Battery
Group
SLI51
CCA/CA
450
RELAY 1 RELAY 2 RELAY 3
F6 F7
F8 F9
F10
F1 F2 F3 F4 F5
ENGINE FUSE BOX
ENGINE OE HARNESS FUSES AND RELAYS
POSITION ITEM FUNCTION AMPS/VOLTS TYPE
RELAY 1 Relay Fuel Pump 12V CB1A-T-R-12V
RELAY 2 Relay Power 12V CB1A-T-R-12V
RELAY 3 Relay Starter 12V CB1A-T-R-12V
F1 Fuse ECM 10 A Mini
F2 Fuse VSW 5 A Mini
F3 Fuse Starter 30 A Mini
F4 Fuse Fuel Pump 15 A Mini
F5 Fuse Empty - Mini
F6 Fuse Ignition 15 A Mini
F7 Fuse Empty - Mini
F8 Fuse Empty - Mini
F9 Fuse Empty - Mini
F10 Fuse Empty - Mini
