6 - 2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[MAIN-C UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R98 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 99/22.1
R100 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
T 74.4/22.5
R101 7030004990 S.RES ERJ2GEJ 221 X (220) T 77.1/28.7
R103 7030005230 S.RES ERJ2GEJ 334 X (330 k
)
B 46.2/38.1
R104 7030005700 S.RES ERJ2GEJ 274 X (270 k
)
B 47.2/38.1
R105 7030005230 S.RES ERJ2GEJ 334 X (330 k
)
B 46.2/39.7
R106 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 47.2/39.7
R108 7030010040 S.RES ERJ2GEJ-JPW B 65.2/37.7
R109 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 63.2/35.3
R110 7030005080 S.RES ERJ2GEJ 823 X (82 k
)
T 69.3/20.7
R111 7030006610 S.RES ERJ2GEJ 394 X (390 k
)
T 66.6/35.2
R115 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
T 83.4/25.9
R116 7030007060 S.RES ERJ2GEJ 684X (680 k
)
T 80.7/25.5
R121 7030005060 S.RES ERJ2GEJ 333 X (33 k
)
B 68.9/41.3
R122 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 101.1/40.3
R123 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 99.5/41.3
R125 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 39.8/6.2
R126 7030004980 S.RES ERJ2GEJ 101 X (100) B 23.2/4.5
R127 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
)
B 33.7/10.9
R128 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
)
B 33.7/9.2
R129 7030005720 S.RES ERJ2GEJ 563 X (56 k
)
B 35.7/9.2
R133 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 35.4/5.3
R134 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 43.9/8.5
R135 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
)
B 43.9/9.5
R136 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 40.7/9.5
R137 7030005080 S.RES ERJ2GEJ 823 X (82 k
)
B 45/12.8
R138 7030005000 S.RES ERJ2GEJ 471 X (470) B 45/14.5
R139 7030008310 S.RES ERJ2GEJ 564 X (560 k
)
B 43.8/16.6
R140 7030005700 S.RES ERJ2GEJ 274 X (270 k
)
B 42.1/16.6
R141 7030010040 S.RES ERJ2GEJ-JPW B 37.4/18.6
R142 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
)
B 36.7/9.2
R143 7030005100 S.RES ERJ2GEJ 154 X (150 k
)
B 33.7/16
R144 7030005230 S.RES ERJ2GEJ 334 X (330 k
)
B 37.4/17.5
R145 7030005100 S.RES ERJ2GEJ 154 X (150 k
)
B 34.7/17.7
R146 7030005060 S.RES ERJ2GEJ 333 X (33 k
)
B 34.7/16
R147 7030005100 S.RES ERJ2GEJ 154 X (150 k
)
B 35.7/17.7
R148 7030005000 S.RES ERJ2GEJ 471 X (470) B 37.4/16.3
R149 7030005100 S.RES ERJ2GEJ 154 X (150 k
)
B 33.7/17.7
R150 7030007060 S.RES ERJ2GEJ 684X (680 k
)
B 43.8/15.7
R151 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
B 35/38.5
R152 7030005230 S.RES ERJ2GEJ 334 X (330 k
)
B 34.1/42.9
R153 7030005310 S.RES ERJ2GEJ 124 X (120 k
)
B 35.9/42.9
R154 7030005080 S.RES ERJ2GEJ 823 X (82 k
)
B 35.9/41.3
R155 7030005720 S.RES ERJ2GEJ 563 X (56 k
)
B 35.9/37.1
R156 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 48.1/16.4
R157 7030004980 S.RES ERJ2GEJ 101 X (100) B 30.1/8
R158 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
B 37.9/37.1
R159 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 35.9/39.7
R160 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 35/39.7
R161 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 48/19.3
R162 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
B 48/18.4
R163 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 87.6/11.9
R164 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 85.7/10.5
R165 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 102.6/14.7
R166 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
B 101.2/24.6
R167 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 48.2/6.3
R168 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 49.1/6.3
R169 7030004980 S.RES ERJ2GEJ 101 X (100) B 101.2/25.5
R172 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 87.6/30.8
R181 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 57/6.3
R182 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 57/8
R183 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 55.2/8
