ICON MOTOSPORTS ALLIANCE MANUAL
ICON MOTOSPORTS ALLIANCE HELMET
SUPERVENT SYSTEM
The Alliance helmet’s ventilation system consist of strategically placed
air intakes, vents, air channels, and exhaust ports. The main ingredient
in venting the Alliance is the Icon Supervent system featuring oversized
intake ports controlled by individual vent triggers, along with recessed
supervents to reduce wind noise. When activated, air is forced directly into
the helmet, at both high and low speeds. Air is channeled between the
comfort liner and protective EPS liner, expelling through the exhaust ports
for maximum comfort.
To activate the supervent system simply slide the vent triggers
shown in Fig #2a to the back position. To activate the center
mouth vent in Fig #1a, fl ip the vent open by pushing up on the
vent trigger.
Fine tuning of airfl ow into the helmet is handled by the mouth
vent, internal chin bar airports, and side vent exhaust holes.
Represented in Fig #3a & 3b.
