4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[MAIN-C UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
C332 4030017460 S.CER ECJ0EB1E102K T 80.5/4.6
C333 4550006250 S.TAN TEESVA 1A 106M8R T 83.1/3.4
C334 4030016930 S.CER ECJ0EB1A104K T 76.3/8.5
C335 4030018860 S.CER ECJ0EB0J105K B 54.8/24.4
C338 4030016930 S.CER ECJ0EB1A104K B 45.8/34.1
C339 4030016790 S.CER ECJ0EB1C103K B 45.8/30.2
C340 4030016930 S.CER ECJ0EB1A104K B 10.2/17.9
C345 4030016930 S.CER ECJ0EB1A104K B 18.7/38.4
C346 4030017600 S.CER ECJ0EC1H080C B 27.7/32.9
C347 4030017640 S.CER ECJ0EC1H150J B 26.3/33.4
C348 4030017400 S.CER ECJ0EC1H220J B 26.3/30.4
C349 4030016930 S.CER ECJ0EB1A104K B 25.1/29.4
C350 4030016930 S.CER ECJ0EB1A104K B 27.7/27.1
C351 4030016930 S.CER ECJ0EB1A104K B 26.6/27.1
C352 4030017030 S.CER ECJ0EB1A273K B 23.5/41.4
C353 4030016930 S.CER ECJ0EB1A104K B 9.7/4.7
C354 4030016790 S.CER ECJ0EB1C103K B 5.5/30.5
C355 4030017460 S.CER ECJ0EB1E102K B 52.7/5
C357 4030018910 S.CER C1608 JB 0J 475K-T B 29.1/23
C359 4030016930 S.CER ECJ0EB1A104K B 21.7/38.4
C360 4030017420 S.CER ECJ0EC1H470J B 20.2/34.4
C361 4030016930 S.CER ECJ0EB1A104K B 20.2/33.4
C368 4030017730 S.CER ECJ0EB1E471K B 53/25.4
C369 4030016930 S.CER ECJ0EB1A104K B 48.8/27.6
C370 4030016930 S.CER ECJ0EB1A104K B 48.7/25.4
C371 4030016930 S.CER ECJ0EB1A104K B 50.4/29.6
C372 4030018860 S.CER ECJ0EB0J105K B 48.7/26.4
C373 4030018860 S.CER ECJ0EB0J105K B 47.4/32.1
C375 4030017460 S.CER ECJ0EB1E102K B 100/14.7
C376 4030017420 S.CER ECJ0EC1H470J T 95.5/14.3
C377 4030017460 S.CER ECJ0EB1E102K B 26.6/24.2
C379 4030017460 S.CER ECJ0EB1E102K B 87.3/5.4
C384 4030018100 S.CER ECJ0EB1H681K T 61.7/15.5
C386 4030016930 S.CER ECJ0EB1A104K T 58.6/13.3
C387 4030016930 S.CER ECJ0EB1A104K T 60.9/14.6
C388 4030016930 S.CER ECJ0EB1A104K T 60.9/13.7
C390 4030016930 S.CER ECJ0EB1A104K T 78/18.8
C391 4030016930 S.CER ECJ0EB1A104K B 65/19.1
C392 4030016930 S.CER ECJ0EB1A104K B 65.8/15
C393 4030016930 S.CER ECJ0EB1A104K T 78/15.6
C394 4030016930 S.CER ECJ0EB1A104K T 70.6/15.2
C395 4030017420 S.CER ECJ0EC1H470J B 89/29.9
C396 4030017350 S.CER ECJ0EC1H020B B 90.9/18.2
C397 4030017350 S.CER ECJ0EC1H020B B 90.9/19.3
C398 4030017460 S.CER ECJ0EB1E102K B 68.3/34.4
C399 4550007120 S.TAN F92 1D 224MPA T 66.6/33
C400 4030017460 S.CER ECJ0EB1E102K B 72.2/27.2
C401 4030018860 S.CER ECJ0EB0J105K B 71.2/27.3
C402 4030017460 S.CER ECJ0EB1E102K T 97.2/26.7
C406 4030016930 S.CER ECJ0EB1A104K B 45.2/42.9
C409 4030016930 S.CER ECJ0EB1A104K B 14.1/34.4
C410 4030016930 S.CER ECJ0EB1A104K B 11.9/33.4
C412 4030017420 S.CER ECJ0EC1H470J T 80.5/6.4
C413 4030017780 S.CER ECJ0EB1E472K T 76.3/19.8
C420 4030017380 S.CER ECJ0EC1H050B T 86.1/20.7
C421 4550006780 S.TAN TEESVB2 0J 476M8R B 29.7/41.3
