(3) DISPLAY PWB ASSY
- 61 -
<9K, 12K>
<18K, 24K>
LD1
LD2 LD4
LD3
R.ASM
6046AQ3020A
2
J1
LD1 LD2
CN-MAIN
LD3 LD4
1 7
REMOCN
RECEIVER
P.C.B
ASM
6870AQ3148A
6870AQ3149A
(P/No: 6047AQ3021E)
(P/No: 6871AQ3149A)
