Tips: DAW button could not be activated if a DAW software is running.
(Note: We will update Qcon Pro firmware from time to time to support additional DAW apart from
the current existing list. Please check our official website to download and upgrade your Qcon Pro
firmware).
Tips: Qcon Pro will memorise your last selected DAW mode and re-enter the same mode a few
seconds after it has been switched on. (i.e. DAW mode selection is not needed if the last mode is
being used.)
Sub-control buttons
This section of control buttons varies in different DAWs. Qcon Pro is based on
TM
Logic for the settings.
(Note: For different DAWs the labeling may not be perfectly matched.)
9
9a)
9b)
10
6
Assignment section
TRACK button -Activate the track parameters of the software.
PAN/EQ/Send/Plug-in/Instrument buttons -These buttons are used to activate
the corresponding effect function of the DAW. They are typically used in
conjunction with the rotary encoder knobs. Press the button, its light will turn
on, and then rotate the rotary encoder knob to adjust the value, which will
display on the LCD directly above.
Automation section
GROUP - Press to enter “Group” edit mode.
READ/Off button - Press the READ button to activate the read function of the
current audio track.
WRITE button - Press the WRITE button to activate the write function of the
current audio track.
TOUCH button - Press to set selected track's automation to Touch.
LATCH - Press to set selected track's automation to Latch.
TRIM - Currently unassigned.
User-defined control buttons
This section of control buttons is user-defined in Mackie control mode (HUI mode).
You may set their parameters according to your personal needs. PVC labeling
mask is included for noting the set parameters.