C422 4550006780 S.TAN TEESVB2 0J 476M8R B 53.5/16.4
C423 4030017730 S.CER ECJ0EB1E471K B 94.5/25.3
C424 4030016790 S.CER ECJ0EB1C103K B 60.2/22.5
C425 4030016790 S.CER ECJ0EB1C103K T 66.8/16.9
C426 4030016790 S.CER ECJ0EB1C103K B 65.8/17.3
C427 4030016930 S.CER ECJ0EB1A104K B 27.3/13.4
C428 4550006250 S.TAN TEESVA 1A 106M8R B 31/16.9
C429 4550006250 S.TAN TEESVA 1A 106M8R B 31.7/7.5
C430 4030016930 S.CER ECJ0EB1A104K B 28.3/8
C432 4030016930 S.CER ECJ0EB1A104K B 60.2/28.7
C433 4030016930 S.CER ECJ0EB1A104K B 27.3/12.4
C434 4030017420 S.CER ECJ0EC1H470J B 31.3/3.5
C435 4030018920 S.CER ECJ0EB1H392K T 67.6/20.7
C437 4030017460 S.CER ECJ0EB1E102K T 67.2/5.4
J2 6450002250 CNR HSJ1456-010320
J3 6450000131 CNR HSJ1102-018540 [UK-02] only
J4 6510021900 S.CNR BM02B-ASRS-TF T 89.4/4.5
J5 6510025220 S.CNR AXK540145J B 16.3/10.3
J7 6510024740 S.CNR IPS-4039T-02B (4039T-01Y901) B 92.6/25.7
DS1 5010000160 S.LED LNJ310M6URA T 57.3/5.9
DS2 5010000160 S.LED LNJ310M6URA T 57.3/40.3
DS3 5030002760 LCD L3-0200HAY-3 (-4)
MC1 7700002480 MIC SKB-2746 LPC
S1 2230001060 S.SW EVQ-PUL 02K T 102.2/36.1
S2 2260002840 SW SKHLLFA010
S3 2260002800 S.SW SW-167 (SKQTLAE010) B 61.1/44.2
S4 2260002800 S.SW SW-167 (SKQTLAE010) B 51.6/44.2
S5 2260002800 S.SW SW-167 (SKQTLAE010) B 99.6/44.2
EP1 6910015370 S.BEA ACZ1005Y-102-T B 76.2/30.3
EP3 6910015370 S.BEA ACZ1005Y-102-T B 58.4/36.3
[MAIN-C UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
EP6 6910015370 S.BEA ACZ1005Y-102-T T 80/28.2
EP7 8930063020 LCT SRCN-2721-SP-N-W
EP11 6910015370 S.BEA ACZ1005Y-102-T T 75.7/3.1
EP12 6910015370 S.BEA ACZ1005Y-102-T T 69.1/7.5
EP13 0880001930 UBD EX-2887
[PA-C UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC701 1110002751 S.IC TA75S01F (TE85R F) B 20.3/19.8
Q701 1560001231 S.FET RD07MVS1-T112 B 22.6/8.3
Q702 1560001241 S.FET RD01MUS1-T113 B 16/8.2
Q703 1530000371 S.TR 2SC3356-T1B S (R25) T 11.4/14.2
Q704 1530003260 S.TR 2SC5006-T1 T 6.6/8.9
D701 1750000581 S.DIO 1SV307 (TPH3 F) T 31.5/15.4
D702 1790001670 S.DIO RB706F-40T106 T 23.2/17.5
D704 1790001260 S.DIO MA2S077-(TX) B 28.6/16
D705 1790001240 S.DIO MA2S728-(TX) T 26.8/20.3
L701 6200002431 S.COL NLV25T-082J T 27.8/16.4
L703 6200009470 S.COL 0.40-0.9-2TL T 28.1/13.5
L704 6200009470 S.COL 0.40-0.9-2TL T 24.1/14.1
L705 6200008240 S.COL 0.30-0.9-5TL 14N B 19.4/13.6
L706 6200003590 S.COL EXCCL3225U1 T 14.3/19.1
L707 6200005691 S.COL ELJRE 18NGFA T 12.2/16.8
L708 6200005741 S.COL ELJRE 47NGFA T 6.7/13.1
L709 6200008430 S.COL 0.20-1.0-4TL 15N T 31.4/11.7
L710 6200008430 S.COL 0.20-1.0-4TL 15N T 34.4/11.4
L712 6200009070 S.COL LQW18AN18NG00D B 31.3/16.1
L713 6200010910 S.COL LQW18AN56NG00D B 28.3/20.1
R701 7030008280 S.RES ERJ2GEJ 271 X (270) T 27.6/18.9