R184 7030007340 S.RES ERJ2GEJ 153 X (15 k
)
B 53.4/10
R185 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
)
B 52.4/10
R186 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 57/10
R187 7030005070 S.RES ERJ2GEJ 683 X (68 k
)
B 55.2/12.8
R188 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 53.4/8
R190 7030007570 S.RES ERJ2GEJ 122 X (1.2 k
)
B 54.3/12.8
R194 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 58.4/22.5
R195 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 60.2/23.5
R196 7030007350 S.RES ERJ2GEJ 393 X (39 k
)
B 60.2/24.4
R197 7030005080 S.RES ERJ2GEJ 823 X (82 k
)
B 60.2/26.7
R198 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
B 56.6/24.4
R199 7030006610 S.RES ERJ2GEJ 394 X (390 k
)
B 58.4/24.4
R200 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
)
B 58.4/25.4
R201 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 97/39.1
R202 7030005000 S.RES ERJ2GEJ 471 X (470) T 97/38.1
R209 7030005070 S.RES ERJ2GEJ 683 X (68 k
)
B 47.2/41.3
R210 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 46.2/42.9
R211 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 46.2/41.3
R213 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
B 42.2/37
R214 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 44.2/37
R215 7030005070 S.RES ERJ2GEJ 683 X (68 k
)
B 54.8/32
R216 7030005070 S.RES ERJ2GEJ 683 X (68 k
)
B 56.6/32
R217 7030005070 S.RES ERJ2GEJ 683 X (68 k
)
B 60.2/30
R218 7030005070 S.RES ERJ2GEJ 683 X (68 k
)
B 60.2/32
R219 7030007350 S.RES ERJ2GEJ 393 X (39 k
)
B 58.4/33
R220 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 60.2/34
R221 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 48.2/39.7
R222 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
B 7/19.3
R223 7030005720 S.RES ERJ2GEJ 563 X (56 k
)
B 7/20.3
R224 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 7/21.3
R225 7030007260 S.RES ERJ2GEJ 330 X (33) T 94.4/20.7
R226 7030005300 S.RES ERJ2GEJ 150 X (15) T 94.5/16
R227 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
)
T 97.4/22.5
R228 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
)
T 95.6/22.5
[MAIN-C UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R229 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 95.4/26.7
R230 7030005230 S.RES ERJ2GEJ 334 X (330 k
)
B 33.9/22.6
R231 7030005100 S.RES ERJ2GEJ 154 X (150 k
)
B 33.9/21.6
R233 7030004980 S.RES ERJ2GEJ 101 X (100) T 98.7/12.1
R234 7030005530 S.RES ERJ2GEJ 100 X (10) T 103.3/16.8
R235 7030005000 S.RES ERJ2GEJ 471 X (470) T 80.5/8
R236 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
T 77.2/8.5
R237 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
)
T 78.8/5.5
R238 7030005000 S.RES ERJ2GEJ 471 X (470) B 85.7/5.4
R239 7030007340 S.RES ERJ2GEJ 153 X (15 k
)
B 26.3/19.5
R240 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 50.4/26.4
R241 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
B 50.4/28.6
R242 7030005230 S.RES ERJ2GEJ 334 X (330 k
)
B 50.4/27.6
R244 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 53/24.4
R245 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
B 50.4/25.4
R246 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 45.8/32.1
R247 7030005000 S.RES ERJ2GEJ 471 X (470) B 45.8/35.1
R248 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 43.9/5.3
R249 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 45.2/21.2
R254 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 58.4/34
R255 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
B 56.6/33
R256 7510001730 S.TMR ERTJOEP 473J B 18.7/39.4
R257 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 18.7/37.4
R258 7030005530 S.RES ERJ2GEJ 100 X (10) B 26.3/31.4
R259 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
B 26.3/32.4
R260 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
B 27.7/31.3
R261 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
B 26.3/29.4
R262 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
B 26.3/28.4
