Icy Box IB-M2HSF-703 User Manual

Please read carefully the following information to prevent injuries, damage to
material and device as well as data loss:
Warning levels
Signal words and safety codes indicate the warning level and provide immediate information in terms of the
probability of occurrence as well as the type and severity of the consequences if the measures to prevent
hazards are not complied with.
Warns of a directly hazardous situation causing death or serious injury.
Warns of a potentially hazardous situation that may cause death or serious
injury.
Warns of a potentially hazardous situation that may cause minor injury.
Warns of a potential situation that may cause material or environmental
damage and disrupt operative processes.
1. Risk of electrical shock
Contact with parts conducting electricity
Risk of death by electrical shock
• Read the operating instructions prior to use
• Make sure the device has been de-energised prior to working on it
• Do not remove contact p otection panels
• Avoid contact with conducting parts
• Do not bring plug contacts in contact with pointed and metal objects
• Use in intended environments only
• Operate the device using a power unit meeting the specifications of the type plate only!
• Keep the device/power unit away from humidity, liquid, vapour and dust
• Do not modify the device
• Do not connect the device during thunderstorms
• Approach specialist retailers if you require repairs
2. Hazards during assembly (if intended)
Sharp components
Potential injuries to fingers or hands during assembly (if intended)
• Read the operating instructions prior to assembly
• Avoid coming into contact with sharp edges or pointed components
• Do not force components together
• Use suitable tools
• Use potentially enclosed accessories and tools only
DANGER
WARNING
CAUTION
IMPORTANT
WARNING
CAUTION
Safety Information Safety Information

Icy Box IB-M2HSF-703 Specifications

General

Type	Heatsink/Radiatior
Fan diameter	20 mm
Number of speeds	1
Quantity per pack	1 pc(s)
Suitable location	Solid-state drive
Thermal conductivity	1.5 W/m·K
Rotational speed (max)	10000 RPM
Operating temperature (T-T)	-20 - 180 °C
Material	Aluminium, Silicone
Fan connector	4-pin
Product color	Black, Grey
Number of fans	1 fan(s)
Number of fins	8
Thermal pad included	Yes
Voltage	12 V
Harmonized System (HS) code	84733080

Weight and Dimensions

Depth	24 mm
Width	75 mm
Height	13 mm
Weight	51 g
Package depth	200 mm
Package width	105 mm
Package height	27 mm
Package weight	123 g
Fan dimensions (W x D x H)	20 x 20 x 6 mm
