V SERIES USER’S MANUAL
11
Chapter 3 Features
Product Parameters
Model V-12 V-24 V-30 V-48
Structure desktop
desktop/
(optional stands)
desktop/
(optional stands)
Stands
(with stands)
Max media width 415mm 720mm 850mm 1300mm
Max cutting width 305mm 610mm 740mm 1220mm
Main board DSP Microprocessor 64 M flash memory
Interface RS232C,USB
Control penal 10silica gel buttons
Driver Digital DC, servo motor
Display 4*8 high resolution LCD
Drawing instruction HP-GL,HP-GL/2,DMPL
Max cutting speed 950mm/s
Max cutting thickness 1mm
pressure
50g~800g （200 grades digital Adjustable）
Mechanical precision 0.014mm
Repeatable precision 0~0.1mm
Power supply AC90~240V/50Hz~60Hz
Positioning model < 100VA
Working model Roller
Operational environment
+5 ~ +35℃℃，relative humidity 30%~70%
Net weight 9kg 12kg 15.4kg 17.5kg
Gross weight 12.3kg 16kg 17kg 39kg
Dimension 585*265*270 890*265*270 1020*265*270 1530*265*270
Package Dimension 715*380*395 1015*380*395 1085*380*395 1575*370*430