R263 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 16.8/41.4
R264 7030005820 S.RES RR0510P-103-D (10 k
)
B 10.7/4.7
R265 7030005820 S.RES RR0510P-103-D (10 k
)
B 8.8/4.7
R272 7030004980 S.RES ERJ2GEJ 101 X (100) T 55.5/4.8
R273 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
B 7.3/10.5
R274 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
B 7.3/11.6
R275 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
B 7.4/14
R276 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
B 7.4/16.2
R277 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
B 10.1/36.7
R278 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
B 11.1/36.7
R279 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 12.8/4.7
R280 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 14.2/4.7
R281 7030009270 S.RES ERJ2GEJ 821 X (820) B 20.5/4
R288 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
B 6.6/18
R291 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 9.9/15.4
R292 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 5.5/31.5
R293 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 5.5/32.5
R295 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
T 62.1/14.1
R300 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
T 61.7/16.4
R302 7030006610 S.RES ERJ2GEJ 394 X (390 k
)
T 73.5/26.8
R303 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
T 73.6/25.6
R304 7030010040 S.RES ERJ2GEJ-JPW B 72.5/31.8
R305 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
T 68.3/32.6
R306 7030005530 S.RES ERJ2GEJ 100 X (10) B 68.5/24.3
R307 7030005580 S.RES ERJ2GEJ 560 X (56) T 84.5/35.2
R308 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
T 69.3/21.6
R309 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 48.2/41.3
R315 7210003061 VAR TP76N00N-15F-A103-2251A
R321 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 14.5/41.4
R345 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 81.9/39.3
R346 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 82.8/39.3
R347 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 83.7/39.3
R348 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 84/30.1
R349 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 26.3/23
R350 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 8.5/29.1
R351 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 26.3/21.6
R352 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 7.6/27.6
R353 7410001130 S.ARY EXB28V102JX B 12.1/15.7
R354 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 11.9/34.3
R361 7030008370 S.RES ERJ2GEJ 561 X (560) B 88.6/24.4
R363 7030005100 S.RES ERJ2GEJ 154 X (150 k
)
T 84/27.7
R364 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
B 29.4/14.9
R367 7030004980 S.RES ERJ2GEJ 101 X (100) B 23.7/9.9
R368 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 42.2/5.3
R369 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 35.4/4.4
R370 7030010040 S.RES ERJ2GEJ-JPW B 10.2/17
R371 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
)
B 27.3/11.4
R372 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
B 27.3/14.4
R375 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 35.7/12.6
R377 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 47.2/23.6
R378 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 48.8/28.6
R379 7030004980 S.RES ERJ2GEJ 101 X (100) T 68.2/7.5
C16 4550007120 S.TAN F92 1D 224MPA T 75.3/33.6
C17 4550002980 S.TAN TEESVA 1C 225M8R T 77.3/36.1
C19 4030017520 S.CER ECJ0EC1H0R3B [UK-02] only B 86.5/32.5
C21 4030017530 S.CER ECJ0EC1H0R5B B 99.8/32.2
C22 4030017540 S.CER ECJ0EC1HR75B B 98.4/32.7
C23 4030017630 S.CER ECJ0EC1H120J B 97.1/33.8
C24 4030017460 S.CER ECJ0EB1E102K B 98.4/36.4
C25 4030017360 S.CER ECJ0EC1H030B B 98.4/31.8
C26 4030017460 S.CER ECJ0EB1E102K B 50.4/24.4
C27 4030017630 S.CER ECJ0EC1H120J B 99.8/33.8
C28 4030017530 S.CER ECJ0EC1H0R5B B 93.9/33.6
C29 4030017570 S.CER ECJ0EC1H040B B 93.5/32.4
C30 4030017460 S.CER ECJ0EB1E102K B 90/29.9
C31 4030017420 S.CER ECJ0EC1H470J B 98/37.6
