ICON EDGE USER MANUAL
28
82-91 Rot. gobo 7
92-101 Rot. gobo 8
102-112 Rot. gobo 1 shake
113-123 Rot. gobo 2 shake
124-134 Rot. gobo 3 shake
135-145 Rot. gobo 4 shake
146-156 Rot. gobo 5 shake
157-167 Rot. gobo 6 shake
168-178 Rot. gobo 7 shake
179-189 Rot. gobo 8 shake
190-221 Clock-wise scroll from fast to slow
222-223
No rotation
224-255 Counter clock-wise scroll from slow to fast
12 17
Rotating gobo index, rotating gobo rotation :
0-127 Gobo indexing
128-189
Clock-wise rotation from fast to slow
190-193 No rotation
194-255
Counter clock-wise rotation from slow to fast
18
Rotating gobo indexing Fine
0-255 Fine indexing
13 19
Fixed Gobos :
0-7 Open/hole
8-14 Gobo 1
15-21 Gobo 2
22-28 Gobo 3
29-35 Gobo 4
36-42 Gobo 5
43-49 Gobo 6
50-56 Gobo 7
57-63 Gobo 8
64-70 Gobo 9
71-77 Gobo 10
78-84 Gobo 11
85-91 Gobo 12
92-98 Gobo 13
99-105 Gobo 14
106-111 Gobo 1 shake slow to fast
112-117 Gobo 2 shake slow to fast
118-123 Gobo 3 shake slow to fast
124-129 Gobo 4 shake slow to fast
130-135 Gobo 5 shake slow to fast
136-141 Gobo 6 shake slow to fast
142-147 Gobo 7 shake slow to fast
