Page 10
Accuracy
Function
Range and Overload
Resolution
61-732 61-736
Protection
AC Current*
40.0A/400.0A
(50Hz - 60Hz) 1.7% + 6 digits 1.7% + 10 digits
400AAC
40.0A/400.0A (60Hz - 400Hz) 3.0% + 6 digits 3.0% + 10 digits
AC Voltage
400.0V
(50Hz - 500Hz) 1.2% + 5 digits 1.2% + 8 digits
600 VDC or AC rms
600V (50Hz - 500Hz) 1.5% + 5 digits 1.5% + 8 digits
DC Voltage 400.0V/600V 0.5% + 2 digits 600 VDC or AC rms
400.0Ω/4.000kΩ/40.00kΩ/
1.0% + 4 digits
400.0k Ω
Resistance
4.000MΩ 1.5% + 4 digits
600 VDC or AC rms
40.00MΩ 3.0% + 5 digits
Continuity
Audible indication < 25Ω
N/A
600 VDC or AC rms
Response time: 500ms
Ranges & Accuracies:
AC Converter:
61-732 model is averaging sensing, rms calibrated
61-736 model is true rms sensing.
Accuracy:
Accuracy is specified as +/-(a percentage of the reading + a fixed amount) at
23°C±5°C (73.4°F ± 9°F), less than 75% relative humidity.
Temperature Coefficient: 0.1 times the applicable accuracy specification per
degree C from 0°C to 18°C and 28°C to 50°C (32°F to 64°F and 82°F to 122°F)
* Accuracy stated for crest factor ≤ 3
Input Impedance is 10MΩ.
