Dual frequency version (50Hz/60Hz):
NOTE
The values in the table may vary in relation to the unit model and configuration. In this case refer to the offer data.
NOTE
The pressure head is the pressure head available in the user’s premises. The installed pump my differ with respect to the
standard pump. For the flow rate and pressure head values two numbers are specified: the first refers to nominal conditions
and the second refers to maximum conditions.
Model iC 660 iC 770 iC 780
Tank
capacity
water volume (litres) 500 678 678
Pump P3
water flow rate
(m
3
/h)
9.4/48 12.5/56 14.9/56
pump pressure
head
(bar) 3.8/1.5 3.3/2.5 3.3/2.5
rated power (kW) 4 5.5 5.5
Pump P5
water flow rate
(m
3
/h)
9.4/48 12.5/72 14.9/72
pump pressure
head
(bar) 5.5/3.1 4.8/3.4 4.8/3.4
rated power (kW) 7.5 9.2 9.2
Axial flow
fan
No. of fans 2 3 3
total airflow
(m
3
/h)
42800 63900 62100
High
pressure
axial flow
fan
No. of fans 2 3 3
residual
pressure
(Pa) 172 191 176
total airflow
(m
3
/h)
40000 60000 60000
Model iC 215 iC 220 iC 303 iC 305 iC 408 iC 410 iC 412 iC 416
Tank
capacity
water volume (litres) 60 60 115 115 140 255 255 255
Pump P3
water flow rate
(m
3
/h)
0.4/4.8 0.4/4.8 0.4/4.8 0.4/4.8 2.3/9.0 2.3/9.0 3.5/16.2 3.5/16.2
50 Hz pump
pressure head
(bar) 3.1/2.0 3.1/2.0 3.1/2.0 3.1/2.0 3.1/1.9 3.1/1.9 2.4/2.0 2.4/2.0
60 Hz pump
pressure head
(bar) 4.5/3.4 4.5/3.4 4.5/3.4 4.5/3.4 4.5/3.2 4.5/3.2 3.5/3.1 3.5/3.1
rated power (kW) 1.1 1.1 1.1 1.1 2.2 2.2 2.2 2.2
Axial flow
fan
No. of fans 11111222
total airflow
(50 Hz)
(m
3
/h)
3500 3150 6500 6150 8150 14200 13600 13600
total airflow
(60 Hz)
(m
3
/h)
4750 4200 7700 6100 9900 16900 16000 16000
