ICS IL Series - Dimensional Drawings; Ordering Example

Dimensional drawing series ILW
Dimensional drawing series ILK
83
57
83
41,5
12
40220
1
15
40
18
26
57
1
15
83
8350
12
Ordering Example
L K K M 0V F1 48 5 05 00G
Series:
IL Series
Design:
Duct version
Physical outputs:
active outputs
Output signals:
MODBUS RTU
Operation conditions / special versions:
Sealing against vibrations
Measured variable and output range 1:
Measured variable and output range 2:
Supply voltage:
5...30 V DC
Measuring head / Filter / Diameter:
PTFE sintered lter ZE05 / 12 mm
Description of design
Duct version, sensor tube length = 220 mm
