4
Section 4
SPECIFICATION KEYBOARD
MECHANCIAL
Keyswitch
Total Travel 4.0 + 0.5 mm
Operating Force 50 + 7g
Keyboard Housing
Color Black or Cream White
Size 469.9 mm (L) x 203.9 mm (W) x 42.8
mm (H)
Material ABS
Cable Information
Jacket Material PVC jacket with Aluminum Shielding
Length 1.5 M (5ft.) Overall
PC Connector PS/2 or USB
Drop 610 mm (24”) Drop: 1 corner, 2-sidelines,
3-sides
Vibration 60 Hz/sec 3 mm amplitude X,Y,Z each
axis at 2 hours
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 40°C (- 4°F to 104°F)
ELECTRICAL
Power Requirement +5.0 VDC ±10%, 60ma Max
Industry Requirements FCC class B and CE
RELIABILITY
Operating Life 20,000,000 keystrokes
ESD Immunity 0KV to 8 kV min, without data loss.
8KV to 15 kV min, will function after
reset
MTBF More than 60,000 power on hours
