Ideal Air PRO - Installation Summary: Indoor Unit

6
Select Installation Location
(Page 9)
And Drill Wall Hole
(Page 10)
1
Attach Mounting Plate
(Page 10)
2
Prepare Refrigerant Piping
(Page 12)
4
3b
12cm
(4.75”)
2.3m (90.55”)
12cm
(4.75”)
15cm (5.9”)
Determine Wall Hole Position...
(Page 10)
3a
INSTALLATION SUMMARY:
INDOOR UNIT
