (typical)
standby 80 mA (typical)
• Frequency stability : ±10 ppm
(0˚C to +50˚C; 32˚F to 122˚F)
• Usable temperature range : –10˚C to 60˚C; 14˚F to 140˚F
• Antenna connector : BNC (50 Ω)
• No. of memory channels : 43 ch (40 regulator, 2 scan edges and 1 call)
• Acceptable power supply : 9.6 V DC (supplied Ni-Cd cells; negative ground)
• Frequency resolution : 5 kHz and 12.5 kHz
• Dimensions (Projections not included) : 58(W)
× 140.5(H) × 32.3(D) mm; 2
9
⁄32(W) × 5
17
⁄32(H) × 1
9
⁄32(D) inch
• Weight
(with BP-199) : 420 g; 14.8 oz
■ TRANSMITTER
• Output power (9.6 V DC) : 6 W typical (high)
5 W typical (high) [Thailand] only
0.7 W typical
(low)
• Modulation system : Variable reactance frequency modulation
• Max. frequency deviation : ±5 kHz
• Spurious emissions : Less than –60 dB
• External microphone connector : 3-conductor 2.5 (d) mm (
1
⁄10”) ⁄ 2 kΩ
■ RECEIVER
• Receive system : Double conversion superheterodyne
• Intermediate frequencies : 1st 30.85 MHz
2nd 450 kHz
• Sensitivity
(12 dB SINAD) : Less than 0.18 µV (–122 dBm)
• Squelch sensitivity
(threshold) : Less than 0.18 µV (–122 dBm)
• Selectivity : More than 15 kHz/–6 dB
Less than 30 kHz/–60 dB
• Spurious and image refection ratio : 60 dB (typical)
(except 2nd IF image frequency)
• Audio output power (at 9.6 V DC) : 500 mW (typical at 10% distortion with an 8 Ω load)
• External speaker connector : 3-conductor 3.5 (d) mm (
1
⁄8”) ⁄ 8 Ω
All stated specifications are subject to change without notice or obligation.
U.S.A.
Europe, U.K.
Thailand
Italy, Asia,
ANI, C.S.A.
Taiwan
140.000–150.000 MHz*
144.000–146.000 MHz
136.000–174.000 MHz*
145.000–146.000 MHz
136.000–174.000 MHz*
144.000–146.000 MHz
136.000–174.000 MHz*
145.000–146.000 MHz
Version Transmit Receive
