Product Specifications(Cooling & Heating)
Items Unit HMH012KD HMH018KD HMH024KD
Power Supply ø, V, Hz 1,230/208,60 1,230/208,60 1,230/208,60
Cooling Capacity BTU/h 12,000/11,800 18,000/17,800 23,000/22,600
Heating Capacity BTU/h 12,000/11,800 19,000/18,700 23,000/22,600
Input Cooling W 1,260/1,240 1,900/1,870 2,550/2,500
Heating W 1,260/1,240 1,900/1,870 2,550/2,500
Running Current Cooling A 5.7/6.2 8.5/9.0 11.5/12.0
Heating A 5.7/6.2 8.5/9.0 11.5/12.0
COMP. Locked Cooling A 27 49.5 68
Rotor AMP. Heating A 27 49.5 68
E.E.R BTU/hW 9.5/9.5 9.5/9.5 9.0/9.0
C.O.P 2.78/2.78 2.9/2.9 2.6/2.6
Air Circulation Indoor(Dry) m
3
/min(cfm) 10(350) 13(460) 15(530)
Outdoor(Dry) m
3
/min(cfm) 25(882) 46(1,610) 46(1,610)
Moisture Removal l/h(pts/hr) 1.7(3.63) 2.5(5.3) 3.1(6.6)
Noise Level Indoor, High dB(A) 41 47 49
(Sound Med dB(A) 39 43 45
Pressure, 1m) Low dB(A) 37 40 42
Outdoor, Max dB(A) 53 57 58
Features Temperature Control Thermistor Thermistor Thermistor
AUTO Wind Yes Yes Yes
Air Deflection 4-way 4-way 4-way
Steps, Fan/Cool/Heat 3/3/3 3/3/3 3/3/3
Airflow Direction Control(up&down) Auto Auto Auto
Airflow Direction Control(left&right) Manual Manual Manual
Remocon Type Wireless LCD Wireless LCD Wireless LCD
Setting Temperature Range, Cooling Mode 64~86°F 64~86°F 64~86°F
Heating Mode 60~86°F 60~86°F 60~86°F
Temperature Increment 2°F 2°F 2°F
Auto Operation(electronic control) Yes Yes Yes
Self Diagnosis Yes Yes Yes
Timer 24hr, On/Off 24hr, On/Off 24hr, On/Off
Sleep Operation Yes Yes Yes
Soft Dry Operation Yes Yes Yes
Restart Delay minutes 3 3 3
Defrost Control Yes Yes Yes
Hot Start Yes Yes Yes
Refrigerant(R-22) Charge g(oz) 1,250(44.1) 1,500(52.9) 1,600(56.4)
Power cord AWG #: P*mm
2
14:3*2.1 14:3*2.1 14:3*2.1
Fuse or breaker Capacity A 15A 15A 20A
Connecting Cable AWG #: P*mm
2
18:4*0.82 18:4*0.82 18:4*0.82
Connecting Tube Liquid Side mm(in) 6.35(1/4) 9.52(3/8) 9.52(3/8)
(ø. Socket Flare) Gas Side mm(in) 12.7(1/2) 15.88(5/8) 15.88(5/8)
Length, std m(ft) 7.62(25) 7.62(25) 7.62(25)
Additional Drain Hose(Inner Dia.) mm(in) 16(5/8) 16(5/8) 16(5/8)
Dimensions Indoor mm 900*290*183 1080*290*183 1080*290*183
(WxHxD) in 35.4*11.4*7.2 42.5*11.4*7.2 42.5*11.4*7.2
Outdoor mm 801*555*262 870*655*320 870*655*320
in 31.5*21.8*10.3 34.3*25.8*12.6 34.3*25.8*12.6
Net Weight Indoor kg(lbs) 10(22) 12(26.5) 12(26.5)
Outdoor kg(lbs) 35(77) 55(121) 65(143)
* Design and Specifications subject to change without prior notice for product improvement.