R702 7030008280 S.RES ERJ2GEJ 271 X (270) T 28.5/18.9
R703 7030005080 S.RES ERJ2GEJ 823 X (82 k
)
B 34.4/16.9
R704 7030005530 S.RES ERJ2GEJ 100 X (10) T 18.4/2.6
R705 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
T 16.9/2.1
R706 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
T 14.5/2.6
R707 7030010040 S.RES ERJ2GEJ-JPW B 19/11.1
R708 7030004990 S.RES ERJ2GEJ 221 X (220) B 11.4/11.7
R710 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
B 9.8/11.7
R712 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
T 13.6/14.5
R715 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
T 6.8/11.7
R719 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
)
T 26/17.3
R720 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 22.7/15.7
R721 7030008280 S.RES ERJ2GEJ 271 X (270) B 22.5/19.1
R722 7030005600 S.RES ERJ2GEJ 273 X (27 k
)
B 21.9/17.7
R724 7030005080 S.RES ERJ2GEJ 823 X (82 k
)
B 21/22.1
R725 7030006610 S.RES ERJ2GEJ 394 X (390 k
)
B 19.2/17.6
R726 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 17.7/18.8
R727 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 16.4/18.4
R728 7030004970 S.RES ERJ2GEJ 470 X (47) B 19.2/22.3
C701 4030017460 S.CER ECJ0EB1E102K T 29.5/15.4
C702 4030017420 S.CER ECJ0EC1H470J T 30.5/18.2
C703 4030017460 S.CER ECJ0EB1E102K T 29.5/18.2
C705 4030017380 S.CER ECJ0EC1H050B T 29.5/13.6
C707 4030017460 S.CER ECJ0EB1E102K T 21.3/17.2
C708 4030017460 S.CER ECJ0EB1E102K T 25.1/17.3
C709 4030017370 S.CER ECJ0EC1H3R5B T 26.7/13.8
C710 4030007030 S.CER C1608 CH 1H 150J-T T 20.8/13.8
C711 4030017570 S.CER ECJ0EC1H040B T 25.8/13.8
C712 4030007040 S.CER C1608 CH 1H 180J-T T 22.3/13.8
C715 4030017460 S.CER ECJ0EB1E102K B 15.4/13.1
C716 4030017460 S.CER ECJ0EB1E102K B 14.4/13.1
C718 4030017460 S.CER ECJ0EB1E102K T 15.9/2.1
C719 4030016790 S.CER ECJ0EB1C103K B 13.4/13.1
C720 4030017420 S.CER ECJ0EC1H470J B 19/8.4
C722 4030017420 S.CER ECJ0EC1H470J B 16.4/13.1
C723 4030017460 S.CER ECJ0EB1E102K B 9.8/10.7
C724 4030017460 S.CER ECJ0EB1E102K B 6.9/14.1
C725 4030017420 S.CER ECJ0EC1H470J T 14.5/13.7
C726 4030017460 S.CER ECJ0EB1E102K T 15.5/13.7
C727 4030017460 S.CER ECJ0EB1E102K T 16.5/13.7
C729 4030017580 S.CER ECJ0EC1H060C B 10.6/13.1
C731 4030017360 S.CER ECJ0EC1H030B T 7.8/14.2
C732 4030017460 S.CER ECJ0EB1E102K T 5/11.7
C733 4030017360 S.CER ECJ0EC1H030B T 5.4/10.5
C734 4030017420 S.CER ECJ0EC1H470J B 5.7/11.1
C735 4030017360 S.CER ECJ0EC1H030B T 6.2/14.2
C736 4030017530 S.CER ECJ0EC1H0R5B T 7/10.5
C737 4030017530 S.CER ECJ0EC1H0R5B T 9.2/13.7
C738 4030017420 S.CER ECJ0EC1H470J T 14.1/15.9
C742 4030017460 S.CER ECJ0EB1E102K T 31.6/13.4
C744 4030017580 S.CER ECJ0EC1H060C T 30.4/13.5
C745 4030017360 S.CER ECJ0EC1H030B T 32.9/11.8
C746 4030017610 S.CER ECJ0EC1H090C T 31.5/10.2
