4
© 2024 ICS, Oregon Tool, Inc. Specications and pricing are subject to change without notice. REV07102024 - p/n 646325
SAW CONFIGURATION
Blade Capacity
12 in / 355 mm 14-16 in / 508 mm 18-24 in / 660 mm 26 - 36 in / 762 mm
Max. Cutting Depth
5 in / 127 mm
6-7 in / 152-177
mm
11 in / 279 mm 13 in / 330 mm
Engine rpm
2,800 3,200 3, 400 3,600*
Gearbox Output
rpm After 300 rpm
Cut Load
3,600 2,500 1,800 1,200
Blade Shaft Arbor
1 in / 25.4 mm
Blade Flange
4 in / 101.6 mm
Drive Speed
245 feet/min 74 meters/min
Engine Pulley
4.1 in / 104.14 mm
Gearbox Pulley
4.75 in / 120.65
*36-inch blade only for M500 front pivot series saw, not recommended for use with M500SS series
SPECIFICATIONS
OEM Harness Fuses
Location Function Fuse Size Fuse Type
Positive Battery Terminal Alternator fuse 60 Amps ZCASE
Positive Battery Terminal Fan fuse 60 Amps ZCASE
Positive Battery Terminal ECU power supply 40 Amps ZCASE
VIC inline Night light fuse 10 Amps ATO
VIC inline Main VIC power supply 15 Amps ATO
WARNING
Only use fuses listed below. Fuses are designed to protect electrical circuits from
overloading and prevent fires. Using the wrong type or rating of fuse can lead to
electrical malfunctions, overheating, and potentially fire hazards.
