ICON EDGE USER MANUAL
29
148-153 Gobo 8 shake slow to fast
154-159 Gobo 9 shake slow to fast
160-165 Gobo 10 shake slow to fast
166-171 Gobo 11 shake slow to fast
172-177 Gobo 12 shake slow to fast
178-183 Gobo 13 shake slow to fast
184-189 Gobo 14 shake slow to fast
190-221 Clock-wise scroll from fast to slow
222-223 No rotation
224-255 Counter clock-wise scroll from slow to fast
14 20
Wheel Animation :
0-7 Close
8-127
Animation indexing
128-187
Clock-wise scroll from fast to slow
188-195
No rotation
196-255
Counter clock-wise scroll from slow to fast
15 21
8/Linear Prism:
0-63 Open position (hole)
64-127 8 Prism
128- 191 Linear Prism
192- 255 8/Linear Prism
16 22
Rotating 8 prism index, rotating prism
rotation
0-127 Prism indexing
128-189 Clock-wise rotation from fast to slow
190-193 No rotation
194-255 Counter clock-wise rotation from slow to fast
23
Rotating 8 prism indexing Fine
0-255 Fine indexing
17 24
Rotating linear prism index, rotating prism
rotation
0-127 Prism indexing
128-189 Clock-wise rotation from fast to slow
190-193 No rotation
194-255 Counter clock-wise rotation from slow to fast
25
Rotating linear prism indexing Fine
0-255 Fine indexing
18 26
Zoom :
0-255 Zoom adjustment from small to big
27
Zoom Fine:
0-255 Zoom adjustment Fine
19 28
Focus :
0-255 Continuous adjustment from near to far
