ICON EDGE USER MANUAL
26
9.7.2. Manual Control
With this function, you can adjust the lamp more easily. All effects will be canceled, the shutter opens
and the dimmer intensity will be set to 100 %. With the individual functions, you can focus the light on
a flat surface (wall) and perform the fine lamp adjustment.
1． Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until“Test”is
displayed. Press ENTER.
2． Press <Up/Down>, the display will show “Manual control”.
3． Press< ENTER>, the display will show “Manual control”.
4． The display show “PAN”. Use <Up/Down> to select parameters.
5． Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
9.7.3. Calibration
With this function, you can calibrate and adjust the effect wheels to their correct positions. The
password of calibrate values is 050.
1． Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until“Test”is
displayed. Press ENTER.
2． Press <Up/Down>, until the display shows “Calibration”.
3． Press< ENTER>, the display will show “Calibration”.
4． The display shows“Password”, Enter Password and Press <Enter>
5． Press <Up/Down>, the display will show“Pan”, “Tilt”, “Strobe”, “Color Wheel”……
6． Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu.
9.7.4. Lens Cleaning Mode
1． Tap <MODE/ESC>button，access the main menu，Tap the <Up/Down>button until“Test”is
displayed. Press ENTER Tap the <Up/Down>button until“Clean Mode”is displayed.
2． Press ENTER.
3． Press <Up/Down>, until the display shows “Clean Focus”, “Clean 8 Prism” , “Clean Line Prism”
or “Clean Zoom”.
4． Press ENTER to confirm or press <MODE/ESC> to return to the main menu.
10. DMX PROTOCOL
DMX channel´s functions and their values ( 36 DMX channels):
Mode/Channel Value Function
St Ex
1 1
PAN Movement 8bit :
0-255 Pan Movement
2 2
Pan Fine 16bit
0-255 Fine control of Pan movement
3 3
TILT Movement 8bit :
0-255 Tilt Movement
4 4
Tilt Fine 16bit
0-255 Fine control of Tilt movement
5 5
Color Wheel and colour change to
any position:
0-209
Colour change to any position
13-15
Color 1
27-29
Color 2
41-43
Color 3
