8
1.11. Function Keys & Other Details
A. Switch Buttons
Photo/Video Switch GSM Switch
Power Switch IR LEDs Group Switch
1) Switch ON to enable camera to work;
Note: indicator light flashes 5 times in front of the camera.
Camera is activated now in PIR (PIR Auto Mode);
2) Switch ON, then press “OK” once to wake up camera LCD screen to
enter TEST Mode;
3) Press and hold button “OK” for 3 sec to get back to PIR Auto Mode;
4) Switch OFF — Camera stops working;
Switch to Photo Icon, to activate „Photo mode“ or „Photo- & Video
mode“ only. Switch to Video Icon to activate “Video Recording mode”
only..
Note: When video mode is selected the sending of photo’s via GSM is
disabled.
Switch up: 25—up side 25 pcs IR LEDs work;
Switch down: 56—all 56 pcs IR LEDs work;
Switch up: ON—GSM function enabled;
Switch down: OFF—GSM function disabled;
Note: When user wants to configure camera settings, suggest disabling
GSM function to quick wake up LCD screen.
