Remove the long arm cover by unscrewing the 2 6-32 flathead screws
using a philips head screwdriver.
Remove the end covers by unscrewing the 2 10-24
flathead screws using the 1/8” hex key.
Run the cords along the arm all the way
through the cord channel up into the ceiling mount.
Replace the three covers on the arm, being
careful not to pinch the cords.
Feed the cords through the plastic bushing
in the end covers. The plastic bushing can
be removed, opened and slipped over
cord if necessary.
3
