(1) Indoor Unit
- 7 -
Dimensions
D
W
H
Tubing hole cover
Tubing hole cover
Installation plate
MODEL
9K, 12K 18K, 24K
DIM
W mm(inch) 900(35.4") 1,080(42.5")
H mm(inch) 290(11.4") 290(11.4")
D mm(inch) 183(7.2") 183(7.2")
