Verifying Continuity ( ) Measuring AC ( ) Current (Amps)
Verify the circuit is de-energized to obtain accurate measurements.
Measuring Resistance (Ohms / Ω )
14
Measuring AC ( ) or DC ( ) Voltage
• Verify the circuit is de-energized.
• The meter will sense the level of resistance and a beep if the resistance is less
than 10 Ω to confirm that continuity is present.
• Red LED will illuminate and resistance value will be displayed.
• The default setting is Continuity.
Note: When measuring current, align conductor with dash marks
on jaws.
