WATER CHILLERS

OPERATING AND MAINTENANCE MANUAL

iC 215 ÷ iC 780

38178800943

Original instructions in Italian language

Table of Contents

Questions and Answers:

S
sgomezAug 8, 2025
Why is the ICS iC 408 tank water outlet temperature too high?
- A
  Anthony HumphreyAug 8, 2025
  If the tank water outlet temperature (BTWOT) of your ICS Chiller is higher than the prescribed value, it could be due to several reasons. First, the thermal load might be too high; in this case, try to restore the thermal load to the prescribed limits. Secondly, the ambient temperature might be too high; if the unit is in an enclosed space, improve ventilation to reduce the ambient temperature to the recommended level. Also, check if the condenser fins are dirty and clean them if necessary. Ensure that the front surface of the condenser isn't blocked; if it is, remove the obstruction. Finally, it may be due to refrigerant fluid leak or compressor protection trips; in such cases, call a qualified refrigeration engineer to check for and fix any leaks and recharge the circuit.
N
Nicole RodriguezAug 21, 2025
What to do if there is insufficient pressure head at the ICS iC 408 pump outlet?
- P
  Philip JordanAug 22, 2025
  If you're experiencing insufficient water pressure at the pump outlet of your ICS Chiller, it could be due to an excessively high water flow rate. Try restoring the flow rate to the prescribed limits, perhaps by partially closing the pump outlet cock. Also, reset the pump thermal cutout and check the electrical power consumption. Alternatively, the evaporator might be clogged by impurities. Clean the evaporator by flushing it with a mild detergent suitable for steel, aluminum, and copper, and supply a high flow rate of water in countercurrent conditions. Consider installing a filter upstream from the unit.

ICS iC 408 Specifications

General

Brand	ICS
Model	iC 408
Category	Chiller
Language	English

Summary

User's Quick Guide

Unit Start/Stop Procedures

How to switch the unit on and off locally or via digital input.

Setpoint Adjustment

Steps to display and modify the chiller setpoint.

Alarm Handling

Process for displaying and resetting unit alarms.

Chapter 2 Safety

General Safety Rules

Essential safety precautions for installation, use, and maintenance.

User Circuit Liquid Safety

Lifting and Transport Safety

Installation Safety Precautions

Operational Safety

Maintenance Safety

Refrigerant Gas Safety

Information and safety data for R410A refrigerant.

Chapter 5 Installation

Inspection and Location Advice

Freeze Protection Measures

Operating Limits Definition

Hydraulic and Electrical Connections

Instructions for connecting hydraulic and electrical systems.

Chapter 6 Starting

Pre-Startup Checks

Unit Startup Procedure

Step-by-step guide for starting the unit.

Chapter 7 Electronic Controller

User Interface and Buttons

Overview of controller display, icons, and button functions.

Unit Start/Stop and Setpoint

Procedures for unit power control and setpoint adjustment.

Dynamic Setpoint Function

Circuit Value Display & Functions Menu

Alarm Management

Procedures for displaying, resetting, and muting alarms.

General Alarms List

Parameter Access and Families

How to access parameter menus and overview of parameter families.

Hot-Key Programming

Compressor Control Modes

Fan Control Modes

Detailed Parameter Settings

Comprehensive list and settings of controller parameters across various models.

Chapter 9 Operation and Maintenance

Basic Unit Operation

Accessing Unit Components

Process Water Circuit Draining

Maintenance Schedule

Recommended routine maintenance tasks and frequency.

Chapter 10 Troubleshooting

Troubleshooting Common Issues

Detailed guide to diagnosing and resolving common problems.

Chapter 11 Risk Analysis: Residual Risk

Risk Assessment and Mitigation

Identifies risks and provides user instructions for safety.
